Packaging

CAUTION
CAUTION
Pos : 111 /010 Univ ers almodul e/ Leerz eile @ 0\mod_1202116244500_0.docx @ 114 @ @ 1
Pos : 112 /200 Chris t/361 GT-BA Labor-Pil ot ( PROJ EKTE)/Alpha/Al pha 1- 4_2-4_3-4 Standard/Alpha 3-4 LSCbasic/040 Lager ung und Tr ansport/040- 0050 Transportsic herungen Al pha 3- 4 @ 59\m od_1534401501158_68.docx @ 589456 @ 2 @ 1
→
4.5

Transport locking devices

NOTE
Pos : 113 /010 Univ ers almodul e/ Abs chnittswec hs el @ 0 \mod_1202124514062_0.docx @ 418 @ @ 1
Pos : 114 /010 Univ ers almodul e/ Seitenwechs el @ 0\mod_1202116244312_0.docx @ 105 @ @ 1
Version 11/2018, Rev. 1.9 of 01/12/2021 • sb
Translation of the original operating manuel
The freeze-dryer is packaged in a wooden crate.
•
After opening the packaging, take out the accessories.
•
Remove the packaging material.
•
Remove the side walls of the crate.
•
Lift the freeze-dryer upwards and out of the crate/cardboard box. When
lifting the unit, always reach under the freeze-dryer from the side.
The freeze-dryer Alpha 3-4 LSCbasic weighs approx. 86 kg!
The centre of gravity of the freeze-dryer is off-centre!
•
Retain the packaging for any possible future transport of the freeze-
dryer.
Prior to commissioning, the following transport locking devices must be
removed:
•
Install the vacuum sensor that had been removed for transport(see
chapter 5.5 - "Vacuum sensor").
Reinstall the transport locking devices prior to any transport.
Freeze-dryer Alpha 3-4 LSCbasic
4 Storage and transport
41 / 117
