URL of the HMI application
Default setting: localhost
A complete URL must be entered to use the terminal as a VNC client. The following URLs are accepted by the
terminal:
• [Server]/Path/HMIApplication
• [Server]/Path/HMIApplication
• [server]:8080/path/HMIApplication
• [Server]/Path/HMIApplication
If the URL does not include a port number, port 80 is used by default.
If server [server] is available on a different port, the port must be explicitly specified along with the IP address
or hostname:
Syntax
[IP address]:Port
[Hostname]:Port
If the HMI application is provided by the controller of the Power Panel C50, then localhost can be used as the
hostname. This specific hostname is then automatically replaced by the IP address of the controller.
Password
Default setting: EMPTY (no password entered)
Input range: Max. 100 characters
Note: Only one password can be entered, which is only used for the currently selected VNC server.
If a password has been entered, then the VNC client (Power Panel) is connected to the VNC server without an
additional password query.
If no password has been entered, then the password will be queried on the Power Panel each time a connection
to the VNC server is established.
The password is stored on the device in configuration file Config.xml .
Enable local window scaling
Default setting: Disabled
Enabled The VNC application is scaled to the Power Panel screen size.
Disabled The VNC application is displayed on the Power Panel screen in its original size.
Information:
Enabling option Enable local window scaling reduces the performance of the Power Panel because of
increased demands on processing power.
Background color
It is possible to customize the background color of the VNC viewer. This can be useful if the VNC-based HMI
application is smaller than the panel's screen and scaling is not desired or possible.
The background color can be entered in two ways:
1. Hex code: #xxxxxx
2. Color keyword
An overview of possible colors can be obtained from the following website:
s.html#ColorKeywords. Examples:
Color
Lime green
Blue
Azure
Power Panel C80 User's manual V1.02
Example
10.23.20.17:8080
webserver1:8081
Hex code
#32CD32
#0000FF
#F0FFFF
Description
Establishes a connection to IP address 10.23.20.17 on port 8080.
Establishes a connection to host webserver1 on port 8081.
https://www.w3.org/TR/SVG11/type-
