5151094-UIM-H-0220
WARNING
!
Before performing service or maintenance operations on unit, turn off
main power switch to unit. Electrical shock could cause personal
injury. Improper installation, adjustment, alteration, service or mainte-
nance can cause injury or property damage. Refer to this manual.
For assistance or additional information consult a qualified installer,
service agency or the gas supplier.
CAUTION
!
This system uses R-410A Refrigerant which operates at higher pres-
sures than R-22. No other refrigerant may be used in this system.
Gage sets, hoses, refrigerant containers and recovery systems must
be designed to handle R-410A. If you are unsure, consult the equip-
ment manufacturer. Failure to use R-410A compatible servicing
equipment may result in property damage or injury.
SECTION III: MODEL NUMBER NOMENCLATURE
PHE 4
1 2
1. Model Family
PHE - packaged heat pump with electric heat
PCG - packaged A/C with gas heat
PHG - packaged heat pump with gas heat
PCE - packaged A/C with electric heat
2. Nominal Cooling Efficiency
4 = 14 SEER, 6 = 16 SEER
3. Cabinet Size
A = small 35 x 51, B = large 45 x 51
4. Nominal Air Conditioning Cooling Capacity BTUx1000
24 = 24,000 BTU, etc.
Examples:
PHE4B4231A is a packaged heat pump, 14 SEER, large cabinet, 3-1/2 ton, 208/230 V, three-phase model, first generation, first release.
SECTION IV: INSTALLATION
LIMITATIONS
These units must be installed in accordance with the following national
and local safety codes:
• National Electrical Code ANSI/NFPS No. 70 or Canadian Electri-
cal Code Part 1, C22.1 (latest editions)
• Local plumbing and waste water codes and other applicable local
codes
Table 1: Unit Limitations
Model
PHE4B36
PHE4B48
PHE4B60
Table 2: Application Limitations
Air Temperature at Outdoor Coil (°F)
Packaged
Equipment Minimum
Series
DB Cool
14 SEER HP 55
2
A 24
3 4
Unit Voltage
208/230-3-60
208/230-3-60
208/230-3-60
Maximum
DB Heat DB Cool
-10 125
Due to system pressure, moving parts, and electrical components,
installation and servicing of air conditioning equipment can be hazard-
ous. Only qualified, licensed service personnel should install, repair, or
service this equipment. Unlicensed personnel can perform the basic
maintenance functions of cleaning coils and filters and replacing filters.
Observe all precautions in the literature, labels, and tags accompanying
the equipment when working on air conditioning equipment. Install this
product in strict compliance with the installation instructions and any
applicable local, state, and national codes including, but not limited to
building, electrical, and mechanical codes.
Wear safety glasses and work gloves. Use quenching cloth and have a
fire extinguisher available during brazing operations.
INSPECTION
As soon as a unit is received, it should be inspected for possible dam-
age during transit. If damage is evident, the extent of the damage
should be noted on the carrier's freight bill. A separate request for
inspection by the carrier's agent should be made in writing.
REPLACEMENT PARTS
Contact your local Ducted Systems parts distribution center for autho-
rized replacement parts.
3
5 6
5. Gas Heating Input BTU/Hr x 1000
050 = 50,000 BTU/Hr. input, blank = electric heat
6. Voltage-Phase-Frequency
2 = 208/230-1-60, 3 = 208/230-3-60, 4 = 460-3-60
7. NOx Approval
X = low-NOx, blank = not low-NOx
8. Generation Level
1 = first generation
9. Revision Level
A = original release, B = second release
See Tables 3 and 4 for unit physical data and Tables 6, 8, and 9 for
electrical data.
If components are to be added to a unit to meet local codes, they are to
be installed at the dealer's and/or the customer's expense.
The size of the unit for proposed installation must be based on heat
loss/heat gain calculations made in accordance with industry recog-
nized procedures such as the Air Conditioning Contractors of America
(manual J).

Unit Limitations

Applied Voltage
Minimum Maximum
187
187
187
Air Temperature at Indoor Coil (°F)
Minimum
DB Heat WB Cool
75 57
1
7 8
Outdoor DB Temperature
Maximum (°F)
252 125
252 125
252 125
Maximum
DB Heat WB Cool
50 72
Johnson Controls Ducted Systems
A
9
DB Heat
80
