5.5 Mounting orientations

Notice!
Possible damage to device!
• An ambient temperature that is too high can cause damage to the device or faulty behavior.
• For the maximum permissible ambient temperature, see the technical data for the respective
device.
The following drawings show the specified mounting orientations of Power Panel C80 devices. These are only
permitted to be installed as specified.
During installation, it is important to make sure that the spacing as described in section
on page 27 is observed in order to achieve natural air circulation.
Typical application
1) Max. operating temperature: 60°C
Worst-case application
1) Max. operating temperature: 60°C
Power Panel C80 User's manual V1.02
Inclination [°] 4PPC80.0573-xxx
0 No limitation
Up to ±90 No limitation
Up to ±180 No limitation
Inclination [°] 4PPC80.0573-xxx
0 No limitation
Up to ±45 No limitation
From -46 to -90 No limitation
Inclination [°] 4PPC80.0573-xxx
0 No limitation
Up to ±90 No limitation
Up to ±180 No limitation
Inclination [°] 4PPC80.0573-xxx
0 No limitation
Up to ±45 No limitation
From -46 to -90 -5
4PPC80.0702-xxx 4PPC80.101E-xxx
1) 1)
No limitation No limitation
No limitation No limitation
No limitation No limitation
4PPC80.0702-xxx 4PPC80.101E-xxx
1) 1)
No limitation No limitation
No limitation No limitation
No limitation No limitation
4PPC80.0702-xxx 4PPC80.101E-xxx
1) 1)
No limitation No limitation
No limitation No limitation
No limitation No limitation
4PPC80.0702-xxx 4PPC80.101E-xxx
1) 1)
No limitation No limitation
No limitation No limitation
-5 -5
Installation and wiring
"Spacing for air circulation"
Derating [°C]
4PPC80.121E-xxx
1) 1)
No limitation
No limitation
No limitation
-
4PPC80.121E-xxx
1) 1)
No limitation
No limitation
No limitation
-
Derating [°C]
4PPC80.121E-xxx
1) 1)
No limitation
No limitation
No limitation
-
4PPC80.121E-xxx
1) 1)
No limitation
No limitation
-5
-
4PPC80.156B-xxx
1)
No limitation
No limitation
No limitation
4PPC80.156B-xxx
1)
No limitation
No limitation
No limitation
4PPC80.156B-xxx
1)
No limitation
No limitation
No limitation
4PPC80.156B-xxx
1)
No limitation
No limitation
No limitation
