SPECIFICATIONS AND HARDWARE INFORMATION

Specifications

Category
General
Standards
RAM
Flash
Radio Frequency
ISM Band
4G/LTE
3G
Physical Description
Weight
Dimensions
Chassis Type
Environment
Operating Temperature
Storage Temperature
Humidity
Power Requirements
Operating Voltage
PoE Standard
PoE Input Power
2
LoRa ERP
Battery
Certifications and Compliance
EMC and Radio
Compliance
Safety Compliance
1
UL listed at 40° C, limited by 5 V power supply.
8
Description
LoRaWAN 1.0.2 specifications
LTE FDD Cat 4, 3GPP release compliant (-L4E1 models only)
HSPA+ with GPRS fallback (-L4E1 models only)
256MB
256MB
868 MHz ISM band for Europe
4G: B1, B3, B7, B8, B20, B28A (-L4E1 models only)
3G: B1, B3, B8 (-L4E1 models only)
0.41 kg
Refer to Mechanical Drawings for Dimensions.
PC-ABS
1
-0° C to +45° C
-10° C to +60° C +/-5° C up to 1 year
20%-90% RH, non-condensing
5Vdc, 1.4A
IEEE 802.3at
38-57 Vdc
13.3 dBm ERP for low power channels, maximum 14 dB.
25.8 dB for high power channels, maximum 27 dB.
Rechargeable Li-ion Polymer Battery 3.7V 5000mAh/18.5Wh provides backup power
for up to 4 hours. Battery is not user replaceable.
CE Mark, RED (EU)
UL/IEC 62368-1 , Battery: IEC 62133-2,UN38.3
®
Conduit AP MTCAP2-868 and MTCAP2-L4E1-868 Hardware Guide
