Christ Alpha 3-4 LSCbasic Operating Manual page 65

NOTE
Version 11/2018, Rev. 1.9 of 01/12/2021 • sb
Translation of the original operating manuel
The texts of the process and error messages are not included in this
operating manual.
The associated documents can be requested from our service
department.
Dialogue box "Operating mode: select/start" (7)
After the set values have been entered for the process, the process can be
started with this function (see chapter 6.4.2 - "Starting a freeze-drying
process").
Fig. 33: Dialogue box "Operating mode: select/start" (The version of the dialogue box
that is displayed depends on the equipment of the freeze-dryer.)
Button "Standard unit test"
Apart from the process phases of the freeze-drying process ("Freezing",
"Warm-up", "Main drying" and "Final drying") and the operating mode
"Defrosting", the button "Standard unit test" is also available. This button
opens a selection of tests with fixed parameters. After consultation with the
manufacturer, these tests can be performed in order to check the
functionality and processes of the freeze-dryer.
Fig. 34: Dialogue box "Standard unit test"
Freeze-dryer Alpha 3-4 LSCbasic
6 Operation
65 / 117
