The RC Series Console

High Efficiency
RC Series is the highest efficiency units available. Large
oversized air coils, water to refrigerant heat exchangers and rotary
compressors provide extremely efficient operation. This efficiency
means the RC Series requires less loop than any product on the
market. This can mean significant savings on commercial projects.
Quiet Operation
All RC Series Console product is ARI 350 sound rated using third
party sound testing. Room Noise Criteria Curves (NC Curve)
may be calculated using data from the ARI 350 ratings giving the
engineer total flexibility in assuring a quiet environment.
Standard Features
• Slope and Flat top configurations
• Extended cabinet options
• Footprint matches "legacy" products for easy retrofits.
• Attractive rounded corners heavy gauge cabinet.
• Quiet rotary compressors in all models.
• 2-dimension refrigerant piping vibration loops to isolate
the compressor.
• All interior cabinet surfaces including the compressor
compartment are insulated with 1/2˝ [12.7mm] thick
• 1-1/2lb [681g] density, surface coated, acoustic type glass
fiber insulation.
Easy Maintenance and Service Advantages
• 2 removable compressor access panels
• Separate air handler and compressor section access panels
permit service testing without bypass.
• Easy access to low voltage connector for easy thermostat wiring
(remote & thermostat option).
• Quick attach wiring harnesses are used throughout for
fast servicing.
• High and low pressure refrigerant service ports.
• Internal slide out blowers.
Factory Quality
• All refrigerant brazing is performed in a nitrogen environment.
• Computer controlled deep vacuum and refrigerant
charging system.
• All joints are leak detected for maximum leak rate of less than
1/4 oz. per year.
• Computer bar code equipped assembly line insures all
components are correct.
• All units are computer run-tested with water to verify both
function and performance.
