Hyundai KONA
SUV, 5 doors
From April 2023
Optional
48V
12V
Li-ion
Driver only
Li-ion
12V
Seat belt
Stored gas
SRS control unit
Airbag
pretensioner
inflator
Gas strut /
Battery low-
High strength
Preloaded
Fuel tank
voltage
zone
spring
ID No.
Version No.
Version date:
Page
KMH-SX2-RS-I-5-202308
01
08/2023
1 of 4
Advertisement
Related Manuals for Hyundai KONA 2023
Summary of Contents for Hyundai KONA 2023
- Page 1 Hyundai KONA SUV, 5 doors From April 2023 Optional Li-ion Driver only Li-ion Seat belt Stored gas SRS control unit Airbag pretensioner inflator Gas strut / Battery low- High strength Preloaded Fuel tank voltage zone spring ID No. Version No.
- Page 2 1. Identification / recognition Brand Logo Name Model name ① ② Wheel Drive emblem 2. Immobilisation / stabilisation / lifting Immobilization: For automatic vehicles, while depressing the brake pedal shift the lever to P(park) position or press P button to make vehicle in P Chock the wheels and pull the position...
- Page 3 48V [LI ION] Battery: Access: Remove the luggage Remove luggage cover foam Open tailgate Disabling Disconnect 12V battery (shown on page 2) in the hood Wait 10min and get Disconnect 12V (+) Disconnect 48V (-) access to the 48V cable from 48V battery cable and (+) cable in battery shown above pack...
- Page 4 6. In case of fire BATTERY RE-IGNITION! Gas strut! Risk of missile effect of hood and tailgate. Optional Use large amount of water 7. In case of submersion Do not touch any of the 48V components or cables, as doing so poses an electrocution hazard.
