You can refer to the serial port wiring below to connect the smart code reader with an external
device.
ID6000 Series Smart Code Reader User Manual
Device Power
RS-232 Serial Port
Output
RS-232 Serial Port
Input
Device Power
Ground
Figure 3-11 RS-232 Serial Port Wiring
PWR
GND
9
TX
RX
GND
External
Device
