  • Page 1 ® Conduit MTCAP3 Hardware Guide for Europe...
  • Page 2 Legal Notices The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or death, significant property damage, or serious physical or environmental damage.
  • Page 3: Table Of Contents

    CONTENTS Contents Chapter 1 – Product Overview ..........................5 Overview ..................................5 Package Contents................................5 Product Build Options ..............................6 Documentation Overview ............................. 6 Related Documentation .............................. 6 Chapter 2 – Specifications and Hardware Information ..................... 7 Dimensions..................................7 Specifications for LEU7 and 868 MHz Models ......................8 Connectors and LEDs..............................
  • Page 4 CONTENTS Attaching the Antenna ............................... 19 Cabling the Device............................... 19 Chapter 6 – Getting Started ........................... 21 Setting Up Your Credentials (Commissioning) for mPower..................21 mPower Models First-Time Setup ..........................21 Connecting with LoRaWAN End Devices........................21 Chapter 7 – Mounting the Device........................... 22 Mounting the Device..............................
  • Page 5: Chapter 1 - Product Overview

    LoRa antenna (models with external antenna only) Not pictured Mounting feet set Quick start Important: Contact MultiTech Systems if a replacement power supply is needed. Using a different power supply may damage the device and voids the warranty. ® Conduit AP MTCAP3 Hardware Guide for Europe...
  • Page 6: Product Build Options

    MTCAP3-LEU7-A23EEA-DEM LTE Cat 4 mPower programmable access point with LoRa 868 MHz for Europe Documentation Overview The following documents are available at http://www.multitech.com/brands/multiconnect-conduit-ap. Select your model to find the documents specific for that device. Document Description (Part Number) Conduit AP MTCAP3 Hardware Guide for This document.
  • Page 7: Chapter 2 - Specifications And Hardware Information

    SPECIFICATIONS AND HARDWARE INFORMATION Chapter 2 – Specifications and Hardware Information Dimensions ® Conduit AP MTCAP3 Hardware Guide for Europe...
  • Page 8: Specifications For Leu7 And 868 Mhz Models

    SPECIFICATIONS AND HARDWARE INFORMATION Specifications for LEU7 and 868 MHz Models Category Description General Standards LoRaWAN 1.0.4 specifications LTE FDD Cat 4, 3GPP release 11 compliant (LEU7 models only) WCDMA/GSM fallback Radio Frequency ISM Band 868 MHz ISM LTE FDD B1/B3/B7/B8/B20/B28A (LEU7 models only) WCDMA B1/B8 (LEU7 models only)
  • Page 9: Connectors And Leds

    SPECIFICATIONS AND HARDWARE INFORMATION Connectors and LEDs LoRa only models LoRa and cellular radio models LoRa only models with external LoRa antenna LoRa and cellular radio models with external LoRa antenna Note: Some features are available only on select models. ®...
  • Page 10 SPECIFICATIONS AND HARDWARE INFORMATION Item Description Connectors Power 5 Volt power jack. Ethernet RJ45 Ethernet jack. Reset Reset button. Reboots device or restores factory defaults. Refer to Resetting the Device details. LORA RP-SMA connector for external LoRa antenna. (Select models) Cellular models only.
  • Page 11: Ac Power Consumption

    SPECIFICATIONS AND HARDWARE INFORMATION AC Power Consumption Ethernet active, cellular connection established, LoRa RX: 2W Ethernet active, cellular connection at maximum transmit power, LoRa RX+TX: 5W LoRa Power LoRa Maximum Output Power Internal antenna models: Maximum ERP : 12.3 dBm - 24.8 dBm External antenna models: Maximum ERP : 13.0 dBm - 25.5 dBm ERP = EIRP - 2.15 dB...
  • Page 12: Resetting The Device

    SPECIFICATIONS AND HARDWARE INFORMATION Resetting the Device You need: A pin, paperclip, or similar thin object that can fit into the reset hole To reset the device: Find the hole labeled RESET. The reset button is recessed into the case. Use the pin to press and release the RESET button as follows: Reset options: To reboot, press RESET for less than 3 seconds.
  • Page 13: Antenna

    SPECIFICATIONS AND HARDWARE INFORMATION Antenna Your device ships with the following antenna. Contact MultiTech if you need a replacement antenna. LoRa Antenna Manufacturer: PulseLarsen Antenna Description: 868-928 MHz RP-SMA Antenna, 8" Model Number: W1063 MultiTech ordering information: Ordering Part Number...
  • Page 14: Chapter 3 - Safety Information

    SAFETY INFORMATION Chapter 3 – Safety Information Power Supply Caution CAUTION: Do not replace the power supply with one designed for another product; doing so can damage the modem and void your warranty. Adapter shall be installed near the equipment and shall be easily accessible. CAUTION: Pour garantir une protection continue contre les risques d'incendie, remplacez les fusibles uniquement par des fusibles du même type et du même calibre.
  • Page 15: Sécurité Relative Aux Appareils À Radiofréquence (Rf)

    SAFETY INFORMATION Switch OFF your wireless device in hospitals and any other place where medical equipment may be in use. Sécurité relative aux appareils à radiofréquence (RF) À cause du risque d'interférences de radiofréquence (RF), il est important de respecter toutes les réglementations spéciales relatives aux équipements radio.
  • Page 16: Device Maintenance

    Do not expose the device to water, rain, or spilled beverages. It is not waterproof. Exposure to liquids could result in damage to the device. Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with the device's accessory specifications may invalidate the warranty.
  • Page 17: Chapter 4 - Labels

    Actual labels vary depending on the regulatory approval markings and content. The label shown is not the actual size. 1 - MultiTech Model Identification. 2 - MultiTech Ordering Part Number. 3 - UUID 4 - Ethernet MAC Address 5 - Device Node Number...
  • Page 18: Mtcap3-Leu7 Models

    LABELS MTCAP3-LEU7 Models Device Label Package Label ® Conduit AP MTCAP3 Hardware Guide for Europe...
  • Page 19: Chapter 5 - Setting Up Hardware

    SETTING UP HARDWARE Chapter 5 – Setting Up Hardware Installing a SIM Card Models with cellular capability have a micro SIM slot, you'll need a micro (3FF) SIM card from your network provider. To install the SIM card: With the contact side facing down, align the notched edge as shown and slide the SIM card completely into the SIM holder.
  • Page 20 SETTING UP HARDWARE Ethernet only models with external LoRa antenna Ethernet only models, all internal antennas Cellular models with external LoRa antenna Cellular models, all internal antennas ® Conduit AP MTCAP3 Hardware Guide for Europe...
  • Page 21: Chapter 6 - Getting Started

    To do this: Note: MultiTech recommends using Firefox. Open a browser on your computer and enter the default IP address in the URL field, 192.168.2.1. Most browsers display a warning about HTTP addresses being unsafe because of a self-signed certificate.
  • Page 22: Chapter 7 - Mounting The Device

    MOUNTING THE DEVICE Chapter 7 – Mounting the Device Mounting the Device The device ships with a mounting bracket. You will need Device Mounting bracket Four #6 (3.5mm) screws with anchors (not provided) Screwdriver Drill Mounting Bracket Determining Location Follow these guidelines for best performance: The LoRa antenna is omnidirectional, but for best results, mount the device so the LoRa antenna is in a vertical position as shown in the following image.
  • Page 23 MOUNTING THE DEVICE Drill holes for the screws and insert anchors. Place the mounting bracket and secure it with screws. Attach the device to the bracket and rotate until it locks into place. ® Conduit AP MTCAP3 Hardware Guide for Europe...
  • Page 24 MOUNTING THE DEVICE Models with Internal LoRa Antenna Only Models with External LoRa Antenna ® Conduit AP MTCAP3 Hardware Guide for Europe...
  • Page 25: Chapter 8 - Regulatory Information

    Substances) complements the WEEE Directive by banning the presence of specific hazardous substances in the products at the design phase. The WEEE Directive covers all MultiTech products imported into the EU as of August 13, 2005. EU-based manufacturers, distributors, retailers and importers are obliged to finance the costs of recovery from municipal collection points, reuse, and recycling of specified percentages per the WEEE requirements.
  • Page 26: Reach-Svhc Statement

    High Concern (SVHC) on the REACH Candidate List, in a concentration above the 0.1% by weight allowable limit. For the current REACH-SVHC statement, refer to additional regulatory documents at: https://www.multitech.com/support/support Refer to the following for the most current candidate list of substances: https://echa.europa.eu/candidate-list-...
  • Page 27: Restriction Of The Use Of Hazardous Substances (Rohs)

    2015/863 of the European Parliament (Restriction of the use of certain Hazardous Substances in electrical and electronic equipment - RoHS 3). These MultiTech products do not contain the following banned chemicals Lead, [Pb] < 1000 PPM Mercury, [Hg] <...
  • Page 28: Index

    INDEX Index LoRa power ..............11 AC power consumption..........11 antenna .................13 attach ...............19 maintenance ..............16 modem safety ...............14 mounting device ............22 build options ..............6 mPower software............21 CELL LED ................9 package contents ............5 certifications..............8 Ports Ethernet ...............14 configuring ..............21 power jack...............9 connectors...............9 power measurements loRa ................11 power supply..............19...
  • Page 29 INDEX user responsibility............16 ® Conduit AP MTCAP3 Hardware Guide for Europe...
