RC SERIES ENGINEERING GUIDE

Model Nomenclature

1-2 3
RC RC S S
Model
RC – RC Series C Ser ie es s
Cabinet Configuration Config gu u uration
C – Chassis Only assis O O On nly
W – Chassis with Cabinet assis w w ith Cabinet
S – Chassis Slope Top assis S Sl lo ope Top
E – Chassis with Extended assis w w it th Extended
Slope Top pe Top p
Unit Capacity acity
09, 12, 15, 18 15, 18 8
Piping Option ption
L – Left
R – Right ht
Voltage
0 – 208-230/60/1 60/1
2 – 265/60/1
9 – 115/60/1 (09 & 12) (09 & 12)
Unit Control
1 – CCM
TM
A – Aurora Base Control (ABC)
TM
Z – Aurora with SMART Equipment DDC
NOTES:
Chassis only available with left piping option.
SMART Equipment option is only available with remote wall-mounted thermostat control.
4-5 6 7 8 9 10
09 L 0 1 1 C
All RC Series product is Safety listed under UL1995 thru ETL and performance listed with AHRI in
accordance with standard 13256-1.
11 12 13 14 15-16 17
N N B 5 SS
4
*
Vintage
* – Internal Factory Use Only
Non-Standard Option Details
SS – Standard Option
Air Coil/Insulation Option
TM
5 – AlumiSeal /Extended Range
TM
6 – AlumiSeal /Standard Range
7 – No Coating/Extended Range
8 – No Coating/Standard Range
Sound Kit
A – None
B – Blanket
Auxiliary Electric Heat
N – None
B – 1.0kW (09-12)
C – 2.0kW (09-12)
D – 3.0kW (15-18)
Motorized Outside Air Damper
(Field Installed)
N – None
M – Motorized Damper
Water Coil Option
C – Copper
N – CuproNickel
Thermostat Control
1 – Unit Mounted T-Stat
2 – Remote Wall-Mounted T-Stat
