quick reference guide – MANO EDU
2
1
3
4
5
6
7
8
A
B
FBM 752-023
Stand 06/21, Version 1.0
www.reineckervision.com
home
joystick
color mode
1) power port
2) ON/OFF
3) HDMI input
4) HDMI output
5) USB-C port
6) SD card slot
7) camera switch
8) line marker/
mask
TTS
zoom
9) distance camera
10) headphones/
loudspeaker jack
11) volume control
12) autofocus
13) freeze button
Hold the base plate with one hand and
A
unfold the stand
Bring the display into a comfortable viewing
B
position
Unfold the distance camera and turn it
C
in the desired direction
C
10
11
9
12
13
