Product Introduction

mini is a "mini" signal switcher and mixer which is able to stream 6-picture PVW or PGM from any one out of
the 4 HDMI inputs to any live broadcasting platform via third party live streaming software such as OBS. It
adopts compact design, equipped with a 2 inch TFT screen to preview the 4 inputs in real time. 14 transition
effects on board work with T-Bar to do transition switching. Along with seamless switching, there are other
outstanding features such as audio embedding, de-embedding,and automatically identifying color depth of
RGB4:4:4, YUV4:4:4, YUV4:2:2, YUV4:2:0. mini devices are easy to operate either on board or remotely from
mobile devices or laptops with XPOSE mini.
System Connection Diagram
mini System Connection Diagram
