4.1 Installation Preparation
You need to prepare following accessories before installation.
No.
Name
Power and I/O
1
Cable
2
Network Cable
DC Switch
3
Power Supply
4
Fixed Bracket
5
Lens
6
Light Source
4.2 Install Device
Before You Start
● Make sure the device in the package is in good condition and all the assembly parts are
included.
● Make sure all the related equipment is power-off during the installation.
Steps
Note
Here we take type I device as an example to introduce installation.
1. Use 4 M4 screws to fix the device to the bracket, and select one of installation methods to
install the device to the installation position.
ID6000 Series Smart Code Reader User Manual
Chapter 4 Installation
Table 4-1 Accessories
Quantity
1
1
1
1
1
1
Description
It refers to the 12-pin power and I/O cable. You
need to purchase separately.
It refers to the GigE network cable with RJ45
aviation connector. You need to purchase
separately.
It refers to suitable power adapter that you need
to purchase it separately.
It is used to fix the device. You need to purchase
separately.
It refers to C-mount lens that you need to
purchase it separately.
It is used to provide light during image acquisition.
You need to purchase separately.
10
