CHARACTERISTICS:
The HD67832-xxx-B2 is a DALI / BACnet Master - Converter.
It has the following characteristics:
Up to 64 devices on DALI bus;
Configurator for DALI network/devices;
Isolation between DALI – RS485, Power Supply – RS485. Additional isolation Power Supply – DALI for HD67832-xxx-B2 version;
Two-directional information between DALI bus and
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need "DALI Console" software on your PC in order to perform the following:
Configure the DALI network;
Setup the DALI devices (groups, scenes, IDs, ...);
Test DALI communication.
You need Compositor SW67832-xxx-B2 software on your PC in order to perform the following:
Define the parameter of
Define the parameter of DALI line;
Update the device.
ADFweb.com Srl – IT31010 – Mareno – Treviso
BACnet
BACnet
line;
User Manual DALI / BACnet Master - Converter
Document code: MN67832_ENG
bus;
