NOTE
Pos : 15 /010 U nivers almodule/ Seitenw ec hsel @ 0\m od_1202116244312_0.docx @ 105 @ @ 1
Version 11/2018, Rev. 1.9 of 01/12/2021 • sb
Translation of the original operating manuel
Solvent package flask, part no. 102492
(without vacuum pump, type Edwards nXDS 10iC):
Name
Freeze-dryer Alpha 3-4 LSCbasic
Capacitive vacuum sensor CMR 364
Corrugated hose, stainless steel
Reducing adapter DN 25/DN 16
Pressure control valve
Vertical manifold with 12 rubber valves
Glass cover
Solvent package universal, part no. 102490
(without vacuum pump, type Edwards nXDS 10iC):
Name
Freeze-dryer Alpha 3-4 LSCbasic
Capacitive vacuum sensor CMR 364
Corrugated hose, stainless steel
Reducing adapter DN 25/DN 16
Pressure control valve
Base plate, stainless steel
Guide tube
3 shelves
Adapter ring
Drying chamber made of real glass
Connecting ring with 12 rubber valves
Glass cover
The freeze-dryer Alpha 3-4 LSCbasic may only be used with a chemical-
resistant, oil-sealed vacuum pump of the type RC6 by Vakuubrand or a
dry-running vacuum pump of the type nXDS 10iC by Edwards and only
with the specified configurations. Otherwise, the CE mark will be rendered
void.
In addition, every package includes:
•
1 tube of high vacuum grease
•
1 litre of vacuum pump oil
•
1 set of small parts
•
1 drain hose 0.4 m (EPDM DN 10, electrically conductive)
•
1 operating manual
Freeze-dryer Alpha 3-4 LSCbasic
1 General information
Part number
102372
125498
510085
141717
125908
110538
121448
Part number
102372
125498
510085
141717
125908
120921
122036
120903
113412
122300
113398
121448
