RC SERIES ENGINEERING GUIDE
Dimensional Data - Extended Slope Top Cabinet
RCE09-18
Ext. Slope Top
Configuration
Overall Cabinet
A
B
C
Width Depth Height Grille Lid
in.
50.0 12.6
29.1
09-12
cm.
127.0 32.0
73.9
in.
55.0 12.6
29.1
15-18
cm.
139.7 32.0
73.9
D
E
F
G
Grille
Grille
Length
Width
9.2
35.0
6.1
2.4
49.1 12.0
23.4
88.9
15.6
6.1 124.7 30.5 10.9
9.2
35.0
6.1
2.5
54.1 11.8
23.4
88.9
15.6
6.4 137.4 29.8 10.9
26
H
I
J
4.3
4.3
