SPECIFICATIONS AND HARDWARE INFORMATION
Radio Protocol Battery State
LTE Band 7 Battery Charging
(2535 MHz) in Constant
Current Mode
POE Only 56VDC
WCDMA Band 1 Battery Full Chg
(1922 MHz) (4.04 VDC)
LTE Band 7 Battery Full Chg
(2535 MHz) (4.04 VDC)
WCDMA Band 1 Battery Charging
(1922 MHz) in Constant
Current Mode
LTE Band 7 Battery Charging
(2535 MHz) in Constant
Current Mode

Connectors and LEDs

Note: Some features are available only on select models.
Item Description
Connectors
10
Cellular Average
Call Box Measured
Connectio Current at
n, No Data Maximum
Power
200 mA 387 mA
47 mA 133 mA
42 mA 146 mA
149 mA 240 mA
149 mA 267 mA
LoRa and cellular radio models
LoRa only models
®
Conduit AP MTCAP2-LNA3-915 and MTCAP2-915 Hardware Guide
TX Pulse (AVG) Total Inrush
Amplitude Charge
Current for Measured in
GSM850 or Millicoulombs
Peak Current
for HSDPA/LTE
400 mA 0.142 mC
200 mA 0.753 mC
220 mA 0.753 mC
276 mA 0.156 mC
348 mA 0.156 mC
Total
Inrush
Charge
Duration
During
Power Up
7.07 mS
6.8 mS
6.8 mS
16.2 mS
16.2 mS
