Determined using the internal LoRa antenna of 0.85 dB gain. If using an external LoRa antenna, adjust levels to
ensure maximum values are not exceeded.
Important: 2G fallback can cause issues when operating on battery power. If you have a SIM that supports 2G
fallback, consult your carrier for options.

Power Measurements

Cellular Radio Models

Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source
when determining product load.
Constant Current Mode: Voltage during charging in constant current mode was between 3.2 VDC
and 4.0 VDC.
Full Battery Mode: Voltage was between was 4.04 VDC.
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what transmission
scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
Inrush Charge: The total inrush charge at power on.
Radio Protocol Battery State
5.0 Volts
WCDMA Band 1 Battery Full Chg
(1922 MHz) (4.04 VDC)
LTE Band 7 Battery Full Chg
(2535 MHz) (4.04 VDC)
WCDMA Band 1 Battery Charging
(1922 MHz) in Constant
Current Mode
LTE Band 5 Battery Charging
(836.5 MHz) in Constant
Current Mode
POE Only 38 VDC
WCDMA Band 1 Battery Full Chg
(1922 MHz) (4.04 VDC)
LTE Band 7 Battery Full Chg
(2535 MHz) (4.04 VDC)
®
Conduit AP MTCAP2-868 and MTCAP2-L4E1-868 Hardware Guide
Cellular Average
Call Box Measured
Connectio Current at
n, No Data Maximum
Power
294 mA 1.07 A
210 mA 1.18 A
1.21 A 1.64 A
1.15 A 1.67 A
55 mA 178 mA
51 mA 195 mA
SPECIFICATIONS AND HARDWARE INFORMATION
TX Pulse (AVG) Total Inrush
Amplitude Charge
Current for Measured in
GSM850 or Millicoulombs
Peak Current
for HSDPA/LTE
1.2 A 0.273 mC
1.31 A 0.273 mC
1.78 A 0.042 mC
1.77 A 0.042 mC
248 mA 0.825 mC
284 mA 0.825 mC
Total
Inrush
Charge
Duration
During
Power Up
1.28 mS
1.28 mS
1.33 mS
1.33 mS
7.10 mS
7.10 mS
