- Page 1 ® Conduit MTCAP-LNA3-915-041 and MTCAP-915-041 User Guide...
- Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
-
Page 3: Table Of Contents
CONTENTS Contents Chapter 1 – Product Overview ..........................5 Overview ..................................5 Product Build Options ..............................5 Package Contents................................5 Documentation Overview ............................. 6 Related Documentation .............................. 6 Chapter 2 – Specifications and Hardware Information ..................... 7 Dimensions..................................7 Specifications ................................8 Connectors and LEDs.............................. - Page 4 CONTENTS Removing a SIM Card..............................18 Attaching the Antenna ..............................18 Cabling the Device............................... 18 Chapter 6 – Getting Started ........................... 19 mPower Models ................................19 mLinux Models................................19 Dual Carrier Firmware for Cellular Radio........................19 Chapter 7 – Mounting the Device........................... 20 Mounting the Device..............................
-
Page 5: Chapter 1 - Product Overview
1 – 5 Volt, 2.5 Amp power supply 1 – RJ45 Ethernet cable 1 - LoRa antenna 1 – Quick Start Contact MultiTech Systems if a replacement power supply is needed. Using a different power Important: supply may damage the device and voids the warranty. Conduit ®... -
Page 6: Documentation Overview
PRODUCT OVERVIEW Documentation Overview The following documents are available at http://www.multitech.com/brands/multiconnect-conduit-ap. Select your model to find the documents specific for that device. Document Description Part Number Conduit AP MTCAP-LNA-915-041x This document. Hardware, regulatory, and S000725 and MTCAP-915-041x User Guide getting started information. -
Page 7: Chapter 2 - Specifications And Hardware Information
SPECIFICATIONS AND HARDWARE INFORMATION Chapter 2 – Specifications and Hardware Information Dimensions Conduit ® AP MTCAP-LNA3-915-041 and MTCAP-915-041 User Guide... -
Page 8: Specifications
SPECIFICATIONS AND HARDWARE INFORMATION Specifications Category Description General Standards LoRaWAN 1.0.2 specifications LTE 3GPP Release 9 HSPA+ with GPRS fallback 256MB Flash 256MB Radio Frequency ISM Band 915 MHz ISM band for US and Canada 4G/LTE 1900 (B2) / AWS 1700 (B4) / 850 (B5) / 700 (B12/13) 1900 (B2) / 850 (B5) Physical Description Weight... -
Page 9: Connectors And Leds
SPECIFICATIONS AND HARDWARE INFORMATION Connectors and LEDs LoRa only models LoRa and cellular radio models Item Description Connectors Power 5 Volt power jack. Ethernet RJ45 Ethernet jack. Reset Reset button. Reboots device or restores factory defaults. Refer to Resetting the Device details. -
Page 10: Resetting The Device
SPECIFICATIONS AND HARDWARE INFORMATION Resetting the Device You need: A pin, paperclip, or similar thin object that can fit into the reset hole To reset the device: Find the hole labeled RESET. The reset button is recessed into the case. Use the pin to press and release the RESET button as follows: Reset options: To reboot, press RESET for less than 3 seconds. -
Page 11: Mtcap-915-041
Pulse Electronics Antenna Manufacturer: Pulse Electronics Description: 868-928 MHz RP-SMA Antenna, 8" Model Number: W1063 MultiTech Part Number: 45009830L MultiTech ordering information: Ordering Part Number Quantity AN868-915A-1HRA AN868-915A-10HRA AN868-915A-50HRA Conduit ®... - Page 12 SPECIFICATIONS AND HARDWARE INFORMATION Antenna Specifications Category Description Frequency Range 868-928 MHz Impedance 50 Ohms VSWR < 2.0 Gain 3.0 dBi Radiation Omni Polarization Vertical Conduit ® AP MTCAP-LNA3-915-041 and MTCAP-915-041 User Guide...
-
Page 13: Chapter 3 - Safety Information
This battery has an estimated life expectancy of ten years. When this battery starts to weaken, the date and time may be incorrect. Battery is not user replaceable. If the battery fails, the device must be sent back to MultiTech Systems for battery replacement. -
Page 14: Handling Precautions
SAFETY INFORMATION Maintenir une distance d'au moins 20 cm (8 po) entre l'antenne du récepteur et le corps de Attention: l'utilisateur ou à proximité de personnes. Le modem n'est pas conçu pour, ou destinés à être utilisés dans les applications portables, moins de 20 cm du corps de l'utilisateur. Handling Precautions To avoid damage due to the accumulation of static charge, use proper precautions when handling any cellular device. -
Page 15: Interference With Pacemakers And Other Medical Devices
SAFETY INFORMATION Éteignez votre appareil sans fil dans les hôpitaux ou dans toutes les zones où des appareils médicaux sont susceptibles d'être utilisés. Interference with Pacemakers and Other Medical Devices Potential interference Radio frequency energy (RF) from cellular devices can interact with some electronic devices. This is electromagnetic interference (EMI). -
Page 16: Ul Notice
Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The information contained on discs or cards may be affected by the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with MultiTech's accessory specifications may invalidate the warranty. -
Page 17: Chapter 4 - Labels
(2) this device must accept any interference received, including interference that may cause undesired operation. The label shown is not the actual size. 1 - MultiTech Model Identification. 2 - MultiTech Ordering Part Number. 3 - IMEI Number 4 - Device Node Number 5 - UUID... -
Page 18: Chapter 5 - Setting Up Hardware
SETTING UP HARDWARE Chapter 5 – Setting Up Hardware Installing a SIM Card If your device has a SIM slot, you'll need a micro (3FF) SIM card from your network provider. -LNA3 models work on both Verizon and AT&T networks. The device detects the carrier based on Note: your SIM card. -
Page 19: Chapter 6 - Getting Started
If your device uses the mPower platform, getting started information is in mPower Software Guide (S000727), available through your model's page at https://www.multitech.com/brands/multiconnect-conduit-ap mLinux Models If your device uses the mLinux platform, getting started information is at http://www.multitech.net/developer/software/mlinux/getting-started-with-conduit-mlinux/ Dual Carrier Firmware for Cellular Radio This device uses a cellular radio with dual carrier firmware meaning that it can be used on different carrier networks (not simultaneously). -
Page 20: Chapter 7 - Mounting The Device
MOUNTING THE DEVICE Chapter 7 – Mounting the Device Mounting the Device The device ships with a mounting bracket. You will need Mounting bracket MTCAP2 Four #6 screws, with anchors (not provided) Screwdriver Drill Mounting Bracket Determining Location Follow these guidelines for best performance: For optimal performance, place the MTCAP2 at a level higher than the end devices. -
Page 21: Mounting The Device
MOUNTING THE DEVICE Select a location central to all devices to be connected to this MTCAP2. Avoid obstructions. Thick walls and reflective surfaces, such as metal, weaken the signal between the MTCAP2 and Important: other devices. We recommend conducting a site survey to test the signal strength in different locations before you mount the device. - Page 22 MOUNTING THE DEVICE Conduit ® AP MTCAP-LNA3-915-041 and MTCAP-915-041 User Guide...
-
Page 23: Chapter 8 - Regulatory And Environmental Information
REGULATORY AND ENVIRONMENTAL INFORMATION Chapter 8 – Regulatory and Environmental Infor- mation 47 CFR Part 15 Regulation Class B Devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 24: Industry Canada
Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements. -
Page 25: Reach Statement
REGULATORY AND ENVIRONMENTAL INFORMATION REACH Statement Registration of Substances Multi-Tech Systems, Inc. confirms that none of its products or packaging contain any of the Substances of Very High Concern (SVHC) on the REACH Candidate List, in a concentration above the 0.1% by weight allowable limit The latest 197 substances restricted per the REACH Regulation were last updated January 2019. -
Page 26: Restriction Of The Use Of Hazardous Substances (Rohs)
2015/863 of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS). These MultiTech products do not contain the following banned chemicals Lead, [Pb] < 1000 PPM Mercury, [Hg] <... -
Page 27: Information On Hs/Ts Substances According To Chinese Standards
REGULATORY AND ENVIRONMENTAL INFORMATION Information on HS/TS Substances According to Chinese Standards In accordance with China's Administrative Measures on the Control of Pollution Caused by Electronic Information Products (EIP) # 39, also known as China RoHS, the following information is provided regarding the names and concentration levels of Toxic Substances (TS) or Hazardous Substances (HS) which may be contained in Multi-Tech Systems Inc. -
Page 28: Information On Hs/Ts Substances According To Chinese Standards (In Chinese)
REGULATORY AND ENVIRONMENTAL INFORMATION Information on HS/TS Substances According to Chinese Standards (in Chinese) 依 依 照 照 中 中 国 国 标 标 准 准 的 的 有 有 毒 毒 有 有 害 害 物 物 质 质 信 信 息 息 根据中华人民共和国信息产业部... -
Page 29: Index
INDEX Index ISED antenna approval..........11 antenna .................11 attach ...............18 labels ................17 LEDs.................9 lithium battery ..............13 build options ..............5 LORA LED.................9 CELL LED ................9 maintenance ..............15 certifications..............8 modem Chinese hazardous substances safety ...............13 Chinese version............28 mounting device ............20 English version ............27 Class B ................23 Industry Canada ............23 connectors...............9... - Page 30 INDEX interférences RF............14 user responsibility............16 transmission ..............8 WIFI LED ................9 Conduit ® AP MTCAP-LNA3-915-041 and MTCAP-915-041 User Guide...
