Note:

Also, that Relay3 on can also be tied to pin 17 or 16 on port 2. If the jumper is set to be

tied to pin 17, then the relay will activate while the system is active. This can be ideal to control

power to DC servos or to handle servo brakes. Or enable/disable any other feature that is

associated to the system been active.

7.2

Configuration jumper mode US or INT

For the Variable speed control go to

http://cnc4pc.com/Tech_Docs/VARIABLE_SPEED_CONTROL.pdf

For Configure the control software go to

http://cnc4pc.com/Tech_Docs/CONFIGURATION_OF_CONTROL_SOFWARE.pdf

For Replacing Potentiometer go to

http://cnc4pc.com/Tech_Docs/Replacing%20a%20Potentiometer.pdf

7.3

___________________________________________________________________________

User's Manual

Page 7
