RC SERIES ENGINEERING GUIDE
Dimensional Data - Flat Top Cabinet
RCW09-18
RIGHT RETURN
FILTER BRACKET
DETAIL B
TWIST EXTENDED TAB
BACK AND FORTH UNTIL
TAB BREAKS OFF
(ONLY BREAK-OFF
TAB OPPOSITE AS
GRILLE LID AS SHOWN)
REMOVE PLASTIC STRIP
FROM BROKEN TAB AND
REPLACE ON BROKEN
EDGE OF LEG AS SHOWN
D
A
Overall Cabinet
Flat Top
A B
Configuration
Width Depth Height Grille Lid
in. 45.0 10.8
09-12
cm. 114.3 27.3
in. 50.0 12.3
15-18
cm. 127.0 31.1
TOP
F
E
A
C
H
FRONT
C D E F
Grille Grille
Length Width
25.7 9.2 35.0 6.1
65.2 23.4 88.9 15.6
25.7 9.2 35.0 6.1
65.2 23.4 88.9 15.6
24
B
B
G
FILTER BRACKET
J
I
DETAIL B
TWIST EXTENDED
TAB BACK AND
FORTH UNTIL
TAB BREAKS OFF
(ONLY BREAK-OFF
TAB OPPOSITE AS
GRILLE LID AS SHOWN)
REMOVE PLASTIC STRIP
FROM BROKEN TAB AND
REPLACE ON BROKEN
EDGE OF LEG AS SHOWN
G H I J
2.3 44.1 10.3 4.3
5.8 112.0 26.0 10.9
3.3 49.1 11.8 4.3
8.3 124.7 29.8 10.9
LEFT RETURN
