Chapter 1 – Product Overview

Overview

Conduit AP (MTCAP2) connects thousands of IoT assets to the cloud using the LoRaWAN
network coverage to difficult to reach areas and is capable of packet forwarding user data between LoRa end
points and a centrally located network server on the cloud, in a data center, or a public network.
Note: Check for an updated version of this document
conduit-ap.

Product Build Options

Product
MTCAP2-L4E1-868-004A-POE-BB
MTCAP2-868-003A-BB
MTCAP2-L4E1-868-003A-BB

Package Contents

Your device ships with the following:
1 – Conduit AP Access Point
1 – 5 Volt, 2.5 Amp power supply (-03x models only)
1 – RJ45 Ethernet cable
1 – Mounting bracket
1 - Bumpon set
1 – Quick Start
Important: Contact MultiTech Systems if a replacement power supply is needed. Using a different power
supply may damage the device and voids the warranty.
®
Conduit AP MTCAP2-868 and MTCAP2-L4E1-868 Hardware Guide
athttps://www.multitech.com/brands/multiconnect-
Description
LTE Cat 4 mPower Programmable Access Point with Power over Ethernet,
battery backup, and internal LoRa antenna (Europe)
Ethernet-only mPower Programmable Access Point with battery backup,
and internal LoRa antenna (Europe)
LTE Cat 4 mPower Programmable Access Point with battery backup, and
internal LoRa antenna (Europe)
PRODUCT OVERVIEW
®
protocol. It expands LoRa
