DIMENSIONS
Width
Depth
Height (without legs)
WEIGHT
Shipping
Empty
Operating
ICE BANK WEIGHT
WATER BATH CAPACITY
COMPRESSOR
AGITATOR MOTOR
CONDENSER MOTOR
ICE BANK CONTROL
TRANSFORMER
Optional 230V/50Hz and 220V/60Hz systems available.
109 - 12 ounce drinks under 40°F (4.4°C) at two (2) drinks per minute with 105°F (40.5°C) ambient inlet
product (pre-mix) using a 1/3 HP, 115V/60Hz refrigeration system (Condition D).
• NORTH AMERICA – 210-310-7245 • INTERNATIONAL SALES – 210-310-7242 • CUSTOMER SERVICE – 210-310-7242 •
• LATIN AMERICA – 210-524-9567 / 210-310-7245 • EUROPE – 32-2-755-2399 • PACIFIC – 61-8-8268-1978 •
"Lancer" is the registered trademark of Lancer • Copyright — 2000 by Lancer, all rights reserved.
INSTALLATION AND SERVICE MANUAL
COUNTER ELECTRIC DISPENSER
16 7/8 inches
24 3/4 inches
25 1/2 inches
170 pounds
146 pounds
220 pounds
27 pounds
10.87 gallons
1/3 HP Tecumseh, 115V/60Hz
25W, 115V
9W, 115V
Lancer Electronic Ice Bank Control (EIBC)
120V (Primary) / 24V (Secondary)
Please refer to the Lancer web site (www.lancercorp.com) for
information relating to Lancer Installation and Service Manuals,
Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
This manual supersedes and replaces 28-0454, dated 03/29/00.
6655 LANCER BLVD. • SAN ANTONIO, TEXAS 78219 USA • (210) 310-7000
FAX ENGINEERING: • 210-310-7096
FOR
DELTA III PRE-MIX
SPECIFICATIONS
(429 mm)
(628 mm)
(648 mm)
(77.1 kg)
(66.2 kg)
(99.8 kg)
(12.25 kg)
(41.15 liters)
FAX SALES
REV.
10/25/00
P.N. 28-0454/01
