Note
You should refer to the table above and the label attached to the power and I/O cable to wire the
device.

2.2 Indicator Status

The device is equipped with one PWR indicator, one LNK indicator, one ACT indicator, and 2
custom indicators (U1 and U2).
Here we introduce status for all indicators, and you should read it before you use the device. Refer
to Indicator Customization to get the method to set specific functions of the custom indicators.
Device Status
Device is
powered on.
Power supply
exception.
Network
exception.
Device software
exception.
Device exception
Note
When the indicators are flashing slowly, its unlit interval is 1 s.
ID6000 Series Smart Code Reader User Manual
Table 2-2 Description
PWR Indicator
Solid blue Solid green
Unlit
Solid blue Unlit
Solid blue Solid green
Solid blue Solid green
LNK Indicator ACT Indicator
Slow/fast
flashing yellow
Flashing yellow
Solid yellow
4
U1/U2
U1 is unlit, and
U2 is slow
flashing blue.
U1 is unlit, and
U2 is slow
flashing blue.
U1 and U2 are
unlit.
U1 and U2 are
solid blue.
