Select Exposure Start Active
Note
For different models of camera, when selecting ExposureStartActive as Line Out Activation Event,
the specific parameters may be different. The actual product you purchased shall prevail.
If you select ExposureStartActive as Line Out Activation Event, you can set its output delay time
and duration.
Line Out Delay Time
It sets the delay time for outputting the output signal.
Line Out Duration
It sets the time duration of the output signal.
Select Soft Trigger Active
If you select Soft Trigger Active as Line Out Activation Event, you can set its output delay time,
duration, and execute outputting signal manually.
Line Out Delay Time
It sets the delay time for outputting the output signal.
Line Out Duration
It sets the time duration of the output signal.
Line Trigger Software
Click Execute for manually outputting the output signal.
ID6000 Series Smart Code Reader User Manual
Figure 7-31 Select ExposureStartActive
