Xilinx VCK5000 Installation Manual page 19

IMPORTANT! Do not enter Ctrl + c in the terminal while the firmware is flashing as this can cause the
card to become inoperable.
IMPORTANT! If you have multiple cards installed in the system, you must run the above
program command separately for each card.
A message similar to the following will be displayed after successfully flashing the card:
1 device(s) flashed successfully.
****************************************************
Cold reboot machine to load the new image on device(s).
****************************************************
If the card has been flashed with the current platform firmware, you will see a message
similar to the following.
Device(s) up-to-date and do not need to be flashed.
6. Cold boot the machine to load the new firmware image on the FPGA.
IMPORTANT! Be sure to perform a cold boot to fully power off the machine and then power it on
again. The image will not boot from flash if the machine is only rebooted.
7. Update the SC firmware on the card. Run the following command to update the SC firmware
on the card. It is the identical command used to flash the platform firmware on the card.
$ sudo /opt/xilinx/xrt/bin/xbmgmt program --base --device <management
BDF> --image xilinx_vck5000_gen3x16_xdma_base_1
Where management BDF is the card requiring SC firmware update. See
Obtaining Card BDF Values
Updating the SC firmware can take several minutes.
IMPORTANT! If you have multiple cards installed in the system, you must run the above
program command separately for each card.
A message similar to the following will be displayed after a successful SC firmware update,
where the device management BDF is given in square brackets.
Report
[0000:af:00.0] : Successfully flashed
1 device(s) flashed successfully.
******************************************************************
Warm reboot is required to recognize new SC image on the device.
******************************************************************
If the card already has the current firmware, a message similar to the following is displayed
and no additional installation steps are necessary.
Device(s) up-to-date and do not need to be flashed.
8. Warm reboot the system for XRT to recognize the new SC image.
UG1531 (v1.0) March 4, 2022
VCK5000 Hardware Install Guide
Chapter 4: Installing the Deployment Software
to obtain the device management BDF.
xbmgmt
Appendix C:
xbmgmt
