SETUP:
This section defines the parameters of the HD67832 converter.
By Pressing the "Setup" button from the menu bar of the DALI Console software, the "SETUP" window appears (Fig. 10).
The means of the fields for the "SETUP" window are:
In the field "DEVICE IP
In the field "DEVICE PORT" the communication port is defined. It is fixed to '10000';
In the field "CONSOLE
Console Port" of the section "Set Communication" of SW67832;
In the fields "SCI x Protocol" the type of Ethernet communication used is defined. It is possible to leave the default setting;
If the field "DALI 1 ONLY" is checked, the converter will manage just DALI 1 communication;
If the field "DISABLE AUTOMATIC
If the field "AutoRefresh" is checked, the converter automatically refreshes the data when a command is sent.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Figure 10: "Setup" window
ADDRESS" the IP address set inside the converter is defined;
PORT" the communication port for the DALI commands is defined. It is the one defined in the field "DALI
SCAN" is checked, the converter will stop the automatic scan of DALI network;
