Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all models of this vehicle and includes descriptions and explanations of optional as well as standard equipment.
Page 2 Introduction CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the Department of Transportation and other government agencies in your country.
Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Page 5: Table Of Contents
Table of contents Foreword Vehicle information Safety system Instrument cluster Convenient features Driving your vehicle Driver assistance system Emergency situations Maintenance Index...
Page 6: Foreword
1. Foreword Foreword ......................1-2 Hyundai motor company .................. 1-2 How to use this manual ..................1-3 Safety messages ....................1-3 Fuel requirements .....................1-4 Gasoline engine ......................1-4 Unleaded ........................1-4 Leaded ........................1-5 Gasoline containing alcohol and methanol ............. 1-5 Other fuels ........................
Page 7: Foreword
Your Owner’s Manual will introduce you to the features and operation of your new HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it, read this Owner’s Manual carefully before driving your new vehicle.
Page 8: How To Use This Manual
HOW TO USE THIS MANUAL We want to help you get the greatest possible driving pleasure from your vehicle. Your Owner’s Manual can assist you in many ways. We strongly recommend that you read the entire manual. In order to minimize the chance of death or injury, you must read the WARNING and CAUTION sections in the manual.
Page 9: Fuel Requirements
Never add any fuel system cleaning agents to the fuel tank other than what has been specified (We recommend that you consult an authorized HYUNDAI dealer for details.) WARNING •...
Page 10: Leaded
Leaded (if equipped) For some countries, your vehicle is designed to use leaded gasoline. When you are going to use leaded gasoline, we recommend that you ask an authorized HYUNDAI dealer. Octane rating of leaded gasoline is same with unleaded one.
Page 11: Use Of Mtbe
Fuel Additives HYUNDAI recommends that you use unleaded gasoline which has an octane rating of RON (Research Octane Number) 95 / AKI (Anti Knock Index) 91 or higher (for Europe) or Octane Rating of RON (Research Octane Number) 91 / AKI (Anti-Knock Index) 87 or higher (except Europe).
Page 12: Diesel Engine
Diesel engine Diesel fuel Diesel engine must be operated only on commercially available diesel fuel that complies with EN 590 or comparable standard. (EN stands for “European Norm”). Do not use marine diesel fuel, heating oils, or non-approved fuel additives, as this will increase wear and cause damage to the engine and fuel system.
Page 13: Vehicle Modifications
RETURNING USED VEHICLES (FOR EUROPE) HYUNDAI promotes an environmentally sound treatment for end of life vehicles and offers to take back your Hyundai end of life vehicles in accordance with the European Union (EU) End of Life Vehicles Directive. You can get detailed information from your national HYUNDAI homepage.
Page 14: Vehicle Information
2. Vehicle information Exterior overview (I) ...................2-2 Exterior overview (II) ..................2-4 Interior overview (I) ..................2-6 Interior overview (II) ..................2-8 Engine compartment ..................2-10 Dimensions ....................... 2-13 Engine ....................... 2-13 Bulb wattage ....................2-14 Tires and wheels ....................2-15 Load and speed capacity tires (for Europe) ...........
Page 15: Exterior Overview (I)
Vehicle information EXTERIOR OVERVIEW (I)   Front view Front view   The actual shape may differ from the illustration. OOS010001K OOS010001K 1. Hood ............5-37 6. Outside rearview mirror ......5-25 2. Head lamp ........5-46, 9-73 7. Sunroof ...........5-32 3. DRL (Daytime Running Light) ....9-71 8.
Page 16   Front view (N Line) Front view (N Line)   The actual shape may differ from the illustration. OOSN010001K OOSN010001K 1. Hood ............5-37 6. Outside rearview mirror ......5-25 2. Head lamp ........5-46, 9-73 7. Sunroof ...........5-32 3. DRL (Daytime Running Light) ....9-71 8.
Page 17: Exterior Overview (Ii)
Vehicle information EXTERIOR OVERVIEW (II)   Rear view Rear view   The actual shape may differ from the illustration. OOS010002K OOS010002K 1. Door ............5-14 6. High mounted stop lamp .....9-83 2. Fuel filler door ........5-41 7. Rear window wiper blade ....9-42 3.
Page 18   Rear view (N Line) Rear view (N Line)   The actual shape may differ from the illustration. OOSN010002K OOSN010002K 1. Door ............5-14 6. High mounted stop lamp .....9-83 2. Fuel filler door ........5-41 7. Rear window wiper blade ....9-42 3.
Page 19: Interior Overview (I)
Vehicle information INTERIOR OVERVIEW (I)   Left-hand drive type Left-hand drive type   The actual shape may differ from the illustration. OOS010003K OOS010003K [A] : Type A, [B] : Type B 1. Inside door handle ......... 5-16 9. Head-up display button ....... 5-45 2.
Page 20   Right-hand drive type Right-hand drive type   The actual shape may differ from the illustration. OOS010003R OOS010003R [A] : Type A, [B] : Type B 1. Inside door handle ......... 5-16 9. Head-up display button ....... 5-45 2.
Page 21: Interior Overview (Ii)
Vehicle information INTERIOR OVERVIEW (II)   Left-hand drive type Left-hand drive type   The actual shape may differ from the illustration. OOS010004L OOS010004L 1. Instrument cluster ........4-2 Intelligent variable transmission shift 2. Horn ............5-22 lever ............6-21 3.
Page 22   Right-hand drive type Right-hand drive type   The actual shape may differ from the illustration. OOS010004R OOS010004R 1. Instrument cluster ........4-2 Intelligent variable transmission shift 2. Horn ............5-22 lever ............6-21 3. Driver’s front air bag ......3-49 15.
Page 23: Engine Compartment
Vehicle information ENGINE COMPARTMENT   Smartstream G1.0 T-GDi Smartstream G1.0 T-GDi     Smarstream G1.0 T-GDi (48V) MHEV Smarstream G1.0 T-GDi (48V) MHEV   The actual engine compartment in the vehicle may differ from the illustration. OOS090047L/OOS090020L OOS090047L/OOS090020L 1.
Page 24   Smartstream G1.6 T-GDi (including N Line) Smartstream G1.6 T-GDi (including N Line)     Smarstream G2.0 Atkinson (Except Europe) Smarstream G2.0 Atkinson (Except Europe)   The actual engine compartment in the vehicle may differ from the illustration. OOS090002K/OOS090001K OOS090002K/OOS090001K 1.
Page 25 Vehicle information   Smartstream D1.6 (48V) MHEV Smartstream D1.6 (48V) MHEV   The actual engine compartment in the vehicle may differ from the illustration. OOS090022L OOS090022L 1. Engine coolant reservoir .......9-31 5. Air cleaner ..........9-37 Engine coolant cap ....... 9-32 6.
Page 26: Dimensions
DIMENSIONS Items mm (in) 4,205 (165.55) Overall length N Line: 4,215 (165.94) Overall width 1800 (70.86) 1550 (61.02) / 1565 (61.61)* Overall height N Line: 1,560 (61.42 ) / 1,570 (61.81)* 205/60 R16 1575 (62.0) 215/55 R17 1563 (61.53) Front tread 1559 (61.37) 235/45 R18 N Line: 1,559 (61.73)
Page 27: Bulb Wattage
Vehicle information BULB WATTAGE Light Bulb Bulb Type Wattage Low (Type A) High (Type A) Low (Type B) Headlamp High (Type B) Low Beam Assist-static Front lamp Turn signal lamp PY21W Turn signal lamp (Outside mirror) Daytime running lamp (DRL) / position lamp Fog lamp Stop/Tail...
Page 28: Tires And Wheels
TIRES AND WHEELS Inflation pressure Wheel bolt kPa (psi) Wheel torque Items Tire size size Normal load Maximum load kgf·m (lbf·ft, N·m) Front Rear Front Rear 205/60 R16 6.5J x 16 Full size tire 215/55 R17 7.0J x 17 2.3 (230,33) 2.5 (250,36) 11~13 235/45 R18...
Page 29 R-1234yf : 450 (15.87) ± 25 (0.88) R-1234yf (For Europe) g (oz.) R-134a : 500 (17.63) ± 25 (0.88) R-134a (Except Europe) Compressor lubricant 120 (4.23) ± 10 (0.35) g (oz.) We recommend that you contact an authorized HYUNDAI dealer for more details. 2-16...
Page 30: Vehicle Weight And Luggage Volume
VEHICLE WEIGHT AND LUGGAGE VOLUME Gasoline Engine Diesel Engine Smart- stream Smart- Smartstream G1.0 Smartstream stream Smartstream D1.6 G1.0 T-GDi T-GDi G 1.6T-GDi G2.0 (48V) MHEV Items (48V) Atkinson MHEV Gross vehicle 1770 1761 1795 1840 1915 1835 1875 1895 1965 weight (3902)
Page 31: Recommended Lubricants And Capacities
Vehicle information RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification...
Page 32 Lubricant Volume Classification Intelligent Smartstream variable Gasoline 6.7 ℓ G2.0 CVTF SP-CVT1 transmission Engine ( 7.1 US qt.) Atkinson fluid Smartstream G1.0 T-GDi Gasoline API GL-4, SAE 70W Engine Dual clutch Smartstream HK D DCTF TGO-10 (SK) 1.6~1.7 ℓ transmission G1.6 T-GDi SPIRAX S6 GHDE 70W (1.7~1.8 US qt.)
Page 33: Recommended Sae Viscosity Number
Vehicle information Recommended SAE viscosity number CAUTION Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mechanisms that could be damaged.
Page 34  Smartstream G2.0 Atkinson Temperature Range for SAE Viscosity Numbers °C Temperature (°F) For all countries 0W-20  Smartstream D1.6 (48V) MHEV Temperature Range for SAE Viscosity Numbers °C Temperature (°F) 10W-30/40 5W-30/40 Diesel Engine Oil 0W-30 0W-20 2-21...
Page 35: Vehicle Identification Number (Vin)
Vehicle information VEHICLE IDENTIFICATION VEHICLE CERTIFICATION NUMBER (VIN) LABEL   Frame number Frame number   OOS087001 OOS087001 OOS087002 OOS087002 The vehicle identification number (VIN) The vehicle certification label attached is the number used in registering your on the driver’s (or front passenger’s) vehicle and in all legal matters pertaining side center pillar gives the vehicle to its ownership, etc.
Page 36: Tire Specification And Pressure Label
TIRE SPECIFICATION AND ENGINE NUMBER PRESSURE LABEL   Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi /   Smartstream G1.0 T-GDi (48V) MHEV Smartstream G1.0 T-GDi (48V) MHEV OOS010022L OOS010022L   Smartstream G1.6 T-GDi Smartstream G1.6 T-GDi   OOS087003 OOS087003 The tires supplied on your new...
Page 37: Air Conditioner Compressor Label
Directive number, production number, refrigerant 1995/5/EC. (1) and refrigerant oil (2). Further information including the manufacturer’s declaration of conformity is available on Hyundai web site as follows; http://service.hyundai-motor.com 2-24...
Page 38: Fuel Label
FUEL LABEL (IF EQUIPPED) Gasoline engine Diesel engine The fuel label is attached on the fuel filler The fuel label is attached on the fuel filler door. door. OTM048455L OTM048455L OTM048456L OTM048456L A. Octane rating of unleaded gasoline A. Fuel : Diesel 1.
Page 39: Safety System
3. Safety system This chapter provides you with important information about how to protect yourself and your passengers. It explains how to properly use your seats and seat belts, and how your air bags work. Additionally, this chapter explains how to properly restrain infants and children in your vehicle. Important safety precautions ................3-2 Always wear your seat belt ..................
Page 40: Important Safety Precautions
Safety system IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Drivers can become distracted when they take their eyes and attention off and recommendations throughout this section, and throughout this manual. the road or their hands off the wheel to The safety precautions in this section are focus on activities other than driving.
Page 41: Seats
SEATS   Left-hand drive Left-hand drive   OOS030001K OOS030001K [A] : Front seat, [B] : Rear seat Front seat Rear seat (1) Forward and backward (7) Armrest* (2) Seatback angle (8) Seatback folding (3) Seat cushion height* (9) Headrest (4) Lumbar support (Driver’s seat)* (5) Seat warmer*/Air ventilation seat* * : if equipped...
Page 42 Safety system   Right-hand drive Right-hand drive   OOS030001R OOS030001R [A] : Front seat, [B] : Rear seat Front seat Rear seat (1) Forward and backward (7) Armrest* (2) Seatback angle (8) Seatback folding (3) Seat cushion height* (9) Headrest (4) Lumbar support (Driver’s seat)* (5) Seat warmer*/Air ventilation seat*...
Page 43: Safety Precautions
Safety precautions Air bags You can take steps to reduce the risk Adjusting the seats so that you are sitting of being injured by an inflating air bag. in a safe, comfortable position plays an Sitting too close to an air bag greatly important role in driver and passenger increases the risk of injury in the event safety, together with seat belts and air...
Page 44: Front Seats
Safety system Seat belts Front seats Always fasten your seat belt before The front seat can be adjusted by using starting any trip. At all times, passengers the control lever (or knob) or switches should sit upright and be properly located on the outside of the seat restrained.
Page 45 CAUTION To prevent injury: • Do not adjust your seat while wearing your seat belt. Moving the seat cushion forward may cause strong pressure on your abdomen. • Do not allow your hands or fingers to get caught in the seat mechanisms while the seat is moving.
Page 46 Safety system Reclining seatback Sitting in a reclined position when the vehicle is in motion can be dangerous. Even when buckled up, the protections of your restraint system (seat belts and/or air bags) is greatly reduced by reclining your seatback. WARNING NEVER ride with a reclined seatback when the vehicle is moving.
Page 47 Power adjustment (if equipped) WARNING NEVER allow children in the vehicle unattended. The power seats are operable when the engine is turned off. NOTICE To prevent damage to the seats: • Always stop adjusting the seats when OOS037005 OOS037005 the seat has been adjusted as far Forward and rearward adjustment forward or rearward as possible.
Page 48 Safety system Reclining seatback Sitting in a reclined position when the vehicle is in motion can be dangerous. Even when buckled up, the protections of your restraint system (seat belts and air bags) is greatly reduced by reclining your seatback. WARNING NEVER ride with a reclined seatback when the vehicle is moving.
Page 49: Rear Seats
Rear seats Folding the rear seat The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING • Never allow passengers to sit on top of the folded down seatback while OOS037008 OOS037008 the vehicle is moving.
Page 50 Safety system OOS037020 OOS037020 OOS037022 OOS037022 5. To use the rear seat, lift and push the 3. Locate the seatbelt toward the seatback rearward. outboard position before folding down the seatback. If not, the seatbelt Push the seatback firmly until it clicks system may be interfered by the into place.
Page 51 Armrest (if equipped) CAUTION Damaging rear seat belt buckles When you fold the rear seatback, insert the buckle in the pocketbetween the rear seatback and cushion. Doing so can prevent the buckle from being damaged by the rear seatback. CAUTION Rear seat belts When returning the rear seatbacks OOS037024...
Page 52: Headrest
Safety system NOTICE Headrest To prevent damage, NEVER hit or pull The vehicle’s front and rear seats have on the headrests. adjustable headrests. The headrests provide comfort for passengers, but more importantly they are designed to CAUTION help protect passengers from whiplash and other neck and spinal injuries during When there is no occupant in the rear an accident, especially in a rear impact...
Page 53 Front seat headrests OOS037010 OOS037010 Forward and rearward adjustment OOSEV038012L OOSEV038012L (if equipped) The driver’s and front passenger’s seats The headrest may be adjusted forward are equipped with adjustable headrests to 3 different positions by pulling the for the passengers safety and comfort. headrest forward to the desired detent.
Page 54 Safety system   Type A Type A   OLF034015 OLF034015 OOS037011 OOS037011   Type B Type B   NOTICE If you recline the seatback towards the front with the headrest and seat cushion raised, the headrest may come in contact with the sunvisor or other parts of the vehicle.
Page 55 Rear seat headrests   Type A Type A   OOSEV038004 OOSEV038004   Type B Type B   OOSEV038030L OOSEV038030L The rear seats are equipped with headrests in all the seating positions for the passenger’s safety and comfort. CAUTION •...
Page 56: Seat Warmers And Air Ventilation Seats
Safety system Seat warmers and air ventilation seats Front seat warmers (if equipped) Seat warmers are provided to warm the seats during cold weather. WARNING The seat warmers can cause a SERIOUS BURN, even at low temperatures and especially if used for long periods of OOS037018 OOS037018 time.
Page 57 NOTICE Information To prevent damage to the seat warmers With the seat warmer switch in the ON and seats: position, the heating system in the seat • Never use a solvent such as paint turns off or on automatically depending on thinner, benzene, alcohol or gasoline the seat temperature.
Page 58 HIGH ( we recommend that you have your vehicle inspected by an authorized LOW ( MIDDLE ( HYUNDAI dealer. • When pressing the switch for more than 1.5 seconds with the air ventilation seat operating, the operation will turn OFF.
Page 59: Seat Belts
SEAT BELTS This section describes how to use the • Never wear a seat belt over fragile seat belts properly. It also describes objects. If there is a sudden stop or some of the things not to do when using impact, the seat belt can damage it.
Page 60: Seat Belt Warning Light
Safety system Seat belt warning light Seat belt warning   Instrument cluster Instrument cluster   OOS030025K OOS030025K Front passenger’s seat belt warning As a reminder to the front passenger, OAM032161L OAM032161L the front passenger’s seat belt warning Driver’s seat belt warning light will illuminate for approximately 6 As a reminder to the driver, the seat seconds each time you turn the ignition...
Page 61 WARNING Riding in an improper position adversely affects the front passenger’s seat belt warning system. It is important for the driver to instruct the passenger to properly be seated as instructed in this manual. Information • You can find the front passenger’s seat OOSEV038011 OOSEV038011 belt warning light on the center fascia...
Page 62: Seat Belt Restraint System
Safety system NOTICE Seat belt restraint system Lap/shoulder belt If you are not able to smoothly pull enough of the seat belt out from the retractor, firmly pull the seat belt out and release it. After release, you will be able to pull the belt out smoothly.
Page 63 Height adjustment You can adjust the height of the shoulder belt anchor to one of the four different positions for maximum comfort and safety. The shoulder portion should be adjusted so it lies across your chest and midway over your shoulder nearest the door, not over your neck.
Page 64 Safety system Rear center seatbelt Pre-tensioner seat belt (3-point rear center seat belt) OLMB033039 OLMB033039 OOSEV038031L OOSEV038031L Your vehicle is equipped with driver’s and front passenger’s and rear passengers When using the rear center seat belt, the (if equipped) Pre-tensioner Seat Belts buckle with the “CENTER”...
Page 65 (3) SRS control module (4) Rear Retractor pre-tensioner (if equipped) CAUTION Body work on the front area of the vehicle may damage the pre-tensioner seat belt system. Therefore, we recommend the system to be serviced by an authorized HYUNDAI dealer. 3-27...
Page 66 Wash all exposed skin areas thoroughly tensioner seat belts and/or SRS control after an accident in which the pre- module be inspected by an authorized tensioner seat belts were activated. HYUNDAI dealer as soon as possible. 3-28...
Page 67: Additional Seat Belt Safety Precautions
Additional seat belt safety Seat belt use and children precautions Infant and small children Seat belt use during pregnancy Most countries have Child Restraint System laws which require children to The seat belt should always be used travel in approved Child Restraint System during pregnancy.
Page 68 Safety system Seat belt use and injured people Larger children Children under age 13 and who are A seat belt should be used when an too large for a booster seat should injured person is being transported. always occupy the rear seat and use the Consult a physician for specific available lap/shoulder belts.
Page 69: Care Of Seat Belts
When to replace seat belts The entire seat belt assembly or assemblies should be replaced if the vehicle has been involved in an accident. This should be done even if no damage is visible. We recommend that you consult an authorized HYUNDAI dealer. 3-31...
Page 70: Child Restraint System (Crs)
• After an accident, we recommend Most countries have regulations which a HYUNDAI dealer to check the require children to travel in approved Child Restraint System, seat belts, Child Restraint Systems.
Page 71: Selecting A Child Restraint System (Crs)
Selecting a Child Restraint System (CRS) When selecting a Child Restraint System for your child, always: • Make sure the Child Restraint System has a label certifying that it meets applicable Safety Standards of your country. A Child Restraint System may only be installed if it was approved in accordance with the requirements of OOS037028...
Page 72 Safety system Booster seats A booster seat is a Child Restraint System designed to improve the fit of the vehicle’s seat belt system. A booster seat positions the seat belt so that it fits properly over the stronger parts of your child’s body.
Page 73: Installing A Child Restraint System (Crs)
Installing a Child Restraint • Make sure the Child Restraint System is firmly secured. After installing a System (CRS) Child Restraint System to the vehicle, push and pull the seat forward and WARNING from side-to-side to verify that it is securely attached to the seat.
Page 74 Safety system Suitability of each seating position for belted & ISOFIX Child Restraint Systems according to UN regulations (for Europe) (Information for use by vehicle users and CRS manufacturers) • Yes : Suitable for fitment of the designated category of CRS •...
Page 75 Position in the Position in the Seat number Seat number vehicle vehicle Front left row left Front center row center Front right row right Note : You should adjust seatback or seat pumping(if equipped) properly. Note : The seating position(number 5) is not suitable for fitment of child restraint system with support leg.
Page 76 Safety system Recommended Child Restraint Systems (for Europe) ECE-R44/R129 Mass group Name Manufacturer Type of Fixation Approval No. Cabriofix & Group 0+ Maxi Cosi ISOFIX E4 04443907 Familyfix ISOFIX and Group I Duo Plus Britax Römer E1 04301133 top-tether ISOFIX and Group II KidFix II XP Britax Römer...
Page 77 Suitability of each seating position for belted & ISOFIX Child Restraint Systems according to UN regulations (except Europe) (Information for vehicle users and CRS manufacturers) • Yes : Suitable for fitment of the designated category of CRS • No : Not suitable for fitment of the designated category of CRS •...
Page 78 Safety system Position in the Position in the Seat number Seat number vehicle vehicle Front left row left Front center row center Front right row right Note : You should adjust seatback or seat pumping(if equipped) properly. Note : The seating position(number 5) is not suitable for fitment of child restraint system with support leg.
Page 79 ISOFIX anchorage and top-tether anchorage (ISOFIX anchorage system) for children The ISOFIX system holds a Child Restraint System during driving and in an accident. This system is designed to make installation of the Child Restraint System easier and reduce the possibility of improperly installing your Child Restraint System.
Page 80 Safety system Securing a Child Restraint System with the “ISOFIX Anchorage System” To install an i-Size or ISOFIX-compatible Child Restraint System in either of the rear outboard seating positions: 1. Move the seat belt buckle away from the ISOFIX anchorages. 2.
Page 81 • Following an accident we recommend to have the ISOFIX system inspected by your HYUNDAI dealer. An accident can damage the ISOFIX system and may not properly secure the Child Restraint System.
Page 82 Safety system Securing a Child Restraint System WARNING with a lap/shoulder belt Take the following precautions when When not using the ISOFIX system, all installing the top-tether: Child Restraint Systems must be secured • Read and follow all installation to a rear seat with the lap part of a lap/ instructions provided with your Child shoulder belt.
Page 83 ODH033063 ODH033063 OHI038183L OHI038183L 3. Fasten the lap/shoulder belt latch 4. Remove as much slack from the belt into the buckle. Listen for the distinct as possible by pushing down on the “click” sound. Child Restraint System while feeding the shoulder belt back into the retractor.
Page 84: Air Bag - Supplemental Restraint System
Safety system AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM   Left-hand drive Left-hand drive   The actual air bags in the vehicle may differ from the illustration. OOS037034/OOS037070L OOS037034/OOS037070L 1. Driver’s front air bag 4. Curtain air bag* 2. Passenger’s front air bag 5.
Page 85   Right-hand drive Right-hand drive   The actual air bags in the vehicle may differ from the illustration. OOS037034R/OOS037070E OOS037034R/OOS037070E 1. Driver’s front air bag 4. Curtain air bag* 2. Passenger’s front air bag 5. Front passenger air bag ON/OFF switch* 3.
Page 86 Safety system The vehicles are equipped with a WARNING Supplemental Air Bag System for the AIR BAG SAFETY PRECAUTIONS driver’s seat and front passenger’s seats. ALWAYS use seat belts Child Restraint The front air bags are designed to Systems - every trip, every time, supplement the three-point seat belts.
Page 87: Where Are The Air Bags
Where are the air bags? The SRS consists of air bags which are located in the center of the steering Driver’s and passenger’s front air wheel, in the driver’s side lower crash bags pad below the steering wheel, and the ...
Page 88 Safety system OOS037071L OOS037071L OOS030053L OOS030053L Passenger’s front air bag ON/OFF switch To reactivate the passenger’s front air (if equipped) bag: The purpose of the switch is to disable Insert the key or a similar rigid device the passenger’s front air bag in order into the passenger’s front air bag to transport occupants who are at ON/OFF switch and turn it to the ON...
Page 89 ON/OFF switch is set to the OFF position. • We recommend that an authorized HYUNDAI dealer inspect the passenger’s front air bag ON/OFF switch and the SRS air bag system as soon as possible.
Page 90 The curtain air bags are not designed • If the seat or seat cover is damaged, to deploy in all side impact or rollover we recommend that the system be situations. serviced by an authorized HYUNDAI dealer. 3-52...
Page 91: How Does The Air Bags System Operate
How does the air bags system WARNING operate? To reduce the risk of serious injury or death from an inflating curtain air bag, take the following precautions: • All seat occupants must wear seat belts at all times to help keep occupants positioned properly.
Page 92 We recommend that an authorized see the deflated air bags hanging out HYUNDAI dealer inspect the SRS of their storage compartments after as soon as possible if any of these the collision.
Page 93 • To help provide protection, the air   Driver’s front air bag (1) Driver’s front air bag (1)   bags must inflate rapidly. The speed of air bag inflation is a consequence of extremely short time in which to inflate the air bag between the occupant and the vehicle structures before the occupant impacts those...
Page 94 Safety system   Driver’s front air bag (3) Driver’s front air bag (3)   WARNING To prevent objects from becoming dangerous projectiles when the passenger’s air bag inflates: • Do not install or place any objects (drink holder, CD holder, stickers, etc.) on the front passenger’s panel above the glove box where the passenger’s air bag is located.
Page 95: What To Expect After An Air Bag Inflates
• Always wash exposed skin areas thoroughly with cold water and mild soap. • We recommend that an authorized HYUNDAI dealer replace the air bag immediately after deployment. Air bags are designed to be used only once. 3-57...
Page 96: Do Not Install A Child Restraint System On The Front Passenger Seat
To ensure correct function of the airbag system we recommend to replace the bumper with genuine HYUNDAI part or the equivalent (of the genuine part) specified for your vehicle. • Place the ignition switch to the...
Page 97 OOS030044K/OOS037045/OOS030046K/OOS037047/OOS037077 OOS030044K/OOS037045/OOS030046K/OOS037047/OOS037077 1. SRS control module 2. Front impact sensor (front door) 3. Side pressure sensor (front)* 4. Side impact sensor (rear)* * : if equipped 3-59...
Page 98 Safety system Air bag inflation conditions Side and curtain air bags Side and curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on the severity, speed or angles of impact resulting from a side impact collision. Although the driver’s and front passenger’s air bags are designed to inflate in frontal collisions, they also may...
Page 99 Air bag non-inflation conditions OOS030051K OOS030051K Front air bags may not inflate in side OOS037052 OOS037052 impact collisions, because occupants In certain low-speed collisions the air move in the direction of the collision, bags may not deploy. The air bags are and thus in side impacts, front air bag designed not to deploy in such cases deployment would not provide additional...
Page 100 Safety system Information • Vehicles equipped with rollover sensor The side and curtain air bags may inflate in a rollover situation, when it is detected by the rollover sensor. • Vehicles not equipped with rollover sensor The side and/or curtain air bags may inflate when the vehicle is rolled over OOS037055 OOS037055...
Page 101: Srs Care
We recommend that you consult an authorized HYUNDAI dealer for the necessary information. Failure to follow these precautions could increase the risk of personal injury.
Page 102: Additional Safety Precautions
Safety system Additional safety precautions Air bag warning labels Passengers should not move out of or change seats while the vehicle is moving. A passenger who is not wearing a seat belt during a crash or emergency stop can be thrown against the inside of the vehicle, against other occupants, or be ejected from the vehicle.
Page 103: Instrument Cluster
4. Instrument cluster Instrument cluster .................... 4-2 Instrument cluster control ...................4-3 Instrument panel illumination ...................4-3 Gauges and meters ......................4-3 Speedometer ......................4-3 Tachometer ....................... 4-4 Engine Coolant Temperature Gauge ............... 4-4 Fuel Gauge .........................4-5 Outside Temperature Gauge ..................4-5 Odometer ........................4-6 Distance to empty ....................
Page 104: Instrument Cluster
Instrument cluster INSTRUMENT CLUSTER   Conventional cluster (Type A) Conventional cluster (Type A)     Full LCD cluster (Type B) Full LCD cluster (Type B)   The actual cluster in the vehicle may differ from the illustration. For more details, refer to the “Gauges and Meters”...
Page 105: Instrument Cluster Control
Instrument cluster control Gauges and meters Instrument panel illumination Speedometer   Type A Type A   • • km/h km/h • • MPH, km/h MPH, km/h     OOS040120 OOS040120 OOS040001K OOS040001K OOS047103N OOS047103N When the vehicle’s position lights or ...
Page 106: Tachometer
Instrument cluster Tachometer Engine Coolant Temperature Gauge   Type A Type A   Type A Type A     • • Gasoline engine Gasoline engine • • Diesel engine Diesel engine • • Except Europe Except Europe •...
Page 107: Fuel Gauge
Fuel Gauge WARNING   Type A Type A   Running out of fuel can expose vehicle • • Except Europe Except Europe • • For Europe For Europe     occupants to danger. You must stop and obtain additional fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the “0...
Page 108: Odometer
Instrument cluster The temperature unit of the instrument Distance to empty cluster and climate control system will   Type A Type A   Type B Type B     change at once. Odometer   Type A Type A ...
Page 109: Transmission Shift Indicator
Transmission shift indicator Intelligent variable transmission (if equipped) Manual transmission shift indicator / Intelligent transmission shift indicator   Type A Type A   (if equipped)   Type A Type A   OTL045132 OTL045132   Type B Type B ...
Page 110 Instrument cluster Dual clutch transmission shift Dual clutch transmission shift indicator (if equipped) indicator (for Europe, if equipped)   Type A Type A   Type A Type A     OTL045132 OTL045132 OPDE046142 OPDE046142   Type B Type B ...
Page 111 In this case, we recommend that you have the vehicle inspected by an 1. Drive carefully to the nearest safe authorized HYUNDAI dealer. location and stop your vehicle. 2. With the engine stopped, check the Seat Belt Warning Light...
Page 112 In this case, avoid high speed driving and abrupt braking. We recommend you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. 4-10...
Page 113 • [Yellow] When there is a malfunction the vehicle inspected by an authorized with the auto hold system. HYUNDAI dealer as soon as possible. • In this case, we recommend that Electronic Parking Brake you have the vehicle inspected by an (EPB) warning light authorized HYUNDAI dealer.
Page 114 In this case, we recommend that you - It illuminates for approximately 3 have the vehicle inspected by an seconds and then goes off. authorized HYUNDAI dealer as soon as possible. • When there is a malfunction with the Electric Power Steering System.
Page 115 2. Turn off the engine and check the authorized HYUNDAI dealer as soon oil level. If the oil level is low, fill as possible. the engine oil to the proper level.
Page 116 50~100 km after the engine warms up, we recommend that the system be checked by an authorized HYUNDAI dealer. Even if this light doesn’t come on after the engine has started, the engine oil level should be periodically checked and topped up if required.
Page 117 - Tire Pressure Monitoring System In this case, we recommend that (TPMS) malfunction you have the vehicle inspected by an authorized HYUNDAI dealer as soon To identify the details of the warning, as possible. look at the LCD display. For more details, refer to “Tire Pressure Monitoring System (TPMS)”...
Page 118 DPF system checked by an authorized GPF system checked by an authorized HYUNDAI dealer. HYUNDAI dealer. NOTICE NOTICE If you continue to drive with the DPF...
Page 119 HYUNDAI dealer. have the vehicle inspected by an authorized HYUNDAI dealer as soon Information as possible. If the engine does not start within 10 seconds after the preheating is completed,...
Page 120 4WD system. solution warning message” in the In this case, we recommend that chapter 9. you have the vehicle inspected by an authorized HYUNDAI dealer. Electronic Stability Control (ESC) Indicator Light (if equipped) This indicator light illuminates: • When you set the ignition switch or the Engine Start/Stop button to the ON position.
Page 121 AUTO STOP Indicator Light In this case, we recommend that (if equipped) you have the vehicle inspected by an authorized HYUNDAI dealer. This indicator light illuminates: • When the engine enters the Idle Stop Immobilizer Indicator Light mode of the ISG (Idle Stop and Go) (with smart key) system.
Page 122 If any of these conditions occur, we engine if you press the Engine Start/ recommend that you have your vehicle Stop button with the smart key. (For inspected by an authorized HYUNDAI more details, refer to “Starting the dealer. Engine” in chapter 6).
Page 123 In this case, we recommend that you For more details, refer to “High Beam have the vehicle inspected by an an Assist (HBA)” in this chapter 5. authorized HYUNDAI dealer. Light ON Indicator Light This warning light blinks: When there is a malfunction with a LED headlamp related part.
Page 124 Instrument cluster 4 Wheel Drive (4WD) LOCK Cruise Indicator Light Indicator Light (if equipped) (if equipped) This indicator light illuminates: This indicator light illuminates: • Once you set the ignition switch or • When the cruise control system is Engine Start/Stop Button to the ON enabled.
Page 125 For more details, refer to “Drive Mode DBC system. Integrated Control System” in chapter In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer. For more details, refer to “Downhill Brake Control (DBC) System” in chapter 4-23...
Page 126 FCA. In this case, we recommend that Information you have the vehicle inspected by an authorized HYUNDAI dealer. If the icy road warning light appears while driving, you should drive more attentively For more information, refer to “Forward and safely, refraining from over-speeding,...
Page 127: Lcd Display Messages
LCD display messages Press brake pedal to start engine (for smart key system and dual Shift to P (for smart key system and clutch transmission) dual clutch transmission) This warning message is displayed if the This warning message is displayed if you Engine Start/Stop button changes to try to turn off the engine without the the ACC position twice by pressing the...
Page 128 If this occurs, attempt to start the engine by pressing the Engine Start/Stop button again. If the warning message appears each time you press the Engine Start/Stop button, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer. 4-26...
Page 129 Door, Hood, Tailgate open Sunroof open (if equipped) OOS040004K OOS040004K OOS047113 OOS047113 This warning is displayed indicating This warning is displayed if you turn off which door, or hood, or tailgate is open. the engine when the sunroof is open. Close the sunroof securely when leaving your vehicle.
Page 130 Instrument cluster Wiper mode Turn on FUSE SWITCH   Type A Type A   Type B Type B     OJX1049008L OJX1049008L OJX1049063L OJX1049063L OPDE046119 OPDE046119 This indicator displays which wiper speed This warning message is displayed if is selected using the wiper control.
Page 131 DPF or GPF warning light also blinks. In this case, we recommend that you have the DPF or GPF system checked by an authorized HYUNDAI dealer. DPF : Diesel Particulate Filter GPF : Gasoline Particulate Filter For more details, refer to “Warning lights”...
Page 132 This warning message is displayed if there is a malfunction with Forward Collision-Avoidance Assist (FCA). We recommend that you have the vehicle inspected by an authorized HYUNDAI dealer. For more details, refer to “Forward Collision-Avoidance Assist (FCA)” in chapter 7.
Page 133: Lcd Display
LCD DISPLAY LCD display control OOSH049025L OOSH049025L The LCD display modes can be changed by using the control buttons. Switch Function MODE button for changing modes MOVE switch for changing items SELECT/RESET button for setting or resetting the selected item 4-31...
Page 134: View Modes
Instrument cluster View modes View modes Symbol Explanation This mode displays the state of : - Smart Cruise Control (SCC) - Highway Driving Assist (HDA) - Lane Keeping Assist (LKA) - Driver Attention Warning (DAW) Driving Assist - Drivng force distribution (4WD) For more information, refer to "Smart Cruise Control (SCC)", "Highway Driving Assist (HDA)", "Lane Keeping Assist (LKA)”, “Driver Attention Warning (DAW)”...
Page 135: Trip Computer Mode
Trip computer mode Driving Assist mode OTM040039L OTM040039L OOSH049028L OOSH049028L The trip computer mode displays SCC/HDA/LKA information related to vehicle driving This mode displays the state of the Smart parameters including fuel economy, Cruise Control, Highway Driving Assist tripmeter information and vehicle speed. and Lane Keeping Assist.
Page 136: Master Warning Group
Instrument cluster Master warning group OTM040024 OTM040024 Driving force distribution (4WD) OIG059097L OIG059097L This mode displays information related to This warning light informs the driver the 4WD driving force. following situations. If the vehicle is in 4WD lock state, this - Forward Collision-Avoidance Assist mode is not displayed.
Page 137: Urea Level (Diesel Engine)
Urea level (Diesel engine) OCN7040026L OCN7040026L Tire Pressure OTM048163L OTM048163L This mode displays information related to This mode dispalys the approximate Tire Pressure. amount of remaining urea solution inside the urea solution tank. For more details, refer to "Tire Pressure Monitoring System (TPMS)"...
Page 138: User Settings Mode
Instrument cluster User settings mode Shift to P to edit settings This warning message illuminates if you try to select an item from the User Settings mode while driving. • Intelligent variable transmission / Dual clutch transmission. For your safety, change the User Settings after parking the vehicle, applying the parking brake and selecting the shift button to P(Park).
Page 139 1. Driver Assistance Items Explanation To adjust the sensitivity of Smart Cruise Control. • Fast/Normal/Slow Reaction For more details, refer to ''Smart Cruise Control (SCC)'' in chapter 7. • Highway Driving Assist To activate or deactivate the Highway Driving Assist. For more details, refer to the "Highway Driving Assist (HDA)"...
Page 140 Instrument cluster Items Explanation To adjust the Lane Keeping Assist (LKA) function. • Assist • Warning Only Lane Safety • Off For more details, refer to the "Lane Keeping Assist (LKA)" in chapter 7. • Safe Exit Warning (SEW) To activate or deactivate the Safe Exit Warning For more details, refer to the "Safe Exit Warning (SEW)"...
Page 141 2. Head-Up Display (if equipped) Items Explanation Enable Head-up If this item is checked, Head-Up Display will be activated. display Display To adjust the height of the image displayed. Height Rotation To adjust the angle of the image displayed. Brightness To adjust the brightness of the image displayed.
Page 142 Instrument cluster 3. Cluster Items Explanation • At vehicle start • After refueling Reset fuel economy • Manually To reset the fuel economy displayed. Fuel To automatically reset the fuel economy. Economy • Off/After Vehicle On/After Refueling Reset To activate or deactivate the Wiper/ Light mode. Wiper/Lights When activated, the LCD display shows the selected Wiper/Light mode Display...
Page 143 4. Lights Items Explanation To adjust the illumination level. Illumination • Level 1~20 • Off : The one touch turn signal function will be deactivated. One Touch • 3, 5, 7 Flashes : The turn signal indicator will blink 3, 5, or 7 times when Turn Signal the turn signal lever is moved slightly.
Page 144 Instrument cluster 6. Convenience Items Explanation Rear To activate or deactivate the Rear Occupant Alert. Occupant For more details, refer to "Rear Occupant Alert (ROA) system" in chapter Alert • On door unlock : The outside rearview mirrors are unfolded and the welcome light turns on automatically when the doors are unlocked.
Page 145 7. Units Items Explanation Speed Unit To select the speed unit. (km/h, MPH) Temperature To select the temperature unit. (°C,°F) Unit Fuel Economy To select the fuel economy unit. (km/L, L/100km, MPG) Unit Tire Pressure To select the tire pressure unit. (psi, kPa, bar) Unit 4-43...
Page 146: Trip Computer (Type A)
Instrument cluster Trip computer (Type A) The trip computer is a microcomputer- controlled driver information system that displays information related to driving. Information Some driving information stored in the trip computer (for example Average Vehicle Speed) resets if the battery is disconnected.
Page 147   Type A Type A   Type B Type B   Type A Type A   Type B Type B         OTM040063L OTM040063L OTM040064L OTM040064L OTM040067L OTM040067L OTM040068L OTM040068L Drive info Accumulated info Trip distance (1), average fuel economy...
Page 148: Trip Computer (Type B)
Instrument cluster Trip computer (Type B) The trip computer is a microcomputer- controlled driver information system that displays information related to driving. Information Some driving information stored in the trip computer (for example Average Vehicle Speed) resets if the battery is disconnected.
Page 149   Type A Type A   Type B Type B     OOSH049025L OOSH049025L OJX1049011L OJX1049011L OTM040061L OTM040061L To change the trip mode, toggle the Drive info " " switch on the steering wheel Trip distance (1), average fuel economy •...
Page 150 Instrument cluster   Type A Type A   Type B Type B     OJX1049012L OJX1049012L OJX1049067L OJX1049067L OTM040045 OTM040045 Accumulated info Digital speedometer Accumulated trip distance (1), average Digital speedometer display shows the fuel economy (2), and total driving time speed of the vehicle.
Page 151: Convenient Features
5. Convenient features Accessing your vehicle ..................5-5 Remote key ........................5-5 Smart key ........................5-8 Immobilizer system ....................5-13 Door locks......................5-14 Operating door locks from outside the vehicle ............5-14 Operating door locks from inside the vehicle ............5-16 Deadlocks ........................5-17 Auto door lock/unlock features..................5-17 Child-protector rear door locks .................
Page 152 Lighting ......................5-46 Exterior Light ......................5-46 Welcome system ......................5-51 Interior Light ......................5-51 High Beam Assist (HBA) ................5-55 Function setting ......................5-55 Operating condition ....................5-55 System malfunction and limitations .................5-55 Wipers and washers ..................5-58 Windshield wipers ......................5-59 Windshield washers ....................
Page 153 5. Convenient features Interior features ....................5-89 Cup holder ......................... 5-89 Sunvisor ........................5-90 Power outlet ......................5-90 Wireless cellular phone charging system ..............5-91 Clock ...........................5-93 Clothes hanger ......................5-93 Floor mat anchor(s) ....................5-94 Luggage net (holder) ....................5-95 Cargo area cover .......................5-95 Exterior features ....................5-96 Roof rack ........................
Page 154 Bluetooth ......................5-117 Connecting Bluetooth devices ................. 5-117 Using a Bluetooth audio device ................5-120 Using a Bluetooth phone ..................5-121 Setup .......................5-126 Display ........................5-126 Sound ........................5-126 Date/Time ........................5-127 Bluetooth ........................5-127 System ........................5-127 Pan-European eCall ..................5-128 System status icons ..................5-129 Infotainment system specifications .............5-130 USB ..........................
Page 155: Accessing Your Vehicle
To unlock: OPDE046001 OPDE046001 1. Press the Door Unlock button (2) on Your HYUNDAI uses a remote key, which the remote key. you can use to lock or unlock a door (and 2. The doors will unlock. The hazard tailgate) and even start the engine.
Page 156 Convenient features Mechanical key Information   Type A Type A   Type B Type B     The word “HOLD” is written on the button to inform you that you must press and hold the button for more than one second.
Page 157 If you have a problem with the remote key, it is recommended that you contact an authorized HYUNDAI dealer. If the remote key is in close proximity to your mobile phone, the signal could be blocked by your mobile phone’s normal operational signals.
Page 158: Smart Key
3. Remove the old battery and insert a OOS050026L OOS050026L new battery. Make sure the battery Your HYUNDAI uses a Smart Key, which position is correct. you can use to lock or unlock a door (and 4. Reinstall the battery cover and key tailgate) and even start the engine.
Page 159 Locking Even though you press the outside door handle button, the doors will not lock and the chime will sound for three seconds if any of the following occur: • The Smart Key is in the vehicle. • The Engine Start/Stop button is in ACC or ON position.
Page 160 Convenient features NOTICE Information To prevent damaging the smart key: • The door handle button will only • Keep the smart key away from water operate when the smart key is within or any liquid and fire. If the inside 0.7~1 m (28~40 in.) from the outside of the smart key gets damp (due to door handle.
Page 161 HYUNDAI dealer or tow the vehicle, if necessary. Smart key precautions The smart key may not work if any of the following occur: •...
Page 162 If you suspect your smart key might have sustained some damage, or you feel your smart key is not working correctly, it is recommended that you contact an authorized HYUNDAI dealer. Information An inappropriately disposed battery can be harmful to the environment and human health.
Page 163: Immobilizer System
If the system repeatedly does not recognize the coding of the key, it is recommended that you contact your HYUNDAI dealer. Do not attempt to alter this system or add other devices to it. Electrical problems could result that may make your vehicle inoperable.
Page 164: Door Locks
Convenient features DOOR LOCKS Operating door locks from Remote key outside the vehicle Mechanical key   Remote key Remote key   Smart key Smart key     OPDE046413 OPDE046413 To lock the doors, press the Door Lock button (1) on the remote key.
Page 165 Smart key Information • In cold and wet climates, door lock and door mechanisms may not work properly due to freezing conditions. • If the door is locked/unlocked multiple times in rapid succession with either the vehicle key or door lock switch, the system may stop operating temporarily in order to protect the circuit and prevent damage to system components.
Page 166: Operating Door Locks From Inside The Vehicle
Convenient features Operating door locks from inside With the central door lock/unlock switch the vehicle With the door lock button OOS047004 OOS047004 When pressing the ( ) portion (2) on the OOS047003 OOS047003 switch, all vehicle doors will lock. • To unlock a door, push the door lock •...
Page 167: Deadlocks
Deadlocks (if equipped) WARNING Some vehicles are equipped with a Do not leave children or animals deadlock system. Deadlocks prevent unattended in your vehicle. An enclosed opening of a door from either inside or vehicle can become extremely hot, outside the vehicle once the deadlocks causing death or serious injury to have been activated providing an unattended children or animals who...
Page 168: Child-Protector Rear Door Locks
Convenient features Child-protector rear door locks Rear Occupant Alert (ROA) (if equipped) This function prevents the driver from leaving a passenger in the rear seats. If your vehicle is equipped with additional navigation, please refer to the infotainment system manual separately supplied.
Page 169: Theft-Alarm System
THEFT-ALARM SYSTEM This system helps to protect your vehicle Information and valuables. The horn will sound and • Do not lock the doors until all the hazard warning lights will blink passengers have left the vehicle. If the continuously if any of the following remaining passenger leaves the vehicle occur: when the system is armed, the alarm...
Page 170: Steering Wheel
• When you operate the steering wheel recommend to contact an authorized in low temperatures, abnormal noise HYUNDAI dealer to have the system may occur. If the temperature rises, the checked as soon as possible. noise will disappear. This is a normal •...
Page 171: Tilt Steering / Telescopic Steering
Tilt steering / Telescopic steering WARNING Never adjust the steering wheel while driving. You may lose steering control and cause severe personal injury, death or accidents. Information OOS047006 OOS047006 After adjustment, sometimes the lock- Pull down the lock-release lever (1) on release lever may not lock the steering the steering wheel column and adjust wheel.
Page 172: Heated Steering Wheel
Convenient features Heated steering wheel Horn (if equipped) OOS047008 OOS047008 To sound the horn, press the area OOS050003K OOS050003K indicated by the horn symbol on your When the ignition switch is in the ON steering wheel. The horn will operate position or when the engine is running, only when this area is pressed.
Page 173: Mirrors
MIRRORS Inside rearview mirror Day/night rearview mirror (if equipped) Before you start driving, adjust the rearview mirror to the center on the view through the rear window. WARNING Make sure your line of sight is not obstructed. Do not place objects in the rear seat, cargo area, or behind the rear headrests which could interfere with your vision through the rear window.
Page 174 Convenient features Electric Chromic Mirror (ECM) (if equipped) The electric rearview mirror automatically controls the glare from the headlamp of the vehicle behind you in nighttime or low light driving conditions. When the engine is running, the glare is automatically controlled by the sensor mounted in the rearview mirror.
Page 175: Outside Rearview Mirror
Outside rearview mirror WARNING Do not adjust or fold the outside rearview mirrors while driving. This may cause loss of vehicle control resulting in an accident. NOTICE • Do not scrape ice off the mirror face; this may damage the surface of the glass.
Page 176 Convenient features Adjusting the rearview mirrors Folding the outside rearview mirror OOS047013 OOS047013 OOS047014 OOS047014 1. Press either the L (left side) or R (right Manual type side) button (1) to select the rearview To fold the outside rearview mirror, grasp mirror you would like to adjust.
Page 177 • With smart key system - The mirror will fold or unfold when the door is locked or unlocked by the smart key and “Welcome mirror” in the User Setting Mode on the LCD display is activated. - The mirror will fold or unfold when the door is locked or unlocked by the button on the outside door handle and “Welcome mirror”...
Page 178: Windows
Convenient features WINDOWS Power windows (if equipped) OOS047017 OOS047017 (1) Driver’s door power window switch (5) Window opening and closing (2) Front passenger’s door power (6) Automatic power window window switch (7) Power window lock switch* (3) Rear door (left) power window switch* * : if equipped (4) Rear door (right) power window...
Page 179 The ignition switch must be in the Window opening and closing ON position to be able to raise or lower the windows. Each door has a Power Window switch to control that door’s window. The driver has a Power Window Lock switch which can block the operation of passenger windows.
Page 180 OLF044032 OLF044032 checked by an authorized HYUNDAI If a window senses any obstacle while it dealer. is closing automatically, it will stop and lower approximately 30 cm (12 inches) to WARNING allow the object to be cleared.
Page 181 NOTICE WARNING Do not install any accessories on the Do not allow children to play with the windows. The automatic reverse power windows. Keep the driver’s feature may not operate. door power window lock switch in the LOCK position. Serious injury or death Power window lock switch can result from unintentional window operation by a child.
Page 182: Sunroof
Convenient features SUNROOF (IF EQUIPPED) If your vehicle is equipped with a WARNING sunroof, you can slide or tilt your sunroof • Never adjust the sunroof or sunshade with the sunroof control switch located while driving. This could result in on the overhead console.
Page 183: Sunroof Opening And Closing
Sunroof opening and closing Sliding the sunroof Pressing the sunroof control lever backward or forward momentarily to the second detent position completely opens or closes the sunroof even when the switch is released. To stop the sunroof at the desired position while the sunroof is in operation, press the sunroof control lever backward or forward and release the switch.
Page 184: Tilting The Sunroof
Convenient features Automatic reverse (if equipped) Tilting the sunroof OOSH049042L OOSH049042L OOS047023 OOS047023 If the sunroof senses any obstacle while Tilt the sunroof open: it is closing automatically, it will reverse Push the sunroof control lever upward direction then stop to allow the object to until the sunroof moves to the desired be cleared.
Page 185: Sunshade
Sunshade Resetting the sunroof The sunroof may need to be reset if the following conditions occur: - The battery is discharged or disconnected or the sunroof fuse has been replaced or disconnected - The sunroof control lever is not operating correctly To reset the sunroof, perform the following steps: 1.
Page 186: Sunroof Open Warning
• For more detailed information, we not fully closed, the open sunroof recommend that you contact an warning will appear on the LCD authorized HYUNDAI dealer. display until the door is closed or the sunroof is fully closed. Close the sunroof securely when leaving your vehicle.
Page 187: Exterior Features
EXTERIOR FEATURES Hood Opening the hood OOS047026 OOS047026 5. Hold the hood open with the support rod (1). OOS040024 OOS040024 1. Park the vehicle and set the parking WARNING brake. 2. Pull the release lever to unlatch the • Grasp the support rod in the area hood.
Page 188 Convenient features Closing the hood WARNING 1. Before closing the hood, check the • Before closing the hood, ensure following: all obstructions are removed from • All filler caps in engine around the hood opening. compartment must be correctly • Always double check to be sure that installed.
Page 189: Tailgate
Tailgate Closing the tailgate Opening the tailgate OOS050007K OOS050007K Lower the tailgate lid and press down OOS050006K OOS050006K until it locks. To be sure the tailgate lid is Make sure the vehicle is in P (Park) and securely fastened, always check by trying set the parking brake.
Page 190 Convenient features Emergency tailgate safety release WARNING OOS050008K OOS050008K OOS047085 OOS047085 Your vehicle is equipped with the Do not hold the part (gas lifter) that emergency tailgate safety release lever supports the tailgate. Be aware that located on the bottom of the tailgate. the deformation of the part may cause When someone is inadvertently locked in vehicle damage and a risk of injury.
Page 191: Fuel Filler Door
Fuel filler door   Gasoline engine Gasoline engine   Opening the fuel filler door OOS047031 OOS047031   Diesel engine Diesel engine   OOS047086 OOS047086 The fuel filler door must be opened from inside the vehicle by pulling up on the fuel-filler door opener.
Page 192 Convenient features Closing the fuel filler door • Do not get back into a vehicle once you have begun refueling. You 1. To install the fuel tank cap, turn it can generate a build-up of static clockwise until it “clicks” one time. electricity by touching, rubbing 2.
Page 193 • If the fuel filler cap requires immediately contact the manager replacement, use only a genuine of the gas station and then contact HYUNDAI cap or the equivalent the local fire department. Follow any specified for your vehicle. An safety instructions they provide.
Page 194: Head Up Display (Hud)
Convenient features HEAD UP DISPLAY (HUD) (IF EQUIPPED) WARNING • Do not attach any stickers or accessories on the HUD or crash pad. • Do not adjust HUD shutter and combiner directly by hands. • The image may be invisible due to finger prints.
Page 195: Head Up Display On/Off
Head Up Display ON/OFF 5. SCC headway information (if equipped) 6. Lane Following Assist information (if equipped) 7. Lane Safety information (if equipped) 8. Blind-Spot Safety information (if equipped) 9. Highway Driving Assist information (if equipped) 10. Highway Auto Speed Change information (if equipped) OOS040080 OOS040080...
Page 196: Lighting
Convenient features LIGHTING Exterior lights Lighting control OOS04750L OOS04750L AUTO light position (if equipped) OPDE046065 OPDE046065 To operate the lights, turn the knob at When the light switch is in the AUTO the end of the control lever to one of the position, the position lamp and following positions: headlamp will be turned ON or OFF...
Page 197 High beam operation OAE046469L OAE046469L Position lamp position ( OAE046453L OAE046453L The position lamp, license plate lamp To turn on the high beam headlamp, and instrument panel lamp are turned push the lever away from you. The lever will return to its original position. The high beam indicator will light when the headlamp high beams are switched To turn off the high beam headlamp, pull...
Page 198 Convenient features Turn signals and lane change signals Front fog lamps (if equipped) OPDE046066 OPDE046066 OTLE045284 OTLE045284 Fog lamps are used to provide improved To signal a turn, push down on the lever visibility when visibility is poor due to for a left turn or up for a right turn in fog, rain or snow, etc.
Page 199 Rear fog lamp OTLE045285 OTLE045285 Vehicle without front fog lamps OPDE046064 OPDE046064 To turn on the rear fog lamp: Vehicle with front fog lamps Position the light switch in the headlamp To turn on the rear fog lamp: position, and then turn the light switch Position the light switch in the position (1) to the rear fog lamp position.
Page 200 Convenient features Headlamp delay function Daytime running light (DRL) (if equipped) (if equipped) If you place the ignition switch to the The Daytime Running Lights (DRL) can ACC or OFF position with the headlamps make it easier for others to see the front ON, the headlamps (and/or position of your vehicle during the day, especially lamps) remain on for about 5 minutes.
Page 201: Welcome System
It also adjusts to the appropriate headlamp beam level for various situations. WARNING If the function does not work properly, we recommend that the system be inspected by an authorized HYUNDAI dealer. Do not attempt to inspect or replace the wiring yourself. 5-51...
Page 202: Interior Light
Convenient features Interior lights Front lamps   Type A (Without sunglass case) Type A (Without sunglass case)   NOTICE Do not use the interior lights when driving in the dark. The interior lights may obscure your view and cause an accident.
Page 203 Rear lamps Front room lamp • (3) :   Type A Type A   Press the button to turn ON the room lamp for the front/rear seats. • (4) : Press the button to turn OFF the room lamp for the front/rear seats.
Page 204 Convenient features Luggage compartment lamp Vanity mirror lamp (if equipped) OOS050009K OOS050009K OCN7050058 OCN7050058 The luggage compartment lamp comes Push the switch to turn the light on or off. on when the tailgate is opened. • : The lamp will turn on if this button is pressed.
Page 205: High Beam Assist (Hba)
HIGH BEAM ASSIST (HBA) (IF EQUIPPED) Function setting The driver can activate HBA by placing the ignition switch to the ON position and by selecting: ‘User Settings → Lights → HBA (High Beam Assist)’. If you disable this setting, HBA will not work. The setting of HBA will be maintained, as selected, when the engine is re-started.
Page 206: System Malfunction And Limitations
After the message (19 mph). disappears, the master warning light ( ) will illuminate. We recommend that you take your vehicle to an authorized HYUNDAI dealer and have the system checked. CAUTION The function may not operate normally in the following conditions.
Page 207 HYUNDAI • When a vehicle suddenly appears dealer and have the function from around a corner. checked.
Page 208: Wipers And Washers
Convenient features WIPERS AND WASHERS   Front windshield wiper/washer Front windshield wiper/washer   Rear windshield wiper/washer Rear windshield wiper/washer     • • Type A Type A • • Type A Type A     OTLE045159 OTLE045159 OTLE045507...
Page 209: Windshield Wipers
Windshield wipers AUTO (Automatic) control (if equipped) Operates as follows when the ignition switch is in the ON position. /MIST : For a single wiping cycle, move the lever down ( or up (MIST) and release it. The wipers will operate continuously if the lever is held in this position.
Page 210: Windshield Washers
Convenient features NOTICE Windshield washers • When washing the vehicle, set the   Type A Type A   wiper switch in the O (OFF) position to stop the auto wiper operation. The the switch is set in the AUTO mode while washing the vehicle.
Page 211: Rear Window Wiper And Washer Switch
Rear window wiper and washer WARNING switch (if equipped) When the outside temperature is below freezing, ALWAYS warm the windshield   Type A Type A   using the defroster to prevent the washer fluid from freezing on the windshield and obscuring your vision which could result in an accident and serious injury or death.
Page 212 Convenient features Auto rear wiper (if equipped)   Type A Type A   The rear wiper will operate while the vehicle is in reverse with the front wipers ON by selecting the function on the LCD display. Go to ‘User Settings  Convenience  Auto Rear Wiper (reverse)’.
Page 213: Manual Climate Control System
MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) OOS050100K OOS050100K 1. Fan speed control knob 5. A/C (Air conditioning) button* 2. Temperature control knob 6. Air intake control button 3. Mode selection knob 7. Rear window defroster button 4. Front windshield defroster position * : if equipped 5-63...
Page 214: Heating And Air Conditioning
Convenient features Heating and air conditioning 3. Set the temperature control to the desired position. 1. Start the engine. 4. Set the air intake control to Fresh 2. Set the mode to the desired position. mode. To improve the effectiveness of 5.
Page 215 Face-Level (B, D) Air flow is directed toward the upper body and face. Additionally, each outlet can be controlled to direct the air discharged from the outlet. Bi-Level (B, C, D, E) Air flow is directed towards the face and OOS047305 OOS047305 the floor.
Page 216 Convenient features Temperature control (2) Information The temperature will increase by turning Using the system in the fresh air position is the knob to the right. The temperature recommended. will decrease by turning the knob to the Prolonged operation of the heater in the left.
Page 217: System Operation
Fan speed control (1) System operation Ventilation Turn the knob to the right to increase the fan speed and airflow. Turn the knob 1. Set the mode to the position. to the left to decrease fan speed and 2. Set the air intake control to the airflow.
Page 218 • The refrigerant system should be serviced in a well-ventilated place. Air conditioning • The air conditioning evaporator HYUNDAI Air Conditioning Systems are (cooling coil) shall never be repaired filled with R-134a or R-1234yf refrigerant. or replaced with one removed from 1.
Page 219: System Maintenance
HYUNDAI dealer according to the fog up, causing loss of visibility. In this maintenance schedule. If the vehicle is case, set the mode selection knob to...
Page 220 Therefore, if abnormal operation is All refrigerants should be reclaimed found, we recommend that the system with proper equipment. be inspected by an authorized HYUNDAI Venting refrigerants directly to the dealer. atmosphere is harmful to individuals and environment. Failure to heed these NOTICE warnings can lead to serious injuries.
Page 221   Example Example   • • Type A Type A   OOS050010K OOS050010K OHYK059004 OHYK059004 • • Type B Type B Air Conditioning refrigerant label   You can find out which air conditioning refrigerant is applied to your vehicle on the label located inside of the hood.
Page 222: Automatic Climate Control System
Convenient features AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) OOS050103L OOS050103L 1. Temperature control knob 6. Front windshield defroster button 2. Fan speed control knob 7. Mode selection button 3. AUTO (automatic control) button 8. Rear window defroster button 4. Air conditioning button 9.
Page 223: Automatic Heating And Air Conditioning
Automatic heating and air conditioning The Automatic Climate Control System is controlled by setting the desired temperature. 1. Press the AUTO button. (3) The modes, fan speeds, air intake and air-conditioning will be controlled automatically by the temperature setting you select. OOSH059075L OOSH059075L 2.
Page 224 Convenient features Mode selection OOS050101L OOS050101L The mode selection button controls the direction of the air flow through the ventilation system. 5-74...
Page 225 Defrost-Level (A, D) Most of the air flow is directed to the windshield. Face-Level (B, D) Air flow is directed toward the upper body and face. Additionally, each outlet can be controlled to direct the air OOS050120L OOS050120L discharged from the outlet. Instrument panel vents The outlet vents can be opened or closed ( ) separately using the thumbwheel.
Page 226 Convenient features Recirculated air position WARNING With the recirculated air • Continued climate control system position selected, air from the operation in the recirculated air passenger compartment will position may allow humidity to be drawn through the heating increase inside the vehicle which system and heated or cooled may fog the glass and obscure according to the function...
Page 227: System Operation
System operation Air conditioning Ventilation HYUNDAI Air Conditioning Systems are filled with R-134a or R-1234yf refrigerant. 1. Set the mode to the position. 1. Start the engine. Push the air 2. Set the air intake control to the conditioning button.
Page 228 Convenient features NOTICE Air conditioning system operation tips • If the vehicle has been parked in • When using the air conditioning direct sunlight during hot weather, system, monitor the temperature open the windows for a short time gauge closely while driving up to let the hot air inside the vehicle hills or in heavy traffic when escape.
Page 229: System Maintenance
Overfilling also reduces the performance of the air conditioning system. Therefore, if abnormal operation is found, we recommend that the system be inspected by an authorized HYUNDAI dealer. NOTICE OIK047401L OIK047401L [A] : Outside air, [B] : Recirculated air...
Page 230 Convenient features   Example Example   WARNING • • Type A Type A   Vehicles equipped with R-1234yf Since the refrigerant is mildly flammable and operated at high pressure, the air conditioning system should only be serviced by trained and certified technicians.
Page 231: Windshield Defrosting And Defogging
WINDSHIELD DEFROSTING AND DEFOGGING Manual climate control system WARNING To defog inside windshield Windshield heating Do not use the position during cooling operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield could cause the outer surface of the windshield to fog up, causing loss of visibility.
Page 232: Automatic Climate Control System
Convenient features To defrost outside windshield Automatic climate control system To defog inside windshield OOS050111K OOS050111K 1. Set the fan speed to the highest (extreme right) position. OOS050112K OOS050112K 2. Set the temperature to the extreme 1. Select the desired fan speed. hot position.
Page 233: Auto Defogging System (Only For Automatic Climate Control System)
To defrost outside windshield Auto defogging system (only for automatic climate control system, if equipped) Auto defogging reduces the possibility of fogging up the inside of the windshield by automatically sensing the moisture on inside the windshield. The auto defogging system operates when the heater or air conditioning is on.
Page 234: Defroster
Convenient features Defroster • To activate the rear window defroster, press the rear window defroster button located in the center facia NOTICE switch panel. The indicator on the rear window defroster button illuminates To prevent damage to the conductors when the defroster is ON. bonded to the inside surface of the rear window, never use sharp instruments or •...
Page 235: Climate Control Additional Features
CLIMATE CONTROL ADDITIONAL FEATURES Cluster ionizer (if equipped) Sunroof inside air recirculation (if equipped) When the ignition switch is in the ON position, the clean air function turns on When the sunroof is opened, outside automatically. (fresh) air will be automatically selected. At this time, if you press the air intake Also, the clean air function turns off control button, recirculated air position...
Page 236: Storage Compartment
Convenient features STORAGE COMPARTMENT Center console storage WARNING Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot temperatures for extended periods. WARNING ALWAYS keep the storage compartment covers closed securely while driving.
Page 237: Sunglass Holder
Sunglass holder (if equipped) Multi box OOS047058 OOS047058 OOS050011K OOS050011K To open : Small things may be placed in the multi box. Press the cover and the holder will slowly open. Place your sunglasses in the compartment door with the lenses facing out.
Page 238: Luggage Tray
Convenient features Luggage tray (if equipped) To increase luggage space OOS047320 OOS047320 OOS047070 OOS047070 You can place a first aid kit, a reflector triangle (front tray), tools, etc. in the box for easy access. • Grasp the handle on the top of the cover and lift it.
Page 239: Interior Features
INTERIOR FEATURES Cup holder WARNING Front • Avoid abrupt starting and braking when the cup holder is in use to prevent spilling your drink. If hot liquid spills, you could be burned. Such a burn to the driver could cause loss of vehicle control resulting in an accident.
Page 240: Sunvisor
Convenient features Sunvisor Power outlet (if equipped) OOS047062 OOS047062 OOS050027L OOS050027L To use a sunvisor, pull it downward. The power outlet is designed to provide power for mobile telephones or other To use a sunvisor for a side window, pull devices designed to operate with vehicle it downward, unsnap it from the bracket electrical systems.
Page 241: Wireless Cellular Phone Charging System
NOTICE Wireless cellular phone charging system (if equipped) To prevent damage to the Power Outlets : • Use the power outlet only when the engine is running and remove the accessory plug after use. Using the accessory plug for prolonged periods of time with the engine off could cause the battery to discharge.
Page 242 Convenient features If your cellular phone is not charging: • The wireless charging process may temporarily stop, when temperature - Slightly change the position of the abnormally increases inside the cellular phone on the charging pad. wireless cellular phone charging - Make sure the indicator light is system.
Page 243: Clock
Clock Clothes hanger (if equipped) WARNING Do not adjust the clock while driving. You may lose your steering control and cause severe personal injury or accidents. Vehicles with Audio system Select the [SETUP/CLOCK] button on the audio system  Select [Date/Time]. OOS047065 OOS047065 •...
Page 244: Floor Mat Anchors
To avoid any interference with pedal operation, HYUNDAI recommends that the HYUNDAI floor mat designed for use in your vehicle be installed. 5-94...
Page 245: Luggage Net (Holder)
If necessary, we recommend that you Disconnect the strap (1) from the holder contact your authorized HYUNDAI dealer if you want to return the cover to the to obtain a luggage net. original position. To remove the cargo area cover completely, lift the cover to a 50-degree angle and pull it out (2).
Page 246: Exterior Features
Convenient features EXTERIOR FEATURES Roof rack (if equipped) WARNING • The following specification is the maximum weight that can be loaded onto the roof rack. Distribute the load as evenly as possible onto the roof rack and secure the load firmly. ROOF 80 kg (176 lbs.) RACK...
Page 247: Infotainment System
INFOTAINMENT SYSTEM Antenna Information Roof antenna • If you install an aftermarket HID headlamp, your vehicle’s audio and electronic devices may malfunction. • Prevent chemicals such as perfume, cosmetic oil, sun cream, hand cleaner, and air freshener from contacting the interior parts because they may cause damage or discoloration.
Page 248: Steering Wheel Audio Controls
Convenient features Steering wheel audio controls SEEK/PRESET ( ) (2) (if equipped) If the SEEK/PRESET toggle switch is moved up or down and held for 0.8   Type A Type A   seconds or more, it will function in the following modes.
Page 249: Bluetooth ® Wireless Technology Hands-Free
Bluetooth Wireless Technology Voice recognition ® hands-free OOS050025K OOS050025K OOS050024K OOS050024K You can operate the voice recognition function through voice commands. For detailed information, refer to the separately supplied infotainment system manual. Audio / Video / Navigation system (AVN) (if equipped) Detailed information for the AVN system is described in a separately supplied OOS047076...
Page 250: How Vehicle Radio Works
Convenient features How vehicle radio works AM (MW, LW) reception FM reception OJF045309L OJF045309L AM broadcasts can be received at OJF045308L OJF045308L AM and FM radio signals are broadcast greater distances than FM broadcasts. from transmitter towers located around This is because AM radio waves are your city.
Page 251 The following conditions are normal and do not indicate radio trouble : OJF045311L OJF045311L • Station Swapping - As a FM signal weakens, another more powerful JBM004 JBM004 signal near the same frequency may • Fading - As your vehicle moves away begin to play.
Page 252 Bluetooth SIG, Inc. and any use of such possible from the audio equipment. marks by HYUNDAI is under license. Other trademarks and trade names are NOTICE those of their respective owners.
Page 253: Audio (Without Touch Screen)
AUDIO (WITHOUT TOUCH SCREEN) System layout – control panel   Type A Type A   Type B Type B     (With Bluetooth® Wireless Technology) (1) SEEK/TRACK button (4) PHONE button • Change the station/track/file. • Press to start connecting a mobile phone via Bluetooth.
Page 254 Convenient features   Type A Type A   Type B Type B     (With Bluetooth® Wireless Technology) (7) PRESET button (11) TUNE knob/FILE knob/ENTER button • While listening to the radio, press to move to previous or next page of the •...
Page 255: System Layout - Steering Wheel Remote Control
System layout – steering wheel (4) Up/Down lever remote control • Change the station/track/file. • While listening to the radio, push to listen to the previous/next saved radio station. • While listening to the radio, push and hold to search for a station. •...
Page 256 Convenient features WARNING WARNING - About driving - About handling the system • Do not operate the system while driving. Driving while distracted may • Do not disassemble or modify the result in a loss of vehicle control, system. Doing so may result in an potentially leading to an accident, accident, fire, or electric shock.
Page 257: Turning The System On Or Off
NOTICE Information Manufacturer: HYUNDAI MOBIS Co., Ltd.203, Teheran-ro, Gangnam-gu, You can turn on the system when the key Seoul, 06141 , KoreaTel: +82-31-260-2707 ignition switch is placed in the “ACC”...
Page 258: Turning The Display On Or Off
Convenient features Turning the display on or off Numberless items Turn the [TUNE] knob to select the To prevent glare, you can turn off the desired item, and then press the knob. screen. The screen can be turned off only while the system is on.
Page 259: Radio
RADIO Turning on the radio FM/AM Mode (With RDS) On the control panel, press the [RADIO] button. FM/AM Mode (1) Current radio mode (2) Radio station information (3) Preset list (1) Current radio mode Press the [MENU] button on the control panel to access the following menu (2) Radio station information options:...
Page 260: Changing The Radio Mode
Convenient features Changing the radio mode DAB/FM Mode (With DAB) Alternatively, press the [RADIO] button on the control panel or the [MODE] button on the steering wheel. Each time you press the button, the radio mode switches. Scanning for available radio stations You can listen to each radio station for a few seconds to test the reception and...
Page 261: Saving Radio Stations
MEDIA PLAYER Saving radio stations Using the media player You can save your favourite radio stations You can play music stored in various and listen to them by selecting them media storage devices, such as USB from the preset list. storage devices, smartphones, and iPods.
Page 262: Using The Usb Mode
Convenient features NOTICE Using the USB mode • When you connect an Apple You can play media files stored in device, playback does not start portable devices, such as USB storage automatically. To start the media devices and MP3 players. Check player in the iPod mode, press the compatible USB storage devices and [MEDIA] button on the control panel.
Page 263 Rewinding/Fast forwarding Playing repeatedly On the control panel, press and hold the On the control panel, press the [1] button. SEEK/TRACK ] button. The repeat play mode changes each time you press it. The corresponding mode • You can also push and hold the Up/ icon will be displayed on the screen.
Page 264: Using The Ipod Mode
Convenient features NOTICE Using the iPod mode • When connecting a USB storage You can listen to music stored on your device, do not use an extension Apple devices, such as an iPod or an cable. Connect it directly to the iPhone.
Page 265 Rewinding/Fast forwarding Playing repeatedly On the control panel, press and hold the On the control panel, press the [1] button. SEEK/TRACK ] button. The repeat play mode changes each time you press it. The corresponding mode • You can also push and hold the Up/ icon will be displayed on the screen.
Page 266 Convenient features Notes on connecting Apple devices Notes on playing Apple devices • Ensure that the iOS and firmware • Depending on the model, your of your device is up-to-date before device may not be recognised due connecting it to your system. to unsupported communication Outdated devices may cause a system protocols.
Page 267: Bluetooth
BLUETOOTH NOTICE Connecting Bluetooth devices • On your system, you can use only Bluetooth is a short-range wireless Bluetooth Handsfree and Audio networking technology. Via Bluetooth, features. Connect a mobile device you can connect nearby mobile devices wirelessly to send and receive that supports both features.
Page 268 Convenient features Pairing devices with your system 4. Choose whether or not to connect the Bluetooth device to your system prior For Bluetooth connections, first pair your to other devices. device with your system to add it to the • If you grant priority to the Bluetooth system’s list of Bluetooth devices.
Page 269 Connecting a paired device Disconnecting a device To use a Bluetooth device on your If you want to stop using a Bluetooth system, connect the paired device to the device or connect another device, system. Your system can connect with disconnect your currently connected only one device at a time.
Page 270: Using A Bluetooth Audio Device
Convenient features Using a Bluetooth audio device Pausing/Resuming playback To pause playback, press the [3] You can listen to music stored in the button on the control panel. To resume connected Bluetooth audio device via playback, press the [3] button again. your vehicle’s speakers.
Page 271: Using A Bluetooth Phone
• If you use the Bluetooth phone WARNING mode while using Bluetooth audio, • Park your vehicle in a safe location playback may not automatically before connecting Bluetooth resume after you end the call devices. Distracted driving can depending on the connected mobile cause a traffic accident and lead to phone.
Page 272 Convenient features Making a call Using the favourites list 1. From the Phone screen, press the [1] If your mobile phone is connected to the button to select Favourites. system, you can make a call by selecting a name from your call history or contacts 2.
Page 273 • Permission is required to download Using your call history your call history from the mobile 1. From the Phone screen, press the [2] phone. When you attempt to button to select Call history. download data, you may need to 2.
Page 274 Convenient features NOTICE Answering calls When a call comes in, a notification pop- • Contacts can be downloaded only up window of the incoming call appears from the currently connected on the system screen. Bluetooth device. • Contacts can be viewed only when the Bluetooth device is connected.
Page 275 NOTICE Using options during a call During a call, you will see the call screen • If the caller information is saved in shown below. Press a button to perform your contacts list, the caller’s name the function you want. and phone number will be displayed.
Page 276: Setup
Convenient features SETUP Display Sound You can change the settings related to You can change the settings related to the system display. sounds, such as location where sound will be concentrated and the output level On the control panel, press the for each range.
Page 277: Date/Time
Date/Time System You can change the date and time that You can change the display language or are shown on the system display. initialise system settings. On the control panel, press the On the control panel, press the [SETUP/CLOCK] [3] buttons to select [SETUP/CLOCK] [5] buttons to select Date/Time.
Page 278 Convenient features PAN-EUROPEAN ECALL (IF EQUIPPED) The Pan-European eCall system is an automatic emergency call service made in event of a traffic accident or other accidents on the roads. Driver or passenger manually can make an emergency call in the single duty dispatch service, by pressing SOS button to call the necessary emergency services.
Page 279: System Status Icons
SYSTEM STATUS ICONS Status icons appear at the top of the Signal strength screen to display the current system Icon Description status. Familiarise yourself with the status icons Signal strength of the mobile that appear when you perform certain phone connected via Bluetooth actions or functions and their meanings.
Page 280: Usb
Convenient features INFOTAINMENT SYSTEM SPECIFICATIONS • Supported characters for folder/ file names (Unicode support): 2,604 Supported audio formats Korean characters, 94 alphanumeric • Audio file specification characters, 4,888 Chinese characters - WAVeform audio format in common use, 986 special characters - MPEG1/2/2.5 Audio Layer3 •...
Page 281: Bluetooth
(recommended) are registered trademarks owned by Bluetooth SIG, Inc. and any use • Maximum device size: 32 GB of such marks by HYUNDAI is under licence. NOTICE • Operation is guaranteed only for a metal cover type USB storage device •...
Page 282: Declaration Of Conformity
Convenient features DECLARATION OF CONFORMITY 5-132...
Page 283: Ncc
According to NCC low-power radio frequency devices technical regulations: Article 12 Without permission, any company, firm or user shall not alter the frequency, increase the power, or change the characteristics and functions of the original design of the certified lower power frequency electric machinery. Article 14 The application of low power frequency electric machineries shall not affect the navigation safety nor interfere a legal communication, if an interference is found, the...
Page 284: Bsmi
Convenient features BSMI 5-134...
Page 285: Ukrsepro
UkrSEPRO Category Item Specification HYUNDAI MOBIS Co., Ltd. Manufacturer 203, Teheran-ro, Gangnam-gu, Seoul, 06141, Korea Frequency range 2400 to 2483.5 MHz Supported Bluetooth specification Supported profile HFP (1.7), A2DP (1.3), AVRCP (1.6), PBAP (1.2) Bluetooth Aerial power 2.5 mW (maximum)
Page 286: Driving Your Vehicle
6. Driving your vehicle Before driving ....................6-4 Before entering the vehicle ..................6-4 Before starting ......................6-4 Ignition switch ....................6-5 Key ignition switch .......................6-5 Engine start/stop button ................... 6-9 Manual transmission operation ................6-15 Manual transmission ..................6-15 Good driving practices ....................6-17 Intelligent manual transmission ..............6-18 Intelligent manual transmission operation .............
Page 287 Idle stop and go (ISG) system ...............6-59 Activating the isg ....................... 6-59 Deactivating the isg ....................6-59 Condition of isg system operation ................6-62 ISG indication ......................6-63 ISG malfunction ......................6-65 The battery sensor deactivation ................6-66 Start stop coasting (SSC) (for 48V MHEV) ........... 6-67 SSC operating conditions ..................6-67 Engine restarting conditions ..................6-67 Drive mode integrated control system ............6-68...
Page 288 If you hear a change in the sound of the exhaust or if you drive over something that strikes the underneath side of the vehicle, we recommend that the exhaust system be checked as soon as possible by an authorized HYUNDAI dealer.
Page 289: Before Driving
Driving your vehicle BEFORE DRIVING Before entering the vehicle WARNING • Be sure all windows, outside mirror(s), To reduce the risk of SERIOUS INJURY or and outside lights are clean and DEATH, take the following precautions: unobstructed. • ALWAYS wear your seat belt. All •...
Page 290: Ignition Switch
IGNITION SWITCH WARNING WARNING To reduce the risk of SERIOUS INJURY or • NEVER turn the ignition switch to DEATH, take the following precautions: the LOCK or ACC position while the vehicle is in motion except in an • NEVER allow children or any person emergency.
Page 291 Driving your vehicle Key ignition switch positions Switch Position Action Notes To turn the ignition switch to the LOCK position, push the key in at the ACC position and turn the key towards the LOCK position. The ignition key can be removed in LOCK the LOCK position.
Page 292 Starting the engine Vehicle with dual clutch transmission / intelligent variable transmission: 1. Make sure the parking brake is WARNING applied. • Always wear appropriate shoes when 2. Make sure the shift lever is in P (Park). operating your vehicle. Unsuitable 3.
Page 293 Driving your vehicle Starting the diesel engine Starting and stopping the engine for turbocharger intercooler To start the diesel engine when the 1. Do not race or accelerate the engine engine is cold, it has to be pre-heated and then it has to be warmed up, before immediately after starting the engine.
Page 294 Engine Start/Stop button WARNING (if equipped) • NEVER press the Engine Start/ Stop button while the vehicle is in motion except in an emergency. This will result in the engine turning off and loss of power assist for the steering and brake systems.
Page 295 Driving your vehicle Engine Stop/Start button positions - Vehicle with Manual Transmission/Intelligent Manual Transmission (iMT) Button Position Action Notes To turn off the engine, stop If the steering wheel is not locked the vehicle and then press the properly when you open the driver’s Engine Start/Stop button.
Page 296 Engine Stop/Start button positions - Vehicle with Dual Clutch Transmission/Intelligent Variable Transmission (iVT) Button Position Action Notes To turn off the engine, press If the steering wheel is not locked the Engine Start/Stop button properly when you open the driver’s with shift lever in P (Park).
Page 297 Driving your vehicle Starting the engine Starting the gasoline engine Vehicle with manual transmission: 1. Always carry the smart key with you. WARNING 2. Make sure the parking brake is • Always wear appropriate shoes when applied. operating your vehicle. Unsuitable 3.
Page 298 Starting the diesel engine Information To start the diesel engine when the If the Engine Start/Stop button is pressed engine is cold, it has to be pre-heated while the engine is pre-heating, the engine and then it has to be warmed up, before may start.
Page 299 Driving your vehicle NOTICE To prevent damage to the vehicle: • If the engine stalls while you are in motion, do not attempt to move the shift lever to the P (Park) position. If traffic and road conditions permit, you may put the shift lever in the N (Neutral) position while the vehicle is still moving and press the Engine Start/Stop button in an attempt to...
Page 300: Manual Transmission Operation
MANUAL TRANSMISSION (IF EQUIPPED) Manual transmission operation To shift to R (Reverse), make sure the vehicle has completely stopped, and then move the shift lever to neutral before moving into R (Reverse). When you’ve come to a complete stop and it’s hard to shift into 1st gear or R (Reverse): 1.
Page 301 Driving your vehicle NOTICE Downshifting Down shift to a lower gear when slowing To prevent unnecessary wear or down in heavy traffic or driving up a damage to the clutch: steep hill to prevent high engine loads. • Do not rest your foot on the clutch Also, downshifting reduces the chance pedal while driving.
Page 302: Good Driving Practices
• In the event your vehicle leaves in an accident. the roadway, do not steer sharply. Instead, slow down before pulling back into the travel lanes. • HYUNDAI recommends you follow all posted speed limits. 6-17...
Page 303: Intelligent Manual Transmission
Driving your vehicle INTELLIGENT MANUAL TRANSMISSION (IF EQUIPPED) Intelligent Manual Transmission (iMT) The shift lever must be returned to the system use E-Clutch (Electronic Clutch) neutral position before shifting into technology. Using the E-Clutch, the R (Reverse). Push the button located vehicle can cut engine drive off without immediately below the shift knob pressing the clutch pedal by driver.
Page 304 CAUTION WARNING • When downshifting from fifth gear • Before leaving the driver's seat, to fourth gear, caution should be always set the parking brake fully taken not to inadvertently press the and shut the engine off. Then make shift lever sideways in such a manner sure the transmission is shifted into that the second gear is engaged.
Page 305 Driving your vehicle Downshifting WARNING When you must slow down in heavy • Always buckle-up! In a collision, an traffic or while driving up steep hills, unbelted occupant is significantly downshift before the engine starts to more likely to be seriously injured labor.
Page 306: Intelligent Variable Transmission Operation
INTELLIGENT VARIABLE TRANSMISSION (IF EQUIPPED) OOS057004 OOS057004 Depress the brake pedal, press the shift button ahead of the shift lever, and then move shift lever. Press the shift button, then move shift lever. Move shift lever. Intelligent variable transmission operation The Intelligent variable transmission has no actual fixed gears.
Page 307 Driving your vehicle R (Reverse) WARNING Use this position to drive the vehicle To reduce the risk of serious injury or backward. death: • ALWAYS check the surrounding NOTICE areas near your vehicle for people, especially children, before shifting a Always come to a complete stop before vehicle into D (Drive) or R (Reverse).
Page 308 Manual shift mode Shift-lock system For your safety, the intelligent variable transmission (IVT) has a shif-tlock system which prevents shifting the transmission from P (Park) into R (Reverse) unless the + (UP) + (UP) brake pedal is depressed. To shift the transmission from P (Park) into R (Reverse): 1.
Page 309: Parking
If you need to use the shift-lock release, Good driving practices we recommend that the system be • Never move the shift lever from P inspected by an authorized HYUNDAI (Park) or N (Neutral) to any other dealer immediately. position with the accelerator pedal depressed.
Page 310 • In the event your vehicle leaves the roadway, do not steer sharply. Instead, slow down before pulling back into the travel lanes. • HYUNDAI recommends you follow all posted speed limits. 6-25...
Page 311: Dual Clutch Transmission Operation
Driving your vehicle DUAL CLUTCH TRANSMISSION (IF EQUIPPED) OOS057004 OOS057004 Depress the brake pedal and press the shift button ahead of the shift lever while moving the shift lever. Press the shift button while moving the shift lever. The shift lever can freely operate. Dual clutch transmission operation The dual clutch transmission has seven forward speeds and one reverse speed.
Page 312 • The dual clutch transmission • When you turn the engine on and off, incorporates a dry-type dual clutch you may hear clicking sounds as the mechanism, which allows for better system goes through a self-test. This acceleration performance and is a normal sound for the dual clutch increased fuel efficiency while driving.
Page 313 (D, is not applied. P) on the instrument cluster will blink. We recommend that you contact an authorized HYUNDAI dealer and have the system checked. OTLE055019 OTLE055019 Steep grade Driving up hills or on steep grades: •...
Page 314 Jerkiness. To return to the normal safety, we recommend that you contact driving condition, stop the vehicle an authorized HYUNDAI dealer and have and apply the foot brake or shift into P the system checked. (Park). Then allow the transmission to cool for a few minutes with engine on, before driving off.
Page 315 Driving your vehicle Transmission ranges N (Neutral) The wheels and transmission are not The indicator in the instrument cluster engaged. displays the shift lever position when the ignition switch is in the ON position. Use N (Neutral) if you need to restart a stalled engine, or if it is necessary to stop P (P ark) with the engine ON.
Page 316 Up (+) : Push the lever forward once to Paddle shifter (if equipped) shift up one gear. Down (-) : Pull the lever backwards once to shift down one gear. Information • Only the seven forward gears can be selected in Manual Shift Mode. To reverse or park the vehicle, move the shift lever to the R (Reverse) or P (Park) position as required.
Page 317 6. Remove the tool from the shift-lock release access hole then install the cap. 7. Depress the brake pedal, and then restart the engine. If you need to use the shift-lock release, we recommend that the system be inspected by an authorized HYUNDAI dealer immediately. 6-32...
Page 318: Parking
Parking Good driving practices Always come to a complete stop and • Never move the shift lever from P continue to depress the brake pedal. (Park) or N (Neutral) to any other Move the shift lever into the P (Park) position with the accelerator pedal position, apply the parking brake, and depressed.
Page 319 • In the event your vehicle leaves the roadway, do not steer sharply. Instead, slow down before pulling back into the travel lanes. • HYUNDAI recommends you follow all posted speed limits. Information - Kickdown Mechanism (if equipped) Use the kickdown mechanism for maximum acceleration.
Page 320: Braking System
BRAKING SYSTEM Power brakes • Wet brakes may impair the vehicle’s ability to safely slow down; the Your vehicle has power-assisted brakes vehicle may also pull to one side that adjust automatically through normal when the brakes are applied. usage. Applying the brakes lightly will If the engine is not running or is turned indicate whether they have been...
Page 321: Parking Brake
Parking brake (if equipped) If the parking brake does not release or does not release all the way, we recommend that the system be checked by an authorized HYUNDAI dealer. WARNING • Whenever leaving the vehicle or parking, always come to a complete stop and continue to depress the brake pedal.
Page 322: Electronic Parking Brake (Epb)
Electronic Parking Brake (EPB) Check the Parking Brake Warning Light by placing (if equipped) the ignition switch to the Applying the parking brake ON position (do not start the engine). This light will be illuminated when the parking brake is applied with the ignition switch in the START or ON position.
Page 323 P (Park) to R (Reverse) or authorized HYUNDAI dealer. D (Drive). • Do not drive your vehicle with EPB • Shift lever in N (Neutral) applied.
Page 324 Warning messages • NEVER allow anyone who is unfamiliar with the vehicle to touch the EPB switch. If EPB is released unintentionally, serious injury may occur. • Only release EPB when you are seated inside the vehicle with your foot firmly on the brake pedal. NOTICE •...
Page 325 ON position, this indicates that the EPB may have malfunctioned. If this occurs, we recommend that you have the system checked by an authorized HYUNDAI dealer. The EPB malfunction indicator may illuminate when the ESC indicator comes on to indicate that ESC is not working...
Page 326 When the EPB (Electronic Parking Brake) does not release If the EPB does not release normally, we recommend that you contact an authorized HYUNDAI dealer by loading the vehicle on a flatbed tow truck and have the system checked. 6-41...
Page 327: Auto Hold
Driving your vehicle Auto Hold The Auto Hold maintains the vehicle in a standstill even though the brake pedal is not depressed after the driver brings the vehicle to a complete stop by depressing the brake pedal. To apply: OOSH069030L OOSH069030L 2.
Page 328 - Drive downhill. - Drive the vehicle in R (Reverse). NOTICE - Park the vehicle. If the AUTO HOLD indicator changes to yellow, the Auto Hold is not working properly. We recommend that you contact an authorized HYUNDAI dealer. 6-43...
Page 329 Press brake pedal We recommend that you contact an When the conversion from Auto Hold to authorized HYUNDAI dealer. EPB is not working properly a warning will sound and a message will appear. Warning messages When this message is displayed, the Auto Hold and EPB may not operate.
Page 330: Anti-Lock Brake System (Abs)
Anti-lock Brake System (ABS) WARNING An Anti-Lock Braking System (ABS) or an Electronic Stability Control (ESC) system will not prevent accidents due to improper or dangerous driving maneuvers. Even though vehicle control is improved during emergency braking, always maintain a safe distance between you and objects OOSH069033L OOSH069033L...
Page 331 To reduce the risk of serious brakes. Depress your brake pedal as hard injury or death, we recommend that you as possible. contact your HYUNDAI dealer as soon When you apply your brakes under as possible. conditions which may lock the wheels,...
Page 332: Electronic Stability Control (Esc)
Electronic Stability Control (ESC) ESC operation (if equipped) ESC ON condition When the ignition switch is in the ON position, the ESC and the ESC OFF indicator lights illuminate for approximately three seconds and goes off, then the ESC is turned on. When operating When the ESC is in operation, the ESC indicator light blinks:...
Page 333 ESC vehicle be checked by an authorized (braking management) are disabled. HYUNDAI dealer as soon as possible. If the ignition switch is placed in the LOCK/OFF position when ESC is off, ESC The ESC OFF indicator light comes on remains off.
Page 334: Vehicle Stability Management (Vsm)
NOTICE Vehicle Stability Management (VSM) (if equipped) Driving with wheels and tires with different sizes may cause the ESC The Vehicle Stability Management (VSM) system to malfunction. Before replacing is a function of the Electronic Stability tires, make sure all four tires and wheels Control (ESC) system.
Page 335: Hill-Start Assist Control (Hac) (If
VSM system. approximately 2 seconds. When the warning light illuminates we recommend that the vehicle be checked by an authorized HYUNDAI Information dealer as soon as possible. • The HAC does not operate when the shift lever is in P (Park) or N (Neutral).
Page 336: Emergency Stop Signal (Ess) (If
Emergency Stop Signal (ESS) (if Downhill Brake Control (DBC) equipped) (if equipped) The Emergency Stop Signal system alerts the driver behind by blinking the stop lights, while sharply and severely braking. The system is activated when: • The vehicle suddenly stops. (The deceleration power exceeds 7 m/ s2, and the driving speed exceeds 55 km/h (34 mph).)
Page 337 Driving your vehicle DBC operation Mode Indicator light Description Press the DBC button when vehicle speed is under 40km/h (25mph). The DBC system will turn ON and enter the standby mode. Standby The system does not turn ON if vehicle speed is over 40km/h (25mph).
Page 338: Good Braking Practices
Move the shift lever into the P checked by an authorized HYUNDAI (Park) position, then apply the parking dealer as soon as possible. brake, and place the ignition switch in the LOCK/OFF position.
Page 339 Driving your vehicle FOUR WHEEL DRIVE (4WD) (IF EQUIPPED) NOTICE Do not drive in water if the level is higher than the bottom of the vehicle. • Check your brake condition once you are out of mud or water. Depress the brake pedal several times as you move slowly until you feel normal braking return.
Page 340: 4Wd Operation
) stays on the instrument cluster, your vehicle may have a malfunction with the 4WD system. When the 4WD warning light ( ) illuminates we recommend that the vehicle be checked by an authorized HYUNDAI dealer as soon as possible. CAUTION When driving on normal roads, deactivate the 4WD LOCK mode by pushing the 4WD LOCK button (4WD LOCK indicator light goes off).
Page 341 Driving your vehicle NOTICE CAUTION When the 4WD LOCK mode is When the vehicle is stuck in snow, sand deactivated, a sensation may be felt as or mud, place a non-slip material under the driving power is delivered entirely the drive wheels to provide traction to the front wheels.
Page 342 Additional driving conditions • Become familiar with the off-road conditions before driving. • Always pay attention when driving off- road and avoid dangerous areas. • Drive slowly when driving in heavy wind. • Reduce vehicle speed when cornering. The center of gravity of 4WD vehicles is higher than conventional 2WD vehicles, making OLMB053018...
Page 343: Emergency Precautions
[A] : Roll Tester (Speedometer) vehicle with any tire/wheel combination [B] : Temporary Free Roller not recommended by HYUNDAI for off- A full-time 4WD vehicle should not be road driving, you should not use these tested on a 2WD roll tester. If a 2WD tires for highway driving.
Page 344: Activating The Isg
IDLE STOP AND GO (ISG) SYSTEM (IF EQUIPPED) Your vehicle may be equipped with Auto stop the ISG system, which reduces fuel   Gasoline engine Gasoline engine   Diesel engine Diesel engine     consumption by stopping and restarting the engine automatically.
Page 345 Driving your vehicle Intelligent Variable Transmission/Dual To stop the engine in idle stop mode (for 48V MHEV) Clutch Transmission Manual Transmission/Intelligent • Conventional Idle STOP Manual Transmission - Decrease the vehicle speed to 0 km/h Three versions of idle stop are available (0 mph).
Page 346 Auto start Intelligent Variable Transmission/ Dual Clutch Transmission To restart the engine from idle stop mode Release the brake pedal. (except 48V MHEV) The engine will start and the green AUTO Manual transmission vehicle/ STOP indicator ( ) on the instrument Intelligent Manual Transmission cluster will go out.
Page 347: Condition Of Isg System Operation
Driving your vehicle NOTICE Condition of ISG system operation 1. Late restart function is only operated when it is on a level ground and the The ISG system will operate under the vehicle is stable. following condition: 2. To start the engine when the brake •...
Page 348: Isg Indication
ISG Indication The engine will also restart automatically without the driver’s any actions if the The ISG System is indicated by lamp on following occurs: the instrument cluster. If your vehicle is • The brake vacuum pressure is low. equipped with a supervision cluster, the notice will illuminate on the LCD display.
Page 349 Driving your vehicle Unintentionally, when the engine is turned off or the vehicle is moving, if the gear is engaged and the clutch pedal is not pressed, the system displays the warning message as shown below. At this time, if the driver presses the clutch pedal all the way, the engine restarts automatically.
Page 350: Isg Malfunction
Hyundai recommends to contact an authorized Hyundai dealer. • When the ISG OFF button light comes on, it may stop illuminating after...
Page 351: The Battery Sensor Deactivation
HYUNDAI dealer. OOS090040E OOS090040E NOTICE [A] : Battery sensor • Use only the genuine HYUNDAI ISG The battery sensor is deactivated, when battery or the equivalent speficied the battery is disconnected from the for your vehicle for replacement. If negative pole for maintenance purpose.
Page 352: Start Stop Coasting (Ssc) (For 48V Mhev)
START STOP COASTING (SSC) (FOR 48V MHEV) Start Stop Costing helps reduce fuel Engine restarting conditions consumption by automatically stopping • The engine will restart manually when: the engine when the vehicle is in motion. - The accelerator pedal is depressed The engine is stopped when vehicle speed can be maintained without the - The brake pedal is depressed...
Page 353 Driving your vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM (IF EQUIPPED) ECO mode (if equipped)   Type A Type A   When the Drive Mode is set to ECO mode, the engine and transmission control logic are changed to maximize fuel efficiency.
Page 354 Limitation of ECO mode operation: SPORT mode If the following conditions occur while SPORT mode manages the ECO mode is operating, the system driving dynamics by operation is limited even though there is automatically adjusting the no change in ECO indicator. steering effort, the engine and transmission control •...
Page 355: Traction Control
Driving your vehicle TRACTION CONTROL (IF EQUIPPED) Traction Control is a system that Traction mode operation achieve optimal driving performance by controlling engine and braking by road condition (snow, muddy, sandy). Traction Control mode OOS060016L OOS060016L OOS060017L OOS060017L OOS060012L OOS060012L If you press the “DRIVE/TRACTION”...
Page 356: Lcd Display Message
LCD display message • When the message "Transmission cooled down. Resume driving (Trans Transmission hot! Park with engine cooled. Resume driving)" appears you can continue to drive your vehicle. • When possible, drive the vehicle smoothly. OJS058137L OJS058137L OJS058138L OJS058138L •...
Page 357: Special Driving Conditions
Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions WARNING When hazardous driving elements If the vehicle is stuck and excessive are encountered such as water, snow, wheel spin occurs, the temperature ice, mud and sand, take the following in the tires can increase very quickly. precautions: If the tires become damaged, a tire •...
Page 358: Smooth Cornering
Smooth cornering Driving in the rain Avoid braking or gear changing in Rain and wet roads can make driving corners, especially when roads are wet. dangerous. Here are a few things to Ideally, corners should always be taken consider when driving in the rain or on under gentle acceleration.
Page 359: Driving In Flooded Areas
Driving your vehicle Driving in flooded areas Reducing the risk of a rollover Avoid driving through flooded areas Your multi-purpose passenger vehicle is unless you are sure the water is no defined as a Sports Utility Vehicle (SUV). higher than the bottom of the wheel hub. SUV’s have higher ground clearance Drive through any water slowly.
Page 360: Winter Driving
WINTER DRIVING The severe weather conditions of winter Snow tires quickly wear out tires and cause other problems. To minimize winter driving WARNING problems, you should take the following suggestions: Snow tires should be equivalent in size and type to the vehicle’s standard tires. Otherwise, the safety and handling of Information your vehicle may be adversely affected.
Page 361 If tire chains must driving on cleared roads. be used, use genuine HYUNDAI parts or equivalent specified for your vehicle When mounting snow chains, park the and install the tire chain after reviewing vehicle on level ground away from traffic.
Page 362: Winter Precautions
9. chain’s connection. We recommend that the system be checked by an authorized HYUNDAI dealer. Change to “winter weight” oil if necessary In some regions during winter, it is recommended to use the “winter...
Page 363 Window washer anti-freeze solution is chains, tow straps or chains, flashlight, available from an authorized HYUNDAI emergency flares, sand, shovel, jumper dealer, and most vehicle accessory cables, window scraper, gloves, ground outlets.
Page 364: Trailer Towing (For Europe)
We recommend that you ask an laden mass of the vehicle may be authorized HYUNDAI dealer for further exceeded by not more than 10% or 100 details before towing. kg (220.4 lbs), whichever value is lower.
Page 365 What is the maximum safe weight of a recommend that you consult an trailer? It should never weigh more than authorized HYUNDAI dealer for the maximum trailer weight with trailer further information on additional brakes. But even that can be too heavy.
Page 366 Tongue load WARNING Gross Axle Weight Gross Axle Weight Gross Vehicle Weight Gross Vehicle Weight Take the following precautions: • Never load a trailer with more weight in the rear than in the front. The front should be loaded with approximately 60% of the total trailer load;...
Page 367 Driving your vehicle Reference weight and distance when towing a trailer (for Europe) Gasoline Engine Smartstream G1.0 T-GDI/ Smartstream Smartstream G1.0 T-GDI (48V) G1.6 T-GDI Item MHEV With brake 1200 (2645) 1250 (2756) Maximum trailer system weight Without kg (Ibs.) 600 (1322) brake system Maximum permissible static...
Page 368: Trailer Towing Equipment
It’s important to have the correct hitch • A HYUNDAI trailer hitch accessory is equipment. Crosswinds, large trucks available at an authorized HYUNDAI going by, and rough roads are a few dealer.
Page 369: Driving With A Trailer
Driving your vehicle Trailer brakes Driving with a trailer If your trailer is equipped with a braking Towing a trailer requires a certain system, make sure it conforms to amount of experience. Before setting your country’s regulations and that out for the open road, you must get to it is properly installed and operating know your trailer.
Page 370 We recommend proceed once the engine has cooled that you consult an authorized sufficiently. HYUNDAI dealer for assistance. • If you tow a trailer with the maximum gross vehicle weight and maximum trailer weight, it can cause the engine or transmission to overheat.
Page 371 Driving your vehicle • When towing a trailer, your vehicle Parking on hills speed may be much slower than the Generally, if you have a trailer attached general flow of traffic, especially to your vehicle, you should not park your when climbing an uphill gradient.
Page 372: Maintenance When Towing A Trailer
Maintenance when towing a WARNING trailer To prevent serious or fatal injury: Your vehicle will need service more • Do not get out of the vehicle without often when you regularly pull a trailer. the parking brake firmly set. If you Important items to pay particular have left the engine running, the attention to include engine oil, automatic...
Page 373: Vehicle Weight
Driving your vehicle VEHICLE WEIGHT Two labels on your driver’s door sill show GVWR (Gross Vehicle Weight Rating) how much weight your vehicle was This is the maximum allowable weight designed to carry: the Tire and Loading of the fully loaded vehicle (including Information Label and the Certification all options, equipment, passengers Label.
Page 374: Driver Assistance System
7. Driver assistance system Driving Safety Forward Collision–Avoidance Assist (FCA) (Front view camera only) ....7-2 Forward Collision–Avoidance Assist (FCA) (Sensor fusion) ........7-14 Lane Keeping Assist (LKA) ..................7-28 Blind-Spot Collision Warning (BCW) ..............7-34 Blind-Spot Collision-Avoidance Assist (BCA) ............7-43 Safe Exit Warning (SEW) ..................7-56 Manual Speed Limit Assist (MSLA) (for Europe) .............7-61 Intelligent Speed Limit Warning (ISLW) ..............7-64...
Page 375 • If the detecting sensor have been replaced or repaired, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer. OTM070237 OTM070237 • NEVER install any accessories or Forward Collision-Avoidance Assist is...
Page 376 The driver can monitor Forward Collision- Avoidance Assist ON/OFF status from the Settings menu. If the warning light remains ON when the function is ON, we recommend that you have the function inspected by an HYUNDAI dealer.
Page 377 Driver assistance system OTM070140N OTM070140N OTM070141N OTM070141N Warning Timing Warning Volume With the engine on, select ‘Driver With the engine on, select ‘Driver Assistance → Warning Timing’ from the Assistance → Warning Volume’ from the Settings menu to change the initial Settings menu to change the Warning warning activation time for Forward Volume to ‘High’, ‘Medium’...
Page 378 Function operation Basic function Function warning and control The basic feature of Forward Collision- Avoidance Assist is to help warn and control the vehicle depending on collision level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. OTM070144N OTM070144N Emergency braking •...
Page 379 Driver assistance system • Forward Collision-Avoidance Assist does not operate in all situations or cannot avoid all collisions. • The driver should hold the responsibility to control the vehicle. Do not solely depend on Forward Collision-Avoidance Assist. Rather, maintain a safe braking distance, and, if necessary, depress the brake pedal to reduce driving speed or to stop the vehicle.
Page 380 We recommend that the function be inspected by an authorized HYUNDAI dealer. Information In a situation where collision is imminent, braking may be assisted by Forward Collision-Avoidance Assist when braking is insufficient by the driver.
Page 381 • Your vehicle is being towed material) is removed, we recommend • The surrounding is very bright that the function be inspected by an authorized HYUNDAI dealer. • The surrounding is very dark, such as in a tunnel, etc. WARNING •...
Page 382 • Driving through steam, smoke or • You are departing or returning to the shadow lane • Only part of the vehicle, pedestrian or • Unstable driving cyclist is detected • You are on a roundabout and the • The vehicle in front is a bus, heavy vehicle in front is not detected truck, truck with a unusually shaped •...
Page 383 Driver assistance system • There is a group of pedestrians or a WARNING large crowd in front • Driving on a curve • The pedestrian is wearing clothing that easily blends into the background, making it difficult to detect • The pedestrian is difficult to distinguish from the similar shaped structure in the surroundings •...
Page 384 • Driving on a slope OADAS006 OADAS006 OADAS005 OADAS005 Forward Collision-Avoidance Assist OADAS009 OADAS009 may detect a vehicle or pedestrian in the next lane or outside the lane when driving on a curved road. If this occurs, the function may unnecessarily warn the driver and control the brake.
Page 385 Driver assistance system • Changing lanes OADAS033 OADAS033 [A] : Your vehicle, OADAS032 OADAS032 [B] : Lane changing vehicle, [A] : Your vehicle, [C] : Same lane vehicle [B] : Lane changing vehicle When a vehicle in front of you When a vehicle moves into your lane merges out of the lane, Forward from an adjacent lane, it cannot...
Page 386 • Detecting vehicle WARNING • When you are towing a trailer or another vehicle, we recommend that Forward Collision-Avoidance Assist is turned off due to safety reasons. • Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles and pedestrians are detected.
Page 387 Driver assistance system FORWARD COLLISION–AVOIDANCE ASSIST (FCA) (SENSOR FUSION) (IF EQUIPPED) Basic function Detecting sensor (Front view camera, Front radar) OJX1070255L OJX1070255L Forward Collision-Avoidance Assist is OOS070001K OOS070001K designed to help detect and monitor the vehicle ahead or help detect a pedestrian or cyclist in the roadway and warn the driver that a collision is imminent with a warning message and an audible...
Page 388 We • Never disassemble the detecting recommend that the vehicle be sensor or sensor assembly, or apply inspected by an authorized HYUNDAI any impact on it. dealer. • If the detecting sensors have been •...
Page 389 The driver can monitor Forward Collision-Avoidance Assist ON/OFF status from the Settings menu. If the warning light remains ON when the function is ON, we recommend that the function be inspected by an authorized HYUNDAI dealer. 7-16...
Page 390 OTM070140N OTM070140N OTM070141N OTM070141N Warning Timing Warning Volume With the engine on, select ‘Driver With the engine on, select ‘Driver Assistance → Warning Timing’ from the Assistance → Warning Volume’ from the Settings menu to change the initial Settings menu to change the Warning warning activation time for Forward Volume to ‘High’, ‘Medium’...
Page 391 Driver assistance system Function operation Basic function Function warning and control The basic function for Forward Collision- Avoidance Assist is to help warn and control the vehicle depending on the collision level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. OTM070144N OTM070144N Emergency Braking...
Page 392 WARNING Take the following precautions when using Forward Collision-Avoidance Assist: • For your safety, change the Settings after parking the vehicle at a safe location. • With ‘Active Assist’ or ‘Warning Only’ selected, when ESC is turned off by pressing and holding the ESC OFF OTM070059L OTM070059L button for more than 3 seconds,...
Page 393 Driver assistance system • During Forward Collision-Avoidance CAUTION Assist operation, the vehicle may • Forward Collision-Avoidance stop suddenly injuring passengers Assist operating speed range may and shifting loose objects. Always reduce due to the conditions of have the seat belt on and keep loose the vehicle or pedestrian in front objects secured.
Page 394 If this occurs the ‘Forward Safety cluster. We recommend that the function system(s) disabled. Camera obscured’ or be inspected by an authorized HYUNDAI the ‘Forward Safety system(s) disabled. dealer. Radar blocked’ warning message, and the warning lights will illuminate on the cluster.
Page 395 Driver assistance system • Your vehicle is being towed WARNING • The surrounding is very bright • Even though the warning message or • The surrounding is very dark, such as warning light does not appear on the in a tunnel, etc. cluster, Forward Collision-Avoidance Assist may not properly operate.
Page 396 • Driving through a tunnel or iron bridge • The pedestrian or cyclist is not fully detected, for example, if the • Driving in large areas where there are pedestrian is leaning over or is not few vehicles or structures (i.e. desert, fully walking upright meadow, suburb, etc.) •...
Page 397 Driver assistance system • The pedestrian or cyclist is wearing WARNING clothing that easily blends into the • Driving on a curve background, making it difficult to detect • The pedestrian or cyclist is difficult to distinguish from the similar shaped structure in the surroundings •...
Page 398 • Driving on a slope OADAS015 OADAS015 OADAS012 OADAS012 OADAS017 OADAS017 OADAS019 OADAS019 Forward Collision-Avoidance Assist OADAS010 OADAS010 OADAS011 OADAS011 may detect a vehicle, pedestrian or Forward Collision-Avoidance Assist cyclist in the next lane or outside the may not detect other vehicles, lane when driving on a curved road.
Page 399 Driver assistance system • Changing lanes OADAS031 OADAS031 [A] : Your vehicle, [B] : Lane changing vehicle, OADAS030 OADAS030 [C] : Same lane vehicle [A] : Your vehicle, When a vehicle in front of you [B] : Lane changing vehicle merges out of the lane, Forward When a vehicle moves into your lane Collision-Avoidance Assist may not...
Page 400 • Detecting vehicle WARNING • When you are towing a trailer or another vehicle, we recommend that Forward Collision-Avoidance Assist is turned off due to safety reasons. • Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles, pedestrians and cyclists are detected.
Page 401 Driver assistance system LANE KEEPING ASSIST (LKA) (IF EQUIPPED) Lane Keeping Assist is designed to help Function settings detect lane markings (or road edges) Setting while driving over a certain speed. The function will warn the driver if the vehicle leaves the lane without using the turn signal, or will automatically assist the driver’s steering to help prevent the...
Page 402 Turning the function On/Off (Lane Driving Assist button) OTM070141N OTM070141N Warning Volume With the engine on, select ‘Driver OOS070014K OOS070014K Assistance → Warning Volume’ from the • Except Europe Settings menu to change the Warning With the engine on, press and hold Volume to ‘High’, ‘Medium’...
Page 403 Driver assistance system Function operation Lane Keeping Assist Function warning and control • To warn the driver that the vehicle is departing from the projected lane Lane Keeping Assist will help warn and in front, the green indicator control the vehicle with Lane Departure light will blink on the cluster, and the Warning and Lane Keeping Assist.
Page 404 WARNING Information • The steering wheel may not be • You may change settings from the assisted if the steering wheel is held instrument cluster (User Settings) or very tight or the steering wheel is infotainment system (Vehicle Settings), steered over a certain degree. whichever option that is provided with your vehicle.
Page 405 If this occurs, we recommend • Lane Keeping Assist will not operate that the function be inspected by an when: authorized HYUNDAI dealer. - The turn signal or hazard warning flasher is turned on WARNING - The vehicle is not driven in the...
Page 406 Limitations of the function • There is a road edge without a lane • There is a boundary structure in the Lane Keeping Assist may not operate roadway, such as a tollgate, sidewalk, normally or may operate unexpectedly curb, etc. under the following circumstances: •...
Page 407 Driver assistance system BLIND-SPOT COLLISION WARNING (BCW) (IF EQUIPPED) Blind-Spot Collision Warning is designed to help detect and monitor approaching vehicles in the driver’s blind spot area and warn the driver of a possible collision with a warning message and audible warning.
Page 408 ‘Driver Assistance → Blind-Spot Safety’ that the vehicle be inspected by an from the Settings menu to set whether or authorized HYUNDAI dealer. not to use each function. • If there is impact on the rear - If ‘Warning Only’ is selected, the...
Page 409 Driver assistance system OTM070097N OTM070097N OTM070140N OTM070140N When the engine is restarted with the Warning Timing function off, the ‘Blind-Spot Safety With the engine on, select ‘Driver System is Off’ message will appear on Assistance → Warning Timing’ from the the cluster.
Page 410 System operation System warning   Left-side Left-side     Right-side Right-side   OTM070141N OTM070141N Warning Volume With the engine on, select ‘Driver OOS057024 OOS057024 Assistance → Warning Volume’ from the Vehicle detection Settings menu to change the Warning •...
Page 411 Driver assistance system WARNING WARNING • The detecting range of the rear Take the following precautions when corner radar is determined by the using Blind-Spot Safety system: standard road width, therefore, on a • For your safety, change the Settings narrow road, the function may detect after parking the vehicle at a safe other vehicles in the next next lane...
Page 412 When the outside rearview mirror warning light is not working properly, the ‘Check side view mirror warning light’ (or 'Check outside mirror warning icon') warning message will appear on the cluster. We recommend that the function be inspected by an authorized HYUNDAI dealer. 7-39...
Page 413 Driver assistance system • There is a fixed object near the WARNING vehicle, such as sound barriers, • Even though the warning message guardrails, central dividers, entry does not appear on the cluster, Blind- barriers, street lamps, signs, Spot Safety system may not properly tunnels, walls, etc.
Page 414 Blind-Spot Safety system may not WARNING operate normally, or the system may • Driving on a curve operate unexpectedly when the following objects are detected: • A motorcycle or bicycle is detected • A vehicle such as a flat trailer is detected •...
Page 415 Driver assistance system • Driving where the road is merging/ • Driving where the heights of the dividing lanes are different OJX1079059 OJX1079059 OOS070017K OOS070017K Blind-Spot Safety system may not Blind-Spot Safety system may not operate properly when driving where operate properly when driving where the road merges or divides.
Page 416 BLIND-SPOT COLLISION-AVOIDANCE ASSIST (BCA) (IF EQUIPPED) Blind-Spot Collision-Avoidance Assist is designed to help detect and monitor approaching vehicles in the driver’s blind spot area and warn the driver of a possible collision with a warning message and audible warning. In addition, if there is a risk of collision when changing lanes or driving forward out of a parking space, the function will help avoid a collision by applying the...
Page 417 • If there is impact on the rear corner radar or near the radar, even though the warning message does not appear on the cluster, Blind-Spot Safety system may not operate properly. We recommend that the function be inspected by an authorized HYUNDAI dealer. 7-44...
Page 418 Function settings replaced or repaired, we recommend Setting that the vehicle be inspected by an authorized HYUNDAI dealer. • Use only genuine parts to repair the rear bumper where the rear corner radar is located. • Do not apply license plate frame or...
Page 419 Driver assistance system OTM070097N OTM070097N OTM070140N OTM070140N When the engine is restarted with the Warning Timing system off, the ‘Blind-Spot Safety System With the engine on, select ‘Driver is Off’ message will appear on the Assistance → Warning Timing’ from the cluster.
Page 420 Function operation Function warning and control   Left-side Left-side     Right-side Right-side   OTM070141N OTM070141N Warning Volume With the engine on, select ‘Driver OOS057024 OOS057024 Assistance → Warning Volume’ from the Vehicle detection Settings menu to change the Warning •...
Page 421 Driver assistance system Collision Warning WARNING • Collision warning will operate when • The detecting range of the rear the turn signal is turned on in the corner radar is determined by a direction of the detected vehicle. standard road width, therefore, on a •...
Page 422 WARNING • Collision-Avoidance Assist will be canceled under the following circumstances: - Your vehicle enters the next lane by a certain distance - Your vehicle is away from the collision risk - The steering wheel is sharply steered OOS070005L OOS070005L - The brake pedal is depressed Collision-Avoidance Assist (while driving) - Forward Collision-Avoidance Assist...
Page 423 Driver assistance system OOS070031L OOS070031L OTM070059L OTM070059L Collision-Avoidance Assist (while Stopping vehicle and ending brake control departing) • When the vehicle is stopped due • To warn the driver of a collision, the to emergency braking, the ‘Drive warning light on the outside rearview carefully’...
Page 424 • Blind-Spot Safety system may warn WARNING the driver late or may not warn the Take the following precautions when driver depending on the road and using Blind-Spot Safety system: driving conditions. • For your safety, change the Settings • Driver should maintain control after parking the vehicle at a safe of the vehicle at all times.
Page 425 (e.g. open cluster. We recommend that the system terrain) where any substance are be inspected by an authorized HYUNDAI not detected right after the engine dealer. is turned on, or when the detecting...
Page 426 • The speed of the other vehicle is very CAUTION fast that it passes by your vehicle in a Turn off Blind-Spot Safety system to short time install a trailer, carrier, etc., or remove • Your vehicle passes by the other the trailer, carrier, etc.
Page 427 Driver assistance system Braking control may not work, driver’s WARNING attention is required in the following • Driving on a curve circumstances: • The vehicle severely vibrates while driving over a bumpy road, uneven road or concrete patch • Driving on a slippery surface due to snow, water puddle, ice, etc.
Page 428 • Driving where the road is merging/ • Driving where the heights of the dividing lanes are different OJX1079059 OJX1079059 OOS070018K OOS070018K Blind-Spot Safety system may not Blind-Spot Safety system may not operate properly when driving where operate properly when driving where the road merges or divides.
Page 429 Driver assistance system SAFE EXIT WARNING (SEW) (IF EQUIPPED) Detecting sensor (Rear corner radar) OOS070026K OOS070026K After the vehicle stops, when an OOS070004K OOS070004K approaching vehicle from the rear area is [1] : Rear corner radar detected as soon as a passenger opens The rear corner radars are sensors a door, Safe Exit Warning will warn the located inside the rear bumper to detect...
Page 430 System settings Setting functions for the system OTM070140N OTM070140N Warning Timing With the engine on, select ‘Driver OOS070043L OOS070043L Assistance → Warning Timing’ from the Safe Exit Warning Settings menu to change the initial With the engine on, select ‘Driver warning activation time for Blind-Spot Assistance →...
Page 431 Driver assistance system Function operation Function warning OTM070141N OTM070141N Warning Volume With the engine on, select ‘Driver OTM070101N OTM070101N Assistance → Warning Volume’ from the Collision warning when exiting vehicle Settings menu to change the Warning • When an approaching vehicle from Volume ‘High’, ‘Medium’...
Page 432 We recommend that the warning - Blind-Spot Safety system sensor or be inspected by an authorized HYUNDAI the sensor surrounding is polluted dealer. or covered - Blind-Spot Safety system fails to...
Page 433 • Safe Exit Warning may not operate after it is removed, we recommend for 3 seconds after the vehicle is that the system be inspected by an authorized HYUNDAI dealer. started, or the rear corner radars are initialized. WARNING • Even though the warning message...
Page 434 MANUAL SPEED LIMIT ASSIST (MSLA) (FOR EUROPE) OTM070111L OTM070111L OOS070006K OOS070006K (1) Manual Speed Limit Assist enabled 2. Push the + switch up or - switch down, indicator and release it at the desired speed. (2) Set speed Push the + switch up or - switch down and hold it.
Page 435 Driver assistance system To resume the function Information • When the accelerator pedal is not depressed beyond the pressure point, vehicle speed will maintain within the speed limit. • A clicking sound may be heard from the kickdown mechanism when the accelerator pedal is depressed beyond the pressure point.
Page 436 To turn off the function WARNING Take the following precautions when   Type A Type A   using Manual Speed Limit Assist: • Always set the vehicle speed to the speed limit in your country. • Keep Manual Speed Limit Assist off when the system is not in use, to ...
Page 437 Driver assistance system INTELLIGENT SPEED LIMIT WARNING (ISLW) (IF EQUIPPED) Intelligent Speed Limit Warning uses Function settings information from the detected road sign Setting and navigation system to inform the driver of the speed limit and additional information of the current road. CAUTION Intelligent Speed Limit Warning may not operate properly if the function is...
Page 438 Function operation Information Function display • Intelligent Speed Limit Warning provides additional road sign   "Driving Assist" "Driving Assist"   screen selected screen selected information in addition to speed limit. The additional road sign information provided may vary according to your country.
Page 439 Driver assistance system Additional road signs   End of a speed limit End of a speed limit     No reliable speed limit information No reliable speed limit information   - - - WUM-207 WUM-207 WUM-208 WUM-208 •...
Page 440 If this occurs, If this occurs, the ‘Speed limit system we recommend that the function be disabled. Camera obscured’ warning inspected by an authorized HYUNDAI message will appear on the cluster. dealer. The function will operate normally when snow, rain or foreign material is removed.
Page 441 Driver assistance system Limitations of the function • The field of view of the front view camera is obstructed by sun glare Intelligent Speed Limit Warning function • Driving on a road that is sharply may not operate or may not provide curved or continuously curved correct information under the following circumstances:...
Page 442 DRIVER ATTENTION WARNING (DAW) (IF EQUIPPED) Basic function Function settings Driver Attention Warning will help Setting determine the driver's attention level by   Type A Type A   Type B Type B     analyzing driving pattern, driving time, etc.
Page 443 Driver assistance system Function operation Basic function Function display and warning The basic function of Driver Attention Warning is to inform the driver of their ‘Attention Level’ and to warn the driver to ‘Consider taking a break’. Attention level   Function off Function off ...
Page 444 • The driver’s attention level is displayed CAUTION on the scale of 1 to 5. The lower the • Driver Attention Warning may level is, the more inattentive the driver suggest a break depending on the driver’s driving pattern or habits, •...
Page 445 If this occurs, we recommend will sound. that the function be inspected by an authorized HYUNDAI dealer. WARNING Limitations of the function • If any other function’s warning Driver Attention Warning may not work...
Page 446 • When the vehicle ahead sharply steers Leading Vehicle Departure Alert feature • When the vehicle cuts in OADAS034 OADAS034 [A] : Your vehicle, [B] : Front vehicle OADAS021 OADAS021 If the vehicle in front makes a sharp turn, such as to turn left or right or make a U-turn, etc., Leading Vehicle Departure Alert may not operate properly.
Page 447 Driver assistance system • When a pedestrian or bicycle is • When driving at a tollgate or between you and the vehicle ahead intersection, etc. OADAS025 OADAS025 OADAS026 OADAS026 If there is a pedestrian(s) or bicycle(s) If you pass a tollgate or intersection in between you and the vehicle in with lots of vehicles or you drive front, Leading Vehicle Departure Alert...
Page 448 CRUISE CONTROL (CC) (IF EQUIPPED) Function operation To set speed 1. Accelerate to the desired speed, which must be more than 30 km/h (20 mph).   Type A Type A   OTM070111 OTM070111 (1) Cruise indicator   Type B Type B ...
Page 449 Driver assistance system To increase speed To decrease speed OOS070010K OOS070010K OOS070009K OOS070009K • Push the - switch down and release it • Push the + switch up and release it immediately. The cruising speed will immediately. The cruising speed will decrease by 1 km/h (1 mph) each time increase by 1 km/h (1 mph) each time the switch is operated in this manner.
Page 450 To temporarily pause the function To resume the function OOS070011K OOS070011K OOS070012K OOS070012K Cruise Control will be paused when: Push the +, - switch or button. • Depressing the brake pedal. If you push the + switch up or - switch down, vehicle speed will be set to the •...
Page 451 Driver assistance system To turn off the function WARNING Take the following precautions when   Type A Type A   using Cruise Control: • Always set the vehicle speed to the speed limit in your country. • Keep Cruise Control off when the system is not in use, to avoid ...
Page 452 SMART CRUISE CONTROL (SCC) (IF EQUIPPED) Smart Cruise Control is designed to CAUTION detect the vehicle ahead and help Always keep the front view camera maintain the desired speed and and front radar in good condition to minimum distance between the vehicle maintain optimal performance of Smart ahead.
Page 453 Driver assistance system Function settings Setting   Type A Type A     Type B Type B   OOS070013K OOS070013K To set vehicle distance Each time the button is pressed, the OOS070008E OOS070008E vehicle distance changes as follows: To turn on the function •...
Page 454 OOS070009K OOS070009K OOS070010K OOS070010K To increase speed To decrease speed • Push the + switch up and release it • Push the - switch down and release it immediately. The cruising speed will immediately. The cruising speed will increase by 1 km/h (1 mph) each time decrease by 1 km/h (1 mph) each time the switch is operated in this manner.
Page 455 Driver assistance system WARNING Check the driving condition before using the switch. Driving speed may sharply increase or decrease when you press the switch.   Type A Type A   OOS070011E OOS070011E To temporarily cancel the function   Type B Type B ...
Page 456 Function operation   Type A Type A   Type B Type B     Operating conditions Smart Cruise Control will operate when the following conditions are satisfied. Basic function • The gear is in D (Drive) •...
Page 457 Driver assistance system Function display and control Overtaking Acceleration Assist Overtaking Acceleration Assist will Basic function operate when the turn signal indicator You can see the status of the Smart is turned on to the left (left-hand drive) Cruise Control operation in the Driving or turned on to the right (right-hand Assist mode on the cluster.
Page 458 To temporarily accelerate OTM070155 OTM070155 • When temporarily canceled OTM070246 OTM070246 indicator is displayed. If you want to speed up temporarily (2) The previous set speed is shaded. when Smart Cruise Control is on, depress the accelerator pedal. While the speed Information is increasing, the set speed, distance level and target distance will blink on the...
Page 459 Driver assistance system Function temporarily canceled Function conditions not satisfied   Type A Type A   Type B Type B   Type A Type A   Type B Type B       ...
Page 460 In traffic situation Warning road conditions ahead OTM070114L OTM070114L OTM070055L OTM070055L In the following situation, the ‘Watch for In traffic, your vehicle will stop if the surrounding vehicles’ warning message vehicle ahead of you stops. Also, if the will appear on the cluster, and an audible vehicle ahead of you starts moving, your warning will sound to warn the driver of vehicle will start as well.
Page 461 Driver assistance system Collision Warning WARNING Take the following precautions when using Smart Cruise Control: • Smart Cruise Control does not substitute for proper and safe driving. It is the responsibility of the driver to always check the speed and distance to the vehicle ahead.
Page 462 We recommend sound is generated, Smart Cruise that the function be inspected by an Control warning message may not authorized HYUNDAI dealer. be displayed and warning sound may not be generated. • You may not hear the warning sound of Forward Collision-Avoidance Assist if the surrounding is noisy.
Page 463 Driver assistance system Function disabled Limitations of the function Smart Cruise Control may not operate   Type A Type A   Type B Type B     normally, or the function may operate unexpectedly under the following circumstances: •...
Page 464 • Only part of the vehicle is detected • The vehicle in front is bent out of shape • The vehicle in front has no tail lights, tail lights are located unusually, etc. • The front vehicle’s speed is fast or slow •...
Page 465 Driver assistance system • Driving on a curve • Driving on a slope OADAS014 OADAS014 OADAS012 OADAS012 On curves, Smart Cruise Control may During uphill or downhill driving, the not detect a vehicle in the same lane, Smart Cruise Control may not detect and may accelerate to the set speed.
Page 466 • Changing lanes • Detecting vehicle OJX1079181 OJX1079181 In the following cases, some vehicles in your lane cannot be detected by the sensor: - Vehicles offset to one side - Slow-moving vehicles or sudden- decelerating vehicles - Oncoming vehicles - Stopped vehicles - Vehicles with small rear profile, such as trailers OADAS030...
Page 467 Driver assistance system OOS057022 OOS057022 OTM058119 OTM058119 In the following cases, the vehicle • When a vehicle in front of you merges in front cannot be detected by the out of the lane, Smart Cruise Control sensor: may not immediately detect the new vehicle that is now in front of you.
Page 468 NAVIGATION-BASED SMART CRUISE CONTROL (NSCC) (IF EQUIPPED) Navigation-based Smart Cruise Control Function settings will help automatically adjust vehicle Setting speed when driving on highways (or motorways) by using road information from the navigation system while Smart Cruise Control is operating. Information Navigation-based Smart Cruise Control is available only on controlled access road of...
Page 469 Driver assistance system Function operation • Function operating Operating conditions Navigation-based Smart Cruise Control is ready to operate if all of the following conditions are satisfied: • Smart Cruise Control is operating • Driving on main roads of highways (or motorways) Information For more details on how to operate Smart...
Page 470 • If Highway Set Speed Auto Change Information function has changed to the standby Highway Curve Zone Auto Slowdown and state by depressing the brake pedal Highway Set Speed Auto Change function or pressing the switch on the uses the same symbol.
Page 471 Driver assistance system Limitations of the function • The vehicle enters a service station or rest area Navigation-based Smart Cruise Control • The speed limit of some sections may not operate normally under the changes according to the road following circumstances: situations •...
Page 472 OJX1070280L OJX1070280L OJX1070281L OJX1070281L [1] : Set route, [2] : Branch line, [3] : Driving route, [1] : Set route, [2] : Branch line, [3] : Driving route, [4] : Main road, [5] : Curved road section [4] : Main road, [5] : Curved road section •...
Page 473 Driver assistance system WARNING • Navigation-based Smart Cruise Control is not a substitute for safe driving practices, but a convenience function. Always have your eyes on the road, and it is the responsibility of the driver to avoid violating traffic laws.
Page 474 • After you pass through a tollgate on a Information highway (or motorway), Navigation- • The time gap could occur between based Smart Cruise Control will the navigation’s guidance and when operate based on the first lane. If Navigation-based Smart Cruise Control you enter one of the other lanes, the operation starts and ends.
Page 475 Driver assistance system LANE FOLLOWING ASSIST (LFA) (IF EQUIPPED) Lane Following Assist is designed to help Function settings detect lane markings and/or vehicles on Setting the road, and assists the driver’s steering to help center the vehicle in the lane. Detecting sensor (Front view camera) OOS070014K OOS070014K...
Page 476 Function operation Warning and control OTM070141N OTM070141N Warning Volume With the engine on, select ‘Driver OTM070243 OTM070243 Assistance → Warning Volume’ from the Lane Following Assist Settings menu to change the Warning If the vehicle ahead and/or both lane Volume to ‘High’, ‘Medium’ or ‘Low’ for markings are detected and your vehicle Hands-off warning.
Page 477 Driver assistance system   Type A Type A   Type B Type B     WARNING • Lane Following Assist does not operate at all times. It is the responsibility of the driver to safely steer the vehicle and to maintain the vehicle in its lane.
Page 478 ‘Check Lane Following Assist (LFA) system’ (or ‘Check LFA (Lane Following Assist) system’) warning message will appear on the cluster. If this occurs, we recommend that the function be inspected by an authorized HYUNDAI dealer. OTM070025 OTM070025 OTM070026 OTM070026 WARNING •...
Page 479 Driver assistance system HIGHWAY DRIVING ASSIST (HDA) (IF EQUIPPED) Basic function Detecting sensor (Front view camera, Front radar) Highway Driving Assist is designed to help detect vehicles and lanes ahead, and help maintain distance from the vehicle ahead, maintain the set speed, and help center the vehicle in the lane while driving on the highway (or motorway).
Page 480 • If there is a problem with the function(s), the settings cannot be changed. We recommend that the function be inspected by an authorized HYUNDAI dealer. • If the engine is restarted, the function(s) will maintain the last setting. 7-107...
Page 481 Driver assistance system Function operation (2) Set speed is displayed. Basic function (3) Lane Following Assist indicator displayed. Function display and control (4) Whether there is a vehicle ahead and You can see the status of the Highway the selected vehicle distance are Driving Assist operation in the Driving displayed.
Page 482 • Restarting after stopping • Hands-off warning   Type A Type A   Type B Type B     OTM070114L OTM070114L OTM070037N OTM070037N OTM070037L OTM070037L When Highway Driving Assist is If the driver takes their hands off the operating, your vehicle will stop if the steering wheel for several seconds, vehicle ahead of you stops.
Page 483 • Highway Driving Assist will turn off cluster. We recommend that the function automatically under the following be inspected by an authorized HYUNDAI situations: dealer. - Driving on roads that the system does not operate, such as a rest area, intersection, junction, etc.
Page 484 • Highway Driving Assist may Limitations of the function inadvertently operate or turn off Highway Driving Assist may not operate depending on road conditions normally, or may not operate under the (navigation information) and following circumstances: surroundings. • The map information and the •...
Page 485 Driver assistance system REAR VIEW MONITOR (RVM) Detecting sensor OOS070015K OOS070015K OOS070029K OOS070029K [1] : Rear view camera Refer to the picture above for the detailed location of the detecting sensor. WARNING The image shown on the screen may differ from the actual distance of the object.
Page 486 Function settings Off conditions Camera settings • The rear view cannot be turned off when the gear is in R (Reverse). • You can change Rear View Monitor • Press the Parking/View button (1) again settings by pressing the setup icon while the gear is in P (Park) with the rear ) on the screen while the system is view on the screen, the rear view will turn...
Page 487 Driver assistance system Rear view while driving (if equipped) Operating conditions Press the Parking/View button while the gear is in D (Drive) or N (Neutral), the driving rear view will appear on the screen. Off conditions • Press the Parking/View button again, the driving rear view will turn off.
Page 488 When Rear View Monitor is not working properly, or the screen flickers, or the camera image does not display normally, we recommend that the function be inspected by an authorized HYUNDAI dealer. Limitations of the function When the vehicle is stopped for a long...
Page 489 Driver assistance system REAR CROSS-TRAFFIC COLLISION WARNING (RCCW) (IF EQUIPPED) Rear Cross-Traffic Collision Warning Detecting sensor (Rear corner radar) Assist is designed to help detect vehicles approaching from the left and right side while your vehicle is reversing, and warn the driver that a collision is imminent with a warning message and an audible warning.
Page 490 Function settings Setting OTM070140N OTM070140N Warning Timing With the engine on, select ‘Driver OTM070194N OTM070194N Assistance → Warning Timing’ from the Rear Cross-Traffic Safety Settings menu to change the initial With the engine on, select ‘Driver warning activation time for Rear Cross- Assistance →...
Page 491 Driver assistance system Function operation Function warning Rear Cross-Traffic Safety system will warn the driver when a collision is imminent.   Left-side Left-side   OTM070141N OTM070141N   Right-side Right-side   Warning Volume With the engine on, select ‘Driver Assistance →...
Page 492 • The function will operate when all the WARNING following conditions are satisfied: Take the following precautions when - The gear is shifted to R (Reverse) using Rear Cross-Traffic Safety system: - Vehicle speed is below 8 km/h • For your safety, change the Settings (5 mph) after parking the vehicle at a safe - The approaching vehicle is within...
Page 493 If this occurs, the ‘Rear Cross-Traffic Safety system disabled. Radar blocked’ limited. We recommend that the system (or ‘Rear cross-traffic safety functions be inspected by an authorized HYUNDAI disabled. Radar blocked’) warning dealer. message will appear on the cluster.   Type A Type A ...
Page 494 WARNING WARNING • Even though the warning message • Driving near a vehicle or structure does not appear on the cluster, Rear Cross-Traffic Safety system may not operate properly. • Rear Cross-Traffic Safety system may not operate properly in an area (for example: open terrain), where any substance are not detected after turning ON the engine.
Page 495 Driver assistance system • When the vehicle is in a complex • When the vehicle is parked diagonally parking environment OJX1079112 OJX1079112 OJX1079113 OJX1079113 [A] : Vehicle Rear Cross-Traffic Safety system may detect vehicles which are parking Rear Cross-Traffic Safety system or pulling out near your vehicle (for may be limited when backing up example: a vehicle leaving beside...
Page 496 • Pulling into the parking space where • When the vehicle is parked rearward there is a structure OJX1079116 OJX1079116 OJX1079115 OJX1079115 Rear Cross-Traffic Safety system may [A] : Structure, [B] : Wall detect vehicles passing by behind you when parking in reverse into Rear Cross-Traffic Safety system a parking space.
Page 497 Driver assistance system REAR CROSS-TRAFFIC COLLISION-AVOIDANCE ASSIST (RCCA) (IF EQUIPPED) Rear Cross-Traffic Collision-Avoidance Detecting sensor (Rear corner radar) Assist is designed to help detect vehicles approaching from the left and right side while your vehicle is reversing, and warn the driver that a collision is imminent with a warning message and an audible warning.
Page 498 Function settings Setting OTM070140N OTM070140N Warning Timing With the engine on, select ‘Driver OTM070194N OTM070194N Assistance → Warning Timing’ from the Rear Cross-Traffic Safety Settings menu to change the initial With the engine on, select ‘Driver warning activation time for Rear Cross- Assistance →...
Page 499 Driver assistance system Function operation Function warning and control Rear Cross-Traffic Safety system will warn and control the vehicle depending on collision level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’.   Left-side Left-side   OTM070141N OTM070141N Warning Volume...
Page 500 At the same time, an audible warning   Left-side Left-side   will sound. If Rear View Monitor is operating, a warning will also appear on the infotainment system screen. • The function will operate when all the following conditions are satisfied: - The gear is shifted to R (Reverse) ...
Page 501 Driver assistance system • The function will operate when all the following conditions are satisfied: - The gear is shifted to R (Reverse) - Vehicle speed is below 8 km/h (5 mph) - The approaching vehicle is within approximately 1.5 m (5 ft.) from the left and right side of your vehicle - The speed of the vehicle approaching from the left and right...
Page 502 • The driver should hold the WARNING responsibility to control the vehicle. Take the following precautions when Do not solely depend on Rear using Rear Cross-Traffic Safety system: Cross-Traffic Safety system. Rather, maintain a safe braking distance, and • For your safety, change the Settings if necessary, depress the brake pedal after parking the vehicle at a safe to reduce driving speed or to stop...
Page 503 When the outside rearview mirror warning light is not working properly, the ‘Check side view mirror warning light’ (or ‘Check outside mirror warning icon’) warning message will appear on the cluster. We recommend that the function be inspected by an authorized HYUNDAI dealer. 7-130...
Page 504 WARNING CAUTION • Even though the warning message For more details on the limitations of does not appear on the cluster, Rear the rear corner radar, refer to “Blind- Cross-Traffic Safety system may not Spot Collision-Avoidance Assist (BCA)” operate properly. section in chapter 7.
Page 505 Driver assistance system • When the vehicle is in a complex • When the vehicle is parked diagonally parking environment OJX1079112 OJX1079112 OJX1079113 OJX1079113 [A] : Vehicle Rear Cross-Traffic Safety system may detect vehicles which are parking Rear Cross-Traffic Safety system or pulling out near your vehicle (for may be limited when backing up example: a vehicle leaving beside...
Page 506 • Pulling into the parking space where • When the vehicle is parked rearward there is a structure OJX1079116 OJX1079116 OJX1079115 OJX1079115 Rear Cross-Traffic Safety system may [A] : Structure, [B] :Wall detect vehicles passing by behind you when parking in reverse into Rear Cross-Traffic Safety system a parking space.
Page 507 Driver assistance system REVERSE PARKING DISTANCE WARNING (PDW) (IF EQUIPPED) Reverse Parking Distance Warning will Function operation help warn the driver if an obstacle is Operating button detected within a certain distance when   Type A Type A the vehicle is moving in reverse at low ...
Page 508 Driving If it still does not work properly, we rearward recommend that the function be inspected by an authorized HYUNDAI 60~120 cm Buzzer beeps dealer. (24~48 in.) intermittently • The audible warning does not sound.
Page 509 - The surface of the sensor is needs repair, we recommend that scratched with a sharp object the function be inspected by an - The sensors or its surrounding authorized HYUNDAI dealer. area is directly sprayed with high pressure washer 7-136...
Page 510 FORWARD/REVERSE PARKING DISTANCE WARNING (PDW) (IF EQUIPPED) Forward/Reverse Parking Distance Parking Distance Warning Auto On Warning will help warn the driver if an To use Parking Distance Warning Auto obstacle is detected within a certain On function, select ‘Driver Assistance distance when the vehicle is moving →...
Page 511 Driver assistance system • When Forward/Reverse Parking • When ‘Parking Distance Warning Auto Distance Warning turns on, the button On’ is deselected, and the vehicle’s indicator light will turn on. If vehicle forward speed is above 30 km/h speed is above 30 km/h (18 mph), (18 mph), the Parking Safety button Forward/Reverse Parking Distance indicator will turn off.
Page 512 If it still does not work properly, we sensors can detect a person, animal recommend that the function be when it is within 60 cm (24 in.) from inspected by an authorized HYUNDAI the sensors. dealer. • The audible warning does not sound.
Page 513 Warning needs repair, we recommend - The surface of the sensor is that the function be inspected by an scratched with a sharp object authorized HYUNDAI dealer. - The sensors or its surrounding area is directly sprayed with high pressure washer...
Page 514 DECLARATION OF CONFORMITY (IF EQUIPPED) Front radar The radio frequency components (front radar) complies:  For Europe and CE certified countries OANATEL171 OANATEL171 OANATEL169 OANATEL169 OANATEL172 OANATEL172 OANATEL170 OANATEL170 7-141...
Page 515 Driver assistance system OANATEL173 OANATEL173 OANATEL175 OANATEL175 OANATEL174 OANATEL174 OANATEL176 OANATEL176 7-142...
Page 516 OANATEL177 OANATEL177 OANATEL179 OANATEL179 OANATEL178 OANATEL178 OANATEL180 OANATEL180 7-143...
Page 517 Driver assistance system  For Singapore OANATEL181 OANATEL181  For Taiwan OANATEL201 OANATEL201  For Brazil OANATEL192 OANATEL192  For Mexico OANATEL191 OANATEL191  For Malaysia OANATEL198 OANATEL198 OANATEL200 OANATEL200 7-144...
Page 518  For Paraguay  For Moldova OANATEL207 OANATEL207 OANATEL193 OANATEL193  For Ukraina  For UAE OANATEL189 OANATEL189  For Argentina OANATEL194 OANATEL194 OANATEL204 OANATEL204 7-145...
Page 519 Driver assistance system  For Japan  For Thailand OANATEL186 OANATEL186  For Jordan OANATEL203 OANATEL203 OANATEL199 OANATEL199  For Republic of South Africa  For Russia OANATEL206 OANATEL206 OANATEL190 OANATEL190  For China OANATEL205 OANATEL205 7-146...
Page 520  For Hongkong  For Phillippines OANATEL188 OANATEL188  For Serbia OANATEL197 OANATEL197 OANATEL195 OANATEL195  For Morocco OANATEL196 OANATEL196 7-147...
Page 521 Driver assistance system Rear corner radar  For Taiwan The radio frequency components (Rear Corner Radar) complies:  For Europe and CE certified countries OOS070034L OOS070034L OANATEL005 OANATEL005  For Indonesia OANATEL006 OANATEL006 7-148...
Page 522  For Malaysia  For Mexico OANATEL007 OANATEL007  For Singapore OANATEL012 OANATEL012  For Japan OANATEL008 OANATEL008  For Vietnam OANATEL010 OANATEL010 OANATEL041 OANATEL041  For Brazil  For Ukraine OANATEL011 OANATEL011 OANATEL013 OANATEL013 7-149...
Page 523 Driver assistance system  For Jordan  For Ghana OANATEL018 OANATEL018 OANATEL014 OANATEL014  For Oman  For Zambia OANATEL015 OANATEL015 OANATEL019 OANATEL019  For UAE  For Jamaica OANATEL020 OANATEL020 OANATEL016 OANATEL016  For Botswana  For Paraguay OANATEL021 OANATEL021 OANATEL017 OANATEL017...
Page 524  For Uzbekistan  For Israel OANATEL022 OANATEL022  For Mozambique OANATEL209 OANATEL209 OANATEL023 OANATEL023  For South Korea  For Thailand OANATEL210 OANATEL210 OANATEL208 OANATEL208 7-151...
Page 525: Emergency Situations
8. Emergency situations Hazard warning flasher..................8-3 In case of an emergency while driving ............8-3 If the engine stalls while driving .................8-3 If the engine stalls at a crossroad or crossing ............8-3 If the engine will not start ................8-4 If the engine doesn’t turn over or turns over slowly ..........
Page 526 Emergency commodity .................. 8-35 Pan-European eCall System ................8-36 Information on data processing ................8-38 Pan-European eCall System ..................8-40...
Page 527: Hazard Warning Flasher
• Turn on your hazard warning flasher. • Try to start the engine again. If your vehicle will not start, we recommend that you contact an authorized HYUNDAI dealer. OOS080006L OOS080006L The hazard warning flasher serves as If the engine stalls at a crossroad...
Page 528: If The Engine Will Not Start
• Check the fuel level and add fuel if traffic. necessary. • When changing a flat tire, follow the If the engine still does not start, we instructions provided later in this recommend that you call an authorized chapter. HYUNDAI dealer for assistance.
Page 529: Jump Starting
JUMP STARTING Jump starting can be dangerous if done If acid gets into your eyes, flush your incorrectly. Follow the jump starting eyes with clean water for at least 15 procedure in this section to avoid serious minutes and get immediate medical injury or damage to your vehicle.
Page 530 In this event please seek qualified assistance. If the cause of your battery discharging is not apparent, we recommend that you have your vehicle checked by an authorized HYUNDAI dealer. Disconnect the jumper cables in the exact reverse order you connected them: 1.
Page 531: If The Engine Overheats
HYUNDAI dealer. from it when you stop.) • When the engine overheats from 5. If engine coolant is leaking out,...
Page 532 ON position or engine is running, fuel efficiency and tire tread life, and or if it comes on after blinking for may affect the vehicle’s handling and approximately one minute, we stopping ability. recommend that you contact an authorized HYUNDAI dealer.
Page 533: Tpms (Tire Pressure Monitoring System) Malfunction Indicator
We recommend that the system be after restarting and about 10 minutes of checked by an authorized HYUNDAI continuous driving before you have the dealer. low pressure tire repaired and replaced on the vehicle.
Page 534: Changing A Tire With Tpms
HYUNDAI dealer. initiated and we recommend that the TPMS sensor on the original mounted wheel be deactivated by a HYUNDAI CAUTION dealer. It is recommended that you do not If the TPMS sensor on the original...
Page 535 CAUTION WARNING We recommend that you use the For EUROPE sealant approved by HYUNDAI if your • Do not modify the vehicle, it may vehicle is equipped with a Tire Pressure interfere with the TPMS function. Monitoring System. The liquid sealant •...
Page 536: Check Tire Pressure
Emergency situations TIRE PRESSURE MONITORING SYSTEM (TPMS) (IF EQUIPPED) (TYPE B) Check tire pressure OOS060047 OOS060047 OOS080005L OOS080005L • You can check the tire pressure in the Assist mode on the cluster. Refer to the “LCD Display Modes” in chapter 4. •...
Page 537: Tire Pressure Monitoring System
HYUNDAI dealer. them to the proper pressure. Driving on 1. The low tire pressure telltale/TPMS a significantly under-inflated tire causes...
Page 538: Low Tire Pressure Position Telltale And Tire Pressure Telltale
Emergency situations Low tire pressure telltale NOTICE The spare tire is not equipped with a tire pressure sensor. Low tire pressure position telltale and CAUTION tire pressure telltale In winter or cold weather, the low tire pressure telltale may illuminate if the tire pressure was adjusted to the recommended tire inflation pressure in warm weather.
Page 539: Tpms (Tire Pressure Monitoring System) Malfunction Indicator
If you have a flat tire, the low Tire We recommend that you have the Pressure and Position telltales will come system checked by an authorized HYUNDAI dealer as soon as possible. We recommend that you have the flat tire repaired by an authorized HYUNDAI NOTICE dealer as soon as possible or replace the flat tire with the spare tire.
Page 540 TPMS malfunctions. Tampering It is recommended that the tire be with, modifying, or disabling the Tire serviced by an authorized HYUNDAI Pressure Monitoring System (TPMS) dealer and replace it with the original components may void the warranty for tire wheel equipped with a tire that portion of the vehicle.
Page 541: Jack And Tools
IF YOU HAVE A FLAT TIRE (WITH SPARE TIRE, IF EQUIPPED) WARNING Changing a tire can be dangerous. Follow the instructions in this section when changing a tire to reduce the risk of serious injury or death. CAUTION Be careful as you use the jack handle to stay clear of the flat end.
Page 542: Changing Tires
Emergency situations Changing tires WARNING A vehicle can slip or roll off of a jack causing serious injury or death to you or those nearby. Take the following safety precautions: • Do not get under a vehicle that is supported by a jack. •...
Page 543   Front Front   Rear Rear     OOS067018 OOS067018 OOS067020 OOS067020 8. Insert the jack handle into the jack 7. Place the jack at the designated and turn it clockwise, raising the jacking position under the frame vehicle until the tire clears the ground.
Page 544 11~13 kgf·m hub. We recommend that you consult (79~94 lbf·ft). an authorized HYUNDAI dealer for assistance. If you have a tire gauge, check the tire pressure (see “Tires and Wheels” in If any of the equipment such as the jack, chapter 2 for tire pressure instructions.).
Page 545 NOTICE WARNING When the original tire and wheel are To prevent compact spare tire failure repaired and reinstalled on the vehicle, and loss of control possibly resulting in the lug nut torque must be set correctly. an accident: The correct lug nut tightening torque is •...
Page 546: Jack Label
Emergency situations Jack label   Example Example   OOS067043 OOS067043 The actual Jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack. 1. Model Name 2. Maximum allowable load 3.
Page 547: Ec Declaration Of Conformity For Jack
EC Declaration of conformity for Jack JACKDOC14S JACKDOC14S 8-23...
Page 548: If You Have A Flat Tire (With Tire Mobility Kit)
For this reason, you should avoid abrupt HYUNDAI dealer. steering or other driving maneuvers, especially if the vehicle is heavily loaded CAUTION or if a trailer is in use.
Page 549: Components Of The Tire Mobility Kit
Components of the Tire Mobility Kit ODE067044 ODE067044 1. Speed-restriction label 2. Sealant bottle and label with speed restriction 3. Filling hose 4. Connectors and cable for the power outlet direct connection 5. Holder for the sealant bottle 6. Compressor 7.
Page 550: Using The Tire Mobility Kit When A Tire Is Flat
Emergency situations 1. Shake the sealant bottle (2). WARNING Sealant • Keep out of reach of children. • Avoid contact with eyes. • Do not swallow. Using the Tire Mobility Kit when a tire is flat CAUTION OIGH067042 OIGH067042 2. Connect the filling hose (3) to the sealant bottle (2) in the direction of (A) and connect the sealant bottle to the compressor (6) in the direction of (B).
Page 551 WARNING Carbon monoxide Do not leave your vehicle running in a poorly ventilated area for extended periods of time. Carbon monoxide poisoning and suffocation can occur. OOS080002K OOS080002K 5. Plug the compressor power cord (4) into the vehicle power outlet. NOTICE Only use the front passenger side power outlet when connecting the...
Page 552 Use of the TMK may be ineffectual for tire damage larger than approximately 4 mm (0.16 in). We recommend that you contact an authorized HYUNDAI dealer if the tire cannot be made roadworthy with the Tire Mobility Kit. WARNING OOS067011...
Page 553: How To Adjust Tire Pressure
NOTICE How to adjust tire pressure Do not let the compressor run for more than 10 minutes, otherwise the device will overheat and may be damaged. Information The pressure gauge may show higher than actual reading when the compressor is running.
Page 554: Notes On The Safe Use Of The Tire Mobility Kit
Tire Mobility Kit, we such as kidney, etc. recommend that you contact an authorized HYUNDAI dealer. • Do not use the Tire Mobility Kit if a tire is severely damaged by driving run flat or with insufficient air pressure.
Page 555: Towing
OOS067007L [A] : Dollies If emergency towing is necessary, we recommend having it done by an authorized HYUNDAI dealer or a commercial tow-truck service. Proper lifting and towing procedures are necessary to prevent damage to the vehicle. The use of wheel dollies or...
Page 556: Removable Towing Hook
Emergency situations Removable towing hook WARNING 1. Open the tailgate, and remove the If your vehicle is equipped with a towing hook from the tool case. rollover sensor, place the ignition switch in the LOCK/OFF or ACC position   Front Front ...
Page 557: Emergency Towing
If towing is necessary, we recommend • Fasten the towing cable or chain you have it done by an authorized securely to the hook. HYUNDAI dealer or a commercial tow truck service. • Do not jerk the hook. Apply steady and even force.
Page 558 Emergency situations NOTICE To avoid damage to your vehicle and vehicle components when towing: • Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. • Do not use the towing hooks to pull a vehicle out of mud, sand or other conditions from which the vehicle cannot be driven out under its own...
Page 559: Fire Extinguisher
EMERGENCY COMMODITY (IF EQUIPPED) Your vehicle is equipped with emergency Tire pressure gauge commodities to help you respond to (if equipped) emergency situation. Tires normally lose some air in day-to- day use, and you may have to add a air Fire extinguisher periodically and usually it is not a sign of If there is small fire and you know how...
Page 560: Pan-European Ecall System
Emergency situations PAN-EUROPEAN ECALL SYSTEM (IF EQUIPPED) The vehicle is equipped with a device* connected with the Pan-European eCall system for making emergency call to response teams. The Pan-European eCall system is an automatic emergency call service made in event of a traffic accident or other** accidents on the roads of Europe.
Page 561 Once the data which is stored in the Pan-European eCall system is delivered to the rescue center to assist the driver and passengers with proper rescue operations, the data will be deleted after rescue operation is completed. Description of the eCall in-vehicle system ESKEV-501 ESKEV-501 Overview of the 112-based eCall in-vehicle system, its operation and functionalities:...
Page 562: Information On Data Processing
Emergency situations Information on data processing (1) Directive 95/46/EC of the European Parliament and of the Council of Any processing of personal data 24 October 1995 on the protection through the 112-based eCall in-vehicle of individuals with regard to the system shall comply with the personal processing of personal data and on data protection rules provided for in...
Page 563 Arrangements for data processing Modalities for exercising data subject’s rights The 112-based eCall in-vehicle system is designed in such a way as to ensure The data subject (the vehicle’s owner) that the data contained in the system has a right of access to data and as memory is not available outside the appropriate to request the rectification, system before an eCall is triggered.
Page 564: Pan-European Ecall System
Emergency situations Pan-European eCall System SOS button: The driver/passenger makes an   Type A Type A   emergency call to the single duty dispatch service by pressing the button. LED: The red and green LED illuminates for 3 seconds when the ignition switch is in the ON position.
Page 565 Automatic accident reporting System operation in the System operation in the Connection with the Public Connection with the Public Emergency services Emergency services event of a traffic accident event of a traffic accident Safety Answering Point Safety Answering Point (PSAP) (PSAP) OOS080010L OOS080010L...
Page 566 Emergency situations Manual accident reporting OOS080010L OOS080010L The driver or passenger manually can make an emergency call in the Public Safety Answering Point(PSAP), by pressing SOS button to call the necessary emergency services. A call to the emergency services through the Pan-European eCall system can be cancelled by pressing the SOS button again within 3 seconds.
Page 567 If red LED illuminates in normal driving conditions, this can indicate malfunction of the Pan-European eCall system. We recommend that system be checked by an authorized HYUNDAI dealer. Otherwise correct operation of the Pan- European eCall system device, installed in your vehicle is not guaranteed.
Page 568: Maintenance
9. Maintenance Engine compartment ..................9-3 Maintenance services ..................9-6 Owner’s responsibility ....................9-6 Owner maintenance ..................9-7 Owner maintenance schedule ..................9-7 Scheduled maintenance services ..............9-9 Normal maintenance schedule (for Europe) ............9-10 Maintenance under severe usage and low mileage conditions (Gasoline engine, for Europe) ..................
Page 569 Climate control air filter.................. 9-39 Blade inspection ......................9-40 Blade replacement ....................9-40 Wiper blades ....................9-40 Battery ......................9-43 For best battery service .................... 9-44 Battery capacity label ....................9-44 Battery recharging ....................9-44 Reset items ........................ 9-45 Tire care ........................9-46 Recommended cold tire inflation pressures ............
Page 570: Engine Compartment
ENGINE COMPARTMENT   Smartstream G1.0 T-GDi Smartstream G1.0 T-GDi     Smarstream G1.0 T-GDI (48V) MHEV Smarstream G1.0 T-GDI (48V) MHEV   The actual engine compartment in the vehicle may differ from the illustration. OOS090047L/OOS090020L OOS090047L/OOS090020L 1.
Page 571 Maintenance   Smartstream G1.6 T-GDi (including N Line) Smartstream G1.6 T-GDi (including N Line)     Smartstream G2.0 Atkinson (Except Europe) Smartstream G2.0 Atkinson (Except Europe)   The actual engine compartment in the vehicle may differ from the illustration. OOS090002K/OOS090001K OOS090002K/OOS090001K 1.
Page 572   Smartstream D1.6 (48V) MHEV Smartstream D1.6 (48V) MHEV   The actual engine compartment in the vehicle may differ from the illustration. OOS090022L OOS090022L 1. Engine coolant reservoir/ 5. Air cleaner Engine coolant cap 6. Engine oil dipstick 2.
Page 573: Maintenance Services
Such modifications may standards and receives technical support adversely affect the performance, safety from HYUNDAI in order to provide you or durability of your vehicle and may, in with a high level of service satisfaction. addition, violate conditions of the limited warranties covering the vehicle.
Page 574: Owner Maintenance
• Check for low or under-inflated tires. The following lists are vehicle checks and inspections we recommend to be WARNING checked by an authorized HYUNDAI dealer at the frequencies indicated to Be careful when checking your engine help ensure safe, dependable operation coolant level when the engine is hot.
Page 575 Maintenance While operating your vehicle: • At least twice a year: (i.e., every Spring and Autumn) • Note any changes in the sound of the exhaust or any smell of exhaust fumes • Check radiator, heater and air in the vehicle. conditioning hoses for leaks or damage.
Page 576: Scheduled Maintenance Services
SCHEDULED MAINTENANCE SERVICES Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. • Repeated driving short distance of less than 8 km (5 miles) in normal temperature or less than 16 km (10 miles) in freezing temperature •...
Page 577 Maintenance 9-10...
Page 578 9-11...
Page 579 Maintenance 9-12...
Page 580 9-13...
Page 581: Maintenance Under Severe Usage And Low Mileage Conditions
Maintenance Maintenance Under Severe Usage and Low Mileage Conditions (Gasoline Engine, for Europe) The following items must be serviced more frequently on cars mainly used under severe and low mileage driving conditions. Refer to the chart below for the appropriate maintenance intervals.
Page 582 Maintenance Driving Maintenance item Maintenance intervals operation condition Dual clutch transmission Every 120,000 km C, D, E, F, G, fluid (80,000 miles) H, I, J Rear differential oil Every 120,000 km C, D, E, G, H, (4WD) (80,000 miles) I, J Every 120,000 km C, D, E, G, H, Transfer case oil (4WD)
Page 583: (Diesel Engine, For Europe)
Maintenance Maintenance Under Severe Usage and Low Mileage Conditions (Diesel Engine, for Europe) The following items must be serviced more frequently on cars mainly used under severe and low mileage driving conditions. Refer to the chart below for the appropriate maintenance intervals.
Page 584 Maintenance Driving Maintenance item Maintenance intervals operation condition Replace more frequently Climate control air filter C, E, G depending on the condition Every 120,000 km (80,000 C, D, E, F, G, Manual transmission fluid miles) H, I, J Dual clutch transmission Every 120,000 km (80,000 C, D, E, F, G, fluid...
Page 585 Maintenance 9-18...
Page 586 9-19...
Page 587 Maintenance 9-20...
Page 588 9-21...
Page 589 Maintenance Maintenance Under Severe Usage and Low Mileage Conditions (Gasoline Engine, except Europe) The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance item...
Page 590 Maintenance Maintenance item Maintenance intervals Driving condition operation Climate control air Replace more frequently C, E, G filter depending on the condition Manual transmission fluid/Intelligent Every 120,000 km C, D, E, F, G, H, I, J manual transmission (80,000 miles) fluid Intelligent Variable Every 90,000 km...
Page 591: Explanation Of Scheduled Maintenance Items
HYUNDAI dealer. Drive belts Fuel filter (for gasoline) Inspect all drive belts for evidence HYUNDAI gasoline vehicle is equipped of cuts, cracks, excessive wear or oil a lifetime fuel filter that integrated with saturation and replace if necessary. Drive the fuel tank.
Page 592 Air cleaner filter We recommend that the Intelligent We recommend that the air cleaner filter variable transmission fluid is changed by be replaced by an authorized HYUNDAI an authorized HYUNDAI dealer according dealer. to the maintenance schedule. Spark plugs (for Gasoline Engine)
Page 593 For more information on checking the pads or lining wear limit, refer to the Check the air conditioning lines and HYUNDAI web site. connections for leakage and damage. (http://service.hyundai-motor.com) Suspension mounting bolts Check the suspension connections for looseness or damage.
Page 594: Engine Oil
ENGINE OIL Checking the engine oil level 5. Pull the dipstick out again and check the level. The level should be between (Gasoline engine) F (Full) and L (Low).   Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi /  ...
Page 595 Maintenance • To keep the engine in optimal   Smartstream G1.0 T-GDi / Smartstream G1.0 T-GDi /   Smartstream G1.0 T-GDi (48V) MHEV Smartstream G1.0 T-GDi (48V) MHEV condition, use recommended engine oil. If not using the recommended oil, replace it according to the severe usage maintenance conditions.
Page 596 Required action When mixed with debris, it can cause Recommend to contact engine damage. Range (A) an authorized HYUNDAI • Oil consumption may increase while dealer. you break in a new vehicle and it will Range (B) Do not refill engine oil.
Page 597: Checking The Engine Oil And Filter
We recommend that the engine oil (Refer to “Recommended lubricants and filter be replaced by an authorized and capacities” in chapter 2.) HYUNDAI dealer. WARNING • Used engine oil may cause irritation or cancer of the skin if left in contact with the skin for prolonged periods of time.
Page 598: Checking The Engine Coolant Level
If the coolant level is low, add enough distilled (deionized) water. Bring the level to MAX, (or F (Full)) but do not overfill. If frequent additions are required, we recommend that the system be inspected by an authorized HYUNDAI dealer. 9-31...
Page 599 Maintenance   Gasoline engine Gasoline engine   WARNING The electric motor for the cooling fan may continue to operate or start up when the engine is not running and can cause serious injury. Keep hands, clothing and tools away from the rotating fan blades of the cooling fan.
Page 600: Changing The Engine Coolant
• When adding coolant, use only We recommend that coolant be changed distilled (deionized) water for your by an authorized HYUNDAI dealer vehicle and never mix hard water in according to the Maintenance Schedule the coolant filled at the factory. An at the beginning of this chapter.
Page 601: Checking The Brake/Clutch Fluid Level
WARNING If the brake/clutch system requires frequent additions of fluid this could indicate a leak in the brake/clutch system. We recommend that the vehicle be inspected by an authorized HYUNDAI dealer. OOS090011K OOS090011K Check the fluid level in the reservoir WARNING periodically.
Page 602: Checking The Imt System Actuator Fluid Level
If the oil level is below MIN mark, have the vehicle checked by a professional workshop. We recommend that you contact an authorized HYUNDAI dealer/ service partner. Use only the specified iMT system actuator fluid. (Refer to Recommended lubricants or capacities.) Never mix...
Page 603: Checking The Washer Fluid Level
WARNING HYUNDAI dealer. To prevent serious injury or death, take Stroke : 5~7 “clicks’’ at a force of 20 kg the following safety precautions when (44 lbs, 196 N).
Page 604: Fuel Filter (For Diesel)
Fuel filter cartridge replacement We recommend the fuel filter cartridge be replaced by an authorized HYUNDAI dealer according to the Maintenance Schedule at the beginning of this chapter. OOS090015K OOS090015K 1.
Page 605 4. Lock the cover with the cover result. attaching clips. • Use HYUNDAI genuine parts or the 5. Check that the cover is firmly equivalent specified for your vehicle. installed. Use of parts without the matching quality could damage the air flow sensor.
Page 606: Filter Inspection
CLIMATE CONTROL AIR FILTER Filter inspection If the vehicle is operated in the severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier. When you, the owner, replace the climate control air filter, replace it performing the following procedure, and be careful to avoid damaging other components.
Page 607: Blade Inspection
Maintenance WIPER BLADES Blade inspection Blade replacement Contamination of either the windshield When the wipers no longer clean or the wiper blades with foreign matter adequately, the blades may be worn or can reduce the effectiveness of the cracked, and require replacement. windshield wipers.
Page 608 Type A Type B OLF074017 OLF074017 OGSR076067 OGSR076067 1. Raise the wiper arm. OGSR076066 OGSR076066 1. Lift up the wiper blade clip. Then lift up the wiper blade. OLF074018 OLF074018 2. Lift up the wiper blade clip. Then pull 2. While pushing the lock (1), pull down down the blade assembly and remove the wiper blade (2).
Page 609 3. Make sure the blade assembly is installed firmly by trying to pull it slightly. To prevent damage to the wiper arms or other components, we recommend that the wiper blades be replaced by an authorized HYUNDAI dealer. 9-42...
Page 610: Battery
BATTERY • When lifting a plastic-cased battery, WARNING excessive pressure on the case may To prevent SERIOUS INJURY or DEATH cause battery acid to leak. Lift with a to you or bystanders, always follow battery carrier or with your hands on these precautions when working near opposite corners.
Page 611: For Best Battery Service
Maintenance For best battery service 1. CMF60L-BCI : The HYUNDAI model name of battery 2. 12V : The nominal voltage 3. 60Ah(20HR) : The nominal capacity (in Ampere hours) 4. 92RC : The no minal reserve capacity (in min.) 5. 550CCA : The cold-test current in amperes by SAE 6.
Page 612: Reset Items
(3) Unhook the positive clamp from Reset items the positive battery terminal. The following items may need to be reset • Always use a genuine HYUNDAI after the battery has been discharged or approved battery or the equivalent the battery has been disconnected.
Page 613: Tire Care
Maintenance TIRES AND WHEELS Tire care WARNING For proper maintenance, safety, and Tire failure may cause loss of vehicle maximum fuel economy, you must control resulting in an accident. To always maintain recommended tire reduce risk of SERIOUS INJURY or inflation pressures and stay within the DEATH, take the following precautions: load limits and weight distribution...
Page 614: Check Tire Inflation Pressure
If you overfill the tire, release air by recommend it be checked by an pushing on the metal stem in the authorized HYUNDAI dealer. center of the tire valve. Recheck the tire • Over-inflation produces a harsh ride, pressure with the tire gauge. Be sure...
Page 615: Tire Rotation
Maintenance Tire rotation WARNING To equalize tread wear, HYUNDAI • Do not use the compact spare tire for recommends that the tires be rotated tire rotation. every 12,000 km (7,500 miles) or sooner • Do not mix bias ply and radial ply if irregular wear develops.
Page 616: Tire Replacement
• Tires degrade over time, even when they are not being used. Regardless of the remaining tread, HYUNDAI recommends that tires be replaced after six (6) years of normal service. OLMB073027 OLMB073027 •...
Page 617: Wheel Replacement
Maintenance Wheel replacement When replacing the metal wheels for any 5, 6 5, 6 reason, make sure the new wheels are equivalent to the original factory units in diameter, rim width and offset. Tire traction Tire traction can be reduced if you drive on worn tires, tires that are improperly inflated or on slippery road surfaces.
Page 618 3. Checking tire life Wheel size designation (TIN : Tire Identification Number) Wheels are also marked with important information that you need if you ever Any tires that are over six years old, have to replace one. The following based on the manufacturing date, explains what the letters and numbers in (including the spare tire) should be the wheel size designation mean.
Page 619 Maintenance 5. Maximum permissible inflation Tread wear pressure The tread wear grade is a comparative rating based on the wear rate of the tire This number is the greatest amount when tested under controlled conditions of air pressure that should be put in on a specified government test course.
Page 620: Low Aspect Ratio Tires
The temperature grade for this tire is recommend to contact an authorized established for a tire that is properly HYUNDAI dealer. inflated and not overloaded. Excessive speed, under-inflation, over-inflation, • Inspect the tire condition and...
Page 621: Fuses
Cartridge type   indicates an electrical problem. Avoid using the system involved. We recommend that you immediately consult an authorized HYUNDAI dealer. Information   Multi fuse Multi fuse   Three kinds of fuses are used: blade type...
Page 622: Instrument Panel Fuse Replacement
If it fits loosely, we recommend to have the system checked by an authorized HYUNDAI dealer. In an emergency, if you do not have a spare fuse, use a fuse of the same rating from a circuit you may not need for operating the vehicle, such as the cigarette lighter fuse.
Page 623 If it fits loosely, we recommend to have the system checked by an NOTICE authorized HYUNDAI dealer. • Always place the fuse switch in the ON position while driving the vehicle. NOTICE • Do not move the transportation fuse After checking the fuse panel in the switch repeatedly.
Page 624 6. Reinstall in the reverse order of Information removal. If the main fuse is blown, we recommend that you consult an authorized HYUNDAI If the multi fuse is blown, we recommend dealer. that you consult an authorized HYUNDAI dealer.
Page 625 Maintenance Fuse/Relay panel description Information Driver’s side fuse panel Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label.
Page 626 Driver’s side fuse panel Fuse Symbol Circuit Protected Fuse Name Rating Emergency Call (E-Call) Module, Front Wireless Charger Unit, ATM Shift Lever IND., Driver Console Switch, Electro Chromic , Mirror, Audio, A/V & Navigation Head Unit, 1.5A MODULE5 MODULE Low ISG Converter, Data Link Connector, AMP, Crash Pad Switch, Head Lamp LH/RH, A/C Control Module, Front/Rear Seat Warmer Control Module, Front Air Ventilation Control Module...
Page 627 Maintenance Driver’s side fuse panel Fuse Symbol Circuit Protected Fuse Name Rating ICM Relay Box (Burglar Alarm Horn Relay) B/A HORN A/C Control Module, Rain Sensor, Electro Chromic Mirror, Head Up, Display, Instrument Cluster, Dirver Console Switch, MEMORY1 MEMORY Blind-Spot, Collision Warning Unit LH/RH, ICM Relay Box (Outside Folding/Unfoling Relay) Rear Seat Warmer Control Module S/HEATER RR...
Page 628 Driver’s side fuse panel Fuse Symbol Circuit Protected Fuse Name Rating Front Seat Warmer Module, S/HEATER Front Air Ventilation Seat Module A/C Control Module A/CON SW A/C Control Module, E/R Junction Block 7.5A (RLY.1, RLY.10, RLY.11 RLY.13) Smart Key Control Module, PDM1 Start/Stop Button Switch Spare...
Page 629 Maintenance Engine compartment fuse panel Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label. OOS090034L OOS090034L Inside the fuse/relay box covers, you can...
Page 630 Engine compartment fuse panel Symbol Relay Name Relay No. PTC Heater #2 Relay RLY.1 Cooling Fan #2 Relay RLY.2 PDM #3 (IG1) Relay RLY.3 (IG1) Srart #1 Relay RLY.4 Fuel Filter Heater Relay RLY.5 PDM #4 (IG2) Relay RLY.6 (IG2) FUEL Fuel Pump Relay RLY.7...
Page 631 Maintenance Engine compartment fuse panel Fuse Symbol Fuse Rating Circuit Protected Type Name 180A (G4FJ/D4FE) E/R Junction Block (Fuse - F19, F20, F21, MAIN MAIN 150A F22, F23, F24-1, F24-2, F25), Alternator MULTI (G3LE/G4FP) FUSE-1 MDPS Unit MDPS PCB Block (Fuse - F1, F2, F3, F6), BATT5 Engine Control Relay) IGPM ((Fuse - F30), IPS0, IPS1, IPS2)
Page 632 Engine compartment fuse panel Fuse Symbol Circuit Protected Type Fuse Name Rating CLUTCH Electronic Clutch Module ACTUATOR 2 CLUTCH Electronic Clutch Module ACTUATOR 1 VACUUM Vacuum Pump V/PUMP PUMP FUEL E/R Junction Block (RLY.7) F/PUMP PUMP IGPM ((Fuse - F21, F24, F27, F28, BATT1 F33), Leak Current Autocut Device) DCT1...
Page 633 Maintenance Engine compartment fuse panel Fuse Symbol Circuit Protected Type Fuse Name Rating CVVD Actuator CVVD Electronic Oil Pump FUSE E/R Junction Block (RLY.14) E/R Junction Block (RLY.5) F/FILTER Glow Relay Unit GLOW [D4FE/G3LE/G4FP] Cooling Fan COOLING FAN2 Motor MULTI E/R Junction Block (RLY.11) PTC1 FUSE-3...
Page 634 Engine compartment fuse panel (PCB Block) Fuse Symbol Circuit Protected Fuse Name Rating A/CON PCB Block (A/C Comp Relay) COMP PCB Block (Horn Relay) HORN ECM/PCM ECU3 Not Used SPARE [G4FP/G4NJ] Ignition Coil #1/#2/#3/#4 IGN COIL [G3LE] Ignition Coil #1/#2/#3 [D4FE] Front Nox Sensor, Rear Nox Sensor, PM (Particulate Matter) Sensor ECM/PCM...
Page 635 Maintenance Engine compartment fuse panel (PCB Block) Fuse Fuse Name Symbol Circuit Protected Rating [G4NJ] Electronic Oil Pump SENSOR4 [D4FE] Disel Heater, Glow Relay Unit SENSOR2 [D4FE] Disel Heater, Glow Relay Unit [G4FP/G3LE] Purge Control Solenoid Valve, Variable Oil Pump, Oil Control Valve #1 (Intake), Oil Control Valve #2 (Exhaust), RCV Control Solenoid, E/R Junction Block (RLY.
Page 636 Engine compartment fuse panel Information (Battery terminal cover) Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
Page 637: Light Bulbs
Maintenance LIGHT BULBS We recommend that you consult an Information authorized HYUNDAI dealer to replace The headlamp and tail lamp lenses could most vehicle light bulbs. It is difficult appear frosty if the vehicle is washed after to replace vehicle light bulbs because...
Page 638: Headlamp, Position Lamp, Turn Signal Lamp And Daytime Running Light Bulb Replacement
Headlamp, position lamp, turn • Always handle them carefully, and avoid scratches and abrasions. If signal lamp and daytime running the bulbs are lit, avoid contact with light bulb replacement liquids. Type A • Never touch the glass with bare hands.
Page 639 8. Install the bulb cover by turning it clockwise. Daytime running light and position lamp If the LED lamp does not operate, we recommend that you have the vehicle checked by an authorized HYUNDAI dealer. OLMB073042L OLMB073042L • Handle halogen bulbs with care.
Page 640: Front Fog Lamp
If the LED lamp does not operate, we 2. Reach your hand into the back of the recommend that you have the vehicle front bumper. checked by an authorized HYUNDAI dealer. 3. Disconnect the power connector from the socket. 4. Remove the bulb-socket from the housing (1) by turn the socket align with the slots of the housing.
Page 641: Headlamp And Front Fog Lamp Aiming (For Europe)
Maintenance Headlamp and front fog lamp Front fog lamp aiming aiming (for Europe) Headlamp aiming   Bulb type Bulb type   LED type LED type     OOS090058L OOS090058L The front fog lamp can be aimed as the same manner of the headlamps aiming.
Page 642 Aiming point   Halogen lamp Halogen lamp     LED lamp LED lamp   OOS070048L/OOS070049L OOS070048L/OOS070049L H1 : Height between the head lamp bulb center and ground (Low beam) H1 : Height between the head lamp bulb center and ground (Low beam) H2 : Height between the head lamp bulb center and ground (High beam) H2 : Height between the head lamp bulb center and ground (High beam) H3 : Height between the fog lamp bulb center and ground...
Page 643 Maintenance Headlamp low beam (LHD side)   Based on 10m screen Based on 10m screen   OPDE076082 OPDE076082 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3.
Page 644 Headlamp low beam (RHD side)   Based on 10m screen Based on 10m screen   OPDE076083 OPDE076083 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3.
Page 645 Maintenance Front fog lamp   Based on 10m screen Based on 10m screen   1. Vertical line of the left fog lamp bulb center 2. Horizontal line of fog lamp bulb center 3. Cut-off line 4. Car axis 5.
Page 646: Side Repeater Lamp Replacement
If the light bulb does not operate, we OOS090018K OOS090018K recommend that you have the vehicle   Type B (LED) Type B (LED)   checked by an authorized HYUNDAI dealer. OOS090018K OOS090018K OOS090036L OOS090036L (1) Stop/Tail lamp (2) Tail lamp(Type A),...
Page 647 Maintenance OOS077066L OOS077066L OOS077068L OOS077068L 4. Remove the rear combination lamp Stop/Tail lamp assembly from the body of the 1. Turn off the engine. vehicle. 2. Open the tailgate. 5. Remove the socket from the 3. Loosen the lamp assembly retaining assembly by turning the socket screws with a cross-tip screwdriver.
Page 648: High Mounted Stop Lamp Replacement
Tail / Stop lamp (Type B) If the LED lamp does not operate, we recommend that you have the vehicle checked by an authorized HYUNDAI dealer. Turn signal lamp / Back up lamp / Rear fog lamp If these lamps do not operate, we...
Page 649: License Plate Light Bulb Replacement
Maintenance License plate light bulb Interior light bulb replacement replacement Map lamp, room lamp, vanity mirror lamp and luggage compartment lamp   Map lamp (Type A) Map lamp (Type A)   OOS077043 OOS077043 1. Using a flat-blade screwdriver, gently pry the lens cover from the lamp OOS077053 OOS077053...
Page 650   Room lamp (Type A) Room lamp (Type A)   Glove box lamp Glove box lamp     OOS077054 OOS077054 OOS077047 OOS077047   Room lamp (Type B) Room lamp (Type B)   1. Using a flat-head screwdriver, gently pry the lens from the interior light housing.
Page 651: Exterior Care
Maintenance APPEARANCE CARE Exterior care Even prompt washing with plain water may not completely remove all these deposits. NOTICE A mild soap, safe for use on painted If you park your vehicle near a stainless surfaces, may be used. steel sign or glass facade building, the After washing, rinse the vehicle vehicle’s exterior plastic parts such thoroughly with lukewarm or cold water.
Page 652 NOTICE High-pressure washing • When using high-pressure washers, Matte paint finish vehicle (if equipped) make sure to maintain sufficient Automatic car wash which uses rotating distance from the vehicle. brushes should not be used as this can Insufficient clearance or excessive damage the surface of your vehicle.
Page 653 HYUNDAI dealer. Take paint deterioration. extreme care, as it is difficult to restore the quality after the repair.
Page 654 NOTICE Underbody maintenance Corrosive materials used for ice and • Do not use any abrasive cleaner, snow removal and dust control may polishing compound, solvent, or wire collect on the underbody. If these brushes on aluminum wheels. materials are not removed, accelerated •...
Page 655 Maintenance High-corrosion areas To help prevent corrosion If you live in an area where your vehicle is You can help prevent corrosion from regularly exposed to corrosive materials, getting started by observing the corrosion protection is particularly following: important. Some of the common causes of accelerated corrosion are road salts, Keep your vehicle clean dust control chemicals, ocean air and...
Page 656: Interior Care
Keep your garage dry Interior care Don’t park your vehicle in a damp, Interior general precautions poorly ventilated garage. This creates Prevent chemicals such as perfume, a favorable environment for corrosion. cosmetic oil, sun cream, hand cleaner This is particularly true if you wash your and air freshener from contacting the vehicle in the garage or drive it into the interior parts because they may cause...
Page 657 Maintenance Cleaning the upholstery and interior Leather (if equipped) trim • Features of seat leather Vinyl (if equipped) - Leather is made from the outer skin of an animal, which goes through a Remove dust and loose dirt from vinyl special process to be available for with a whisk broom or vacuum cleaner.
Page 658 • Caring for the leather seats Cleaning the lap/shoulder belt webbing - Vacuum the seat periodically to remove dust and sand on the seat. It Clean the belt webbing with any will prevent abrasion or damage of mild soap solution recommended for the leather and maintain its quality.
Page 659: Emission Control System
HYUNDAI dealer in Canister accordance with the maintenance Fuel vapors generated inside the fuel schedule in this manual.
Page 660 3. Exhaust emission control Operating precautions for catalytic converters (if equipped) system The Exhaust Emission Control System is a highly effective system which controls WARNING exhaust emissions while maintaining • A hot exhaust system can ignite good vehicle performance. flammable items under your vehicle. Do not park, idle, or drive the vehicle Engine exhaust gas precautions over or near flammable objects, such...
Page 661 We recommend that all the accumulated soot may reach a inspections and adjustments are certain amount regardless of the soot made by an authorized HYUNDAI oxidization process, then the GPF lamp dealer. will illuminate. • Avoid driving with a very low fuel level.
Page 662 DPF system checked by an authorized HYUNDAI dealer. When the vehicle is continuously driven with the DPF Lamp flashing for an extended period of time, it may damage the DPF system and lower the fuel economy.
Page 663: Selective Catalytic Reduction
Maintenance Selective Catalytic Reduction CAUTION (if equipped) Diesel Fuel (if equipped with DPF) The Selective Catalytic Reduction (SCR) We recommend you to use only the system is to catalytically convert NOx regulated diesel fuels, when your to Nitrogen and Water by using the vehicle is equipped with the DPF reduction agent, the urea solution.
Page 664 Low urea warning message In this case, the tank soon needs to be (if equipped) refilled. The remaining urea in the tank approaches to too low level the warning message “Refill Urea tank or vehicle will not start” with SCR warning lamp ).
Page 665 Otherwise, the vehicle can’t be restarted once the engine is turned off by ignition key. In this case, we recommend that the system be inspected by an authorized HYUNDAI dealer. 9-98...
Page 666 If the vehicle can’t be restarted with “Refill Urea tank or vehicle will not start” message, refill enough urea, wait for minutes and try vehicle starting again. If vehicle starting is not possible regardless of urea level, we recommend that the system be inspected by an authorized HYUNDAI dealer. 9-99...
Page 667 Maintenance Adding the urea solution refill the urea solution from the refill bottle 1. Press the ignition switch to the OFF position 2. Turn the urea solution tank cap in a counterclockwise direction to open it. 3. Fully add the ISO 22241-specified urea solution or above the mark on the urea solution tank.
Page 668 • When the urea solution contacts WARNING with the eyes or the skin, you should • Do not apply any external impact on thoroughly wash the contaminated the DPF system. It may damage the skin area. catalyst, which is equipped inside •...
Page 669 (DIN EN 10 088-1-/-2-/-3-specified to the tank, we recommend you to CR-Ni steel, Mo-Cr-Ni steel, contact an authorized HYUNDAI polypropylene, and polyethylene) dealer. • When any unauthorized impurities enter the urea solution tank, it may occur the following problems.
Page 670 Incorrect urea or diluted urea can WARNING increase the freezing point, and thus • When opening the urea solution tank defrosting may not be properly done cap at high outside temperatures, by the heater which is activated ammonia vapors may escape. below certain temperatures.
Page 671: Index
Index...
Page 672 Index Accessing your vehicle ..................5-5 Immobilizer system ..................5-13 Remote key ......................5-5 Smart key ......................5-8 Air Bag - supplemental restraint system .............. 3-46 Additional safety precautions ................3-64 Air bag warning labels ..................3-64 Do not install a Child Restraint System on the front passenger seat ....3-58 How does the air bags system operate? ............
Page 673 Battery ......................... 9-43 Battery capacity label ..................9-44 Battery recharging .................... 9-44 For best battery service ..................9-44 Recommended cold tire inflation pressures ............ 9-46 Reset items ....................... 9-45 Tire care ......................9-46 Before driving ......................6-4 Before entering the vehicle ................6-4 Before starting ....................
Page 674 Index Child Restraint System (CRS) ................3-32 Installing a Child Restraint System (CRS) ............3-35 Our recommendation: Children always in the rear .......... 3-32 Selecting a Child Restraint System (CRS) ............3-33 Climate control additional features ..............5-85 Automatic ventilation ..................5-85 Cluster ionizer ....................
Page 675 Emergency commodity ..................8-35 Emission control system ..................9-92 Selective Catalytic Reduction ................. 9-96 Engine ........................2-13 Engine compartment .................... 2-10 Engine compartment ....................9-3 Engine coolant ..................... 9-31 Changing the engine coolant ................9-33 Checking the brake/clutch fluid level ............... 9-34 Engine number .....................
Page 676 Operating condition ..................5-55 System malfunction and limitations ..............5-55 Highway Driving Assist (HDA) ................ 7-106 Function malfunction and limitations ............7-110 Function operation ..................7-108 Function settings .................... 7-107 How to use this manual ..................1-3 Hyundai motor company ..................1-2...
Page 677 Idle Stop and Go (ISG) system ................6-59 Activating the ISG ................... 6-59 Condition of ISG system operation ..............6-62 Deactivating the ISG ..................6-59 ISG indication ....................6-63 ISG malfunction ....................6-65 The battery sensor deactivation ................ 6-66 If the engine overheats ................... 8-7 If the engine will not start ..................
Page 678 Index Infotainment system specifications..............5-130 Bluetooth ......................5-131 USB ........................ 5-130 Instrument cluster ....................4-2 Gauges and meters ..................... 4-3 Instrument cluster control ................... 4-3 LCD display messages ..................4-25 Transmission shift indicator ................4-7 Intelligent manual transmission ................6-18 Intelligent manual transmission operation .............
Page 679 Lane Following Assist (LFA) ................7-102 Function malfunction and limitations............7-105 Function operation ..................7-103 Function settings.................... 7-102 Lane Keeping Assist (LKA) ................7-28 Function malfunction and limitations .............. 7-32 Function operation .................... 7-30 Function settings ....................7-28 LCD display ......................
Page 680 Index Maintenance services ..................... 9-6 Owner’s responsibility ..................9-6 Manual climate control system ................5-63 Heating and air conditioning ................5-64 System maintenance ..................5-69 System operation ....................5-67 Manual Speed Limit Assist (MSLA) (for Europe) ..........7-61 System operation....................7-61 Manual transmission ....................
Page 681 Radio ........................5-109 Changing the radio mode ................5-110 Listening to saved radio stations ..............5-111 Saving radio stations ..................5-111 Scanning for available radio stations ............. 5-110 Searching for radio stations ................5-110 Turning on the radio ..................5-109 Rear Cross-Traffic Collision-Avoidance Assist (RCCA) ........7-124 Function malfunction and limitations ............
Page 682 Index Safe Exit Warning (SEW) ................... 7-56 Function malfunction and limitations .............. 7-59 Function operation.................... 7-58 System settings ....................7-57 Safety messages ..................... 1-3 Scheduled maintenance services................9-9 Maintenance under severe usage and low mileage condition (Diesel Engine, for Europe) ................9-16 Maintenance under severe usage and low mileage condition (Gasoline Engine, for Europe) ...............9-22 Maintenance under severe usage and low mileage conditions...
Page 683 Special driving conditions ................... 6-72 Driving at night ....................6-73 Driving in flooded areas ................... 6-74 Driving in the rain .................... 6-73 Hazardous driving conditions ................6-72 Highway driving ....................6-74 Reducing the risk of a rollover ................. 6-74 Rocking the vehicle ..................6-72 Smooth cornering .....................
Page 684 Index Theft-alarm system ....................5-19 Tire Pressure Monitoring System (TPMS) (Type A) ..........8-8 Changing a tire with TPMS ................8-10 Low tire pressure telltale ..................8-9 TPMS (Tire Pressure Monitoring System) malfunction indicator ..... 8-9 Tire Pressure Monitoring System (TPMS) (Type B) ........... 8-12 Changing a tire with TPMS ................
Page 685 Trademarks ......................5-131 Trailer towing (for Europe) .................. 6-79 Driving with a trailer ..................6-84 Maintenance when towing a trailer ..............6-87 Trailer towing equipment ................. 6-83 USB and iPod port .................... 5-97 ® Antenna ......................5-97 Audio / Video / Navigation system (AVN) ............. 5-99 Bluetooth Wireless Technology hands-free ...........
Page 686 Index Washer fluid ......................9-36 Windows ......................5-28 Power windows ....................5-28 Windshield defrosting and defogging ..............5-81 Auto defogging system (only for automatic climate control system) ....5-83 Automatic climate control system ..............5-82 Defroster ......................5-84 Manual climate control system ................ 5-81 Rear window defroster ..................

Hyundai KONA 2021 Owner's Manual

Table of Contents

2. Vehicle Information

3. Safety System

4. Instrument Cluster

5. Convenient Features

6. Driving Your Vehicle

Quick Links

Chapters

Related Manuals for Hyundai KONA 2021

Summary of Contents for Hyundai KONA 2021
