Device description

4.2.2 Technical data of the interface variants

IF7: CAN bus interface, galvanically isolated
Order number
Interfaces
Interface IF7
Type
Variant
Max. transfer rate
Bus length ≤25 m
Bus length ≤60 m
Bus length ≤200 m
Bus length ≤1000 m
IF8: CAN bus interface
Order number
Interfaces
Interface IF8
Type
Variant
Max. transfer rate
Bus length ≤25 m
Bus length ≤60 m
Bus length ≤200 m
Bus length ≤1000 m
IF9: RS232 interface
Order number
Interfaces
Interface IF9
Type
Variant
Transfer rate
IF10: RS485 interface
Order number
Interfaces
Interface IF10
Type
Variant
Transfer rate
16
4PPC80.xxxx-x1x, 4PPC80.xxxx-x2x, 4PPC80.xxxx-x3x
CAN bus
3 pins of the 10-pin multipoint connector
Galvanically isolated
1 Mbit/s
500 kbit/s
250 kbit/s
50 kbit/s
4PPC80.xxxx-x1x
CAN bus
3 pins of the 10-pin multipoint connector
1 Mbit/s
500 kbit/s
250 kbit/s
50 kbit/s
4PPC80.xxxx-x2x
RS232
3 pins of the 10-pin multipoint connector
Max. 115.2 kbit/s
4PPC80.xxxx-x3x
RS485
3 pins of the 10-pin multipoint connector
Max. 115.2 kbit/s
