Summary of Contents for lancer CED-04
- Page 1 CED-04 Operation Manual Lancer Corporation Technical Support/Warranty 6655 Lancer Blvd. 800-729-1550 San Antonio, Texas 78219 custserv@lancercorp.com 800-729-1500 lancercorp.com PN: 28-0976 “Lancer” is the registered trademark of Lancer © 2016 by Lancer, all rights reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ABOUT THIS MANUAL BEFORE GETTING STARTED This booklet is an integral and essential part of the product. Each unit is tested under operating conditions and is thoroughly Please carefully read the guidelines and warnings contained inspected before shipment. At the time of shipment, the carrier herein as they are intended to provide the user with essential accepts responsibility for the unit. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS ! Refrigerant F Power • WARNING: The refrigeration system is under high • Follow all local electrical codes when making pressure. Do not tamper with it. Contact qualified connections. service personnel before disposal. • Check the dispenser name plate label, located behind the splash plate for the correct electrical requirements ! Intended Use of unit. -
Page 4: Specifications And Features
SPECIFICATIONS AND FEATURES 22.61 in. 27.19 in. A. Bonnet 15.44 in. B. Splash Plate C. Cup Rest D. Drip Tray DIMENSIONS PLAIN WATER SUPPLY Width: 15.44 inches (392 mm) Min Flowing Pressure: 50 PSIG (0.345 MPA) Depth: 27.19 inches (691 mm) CARBONATED WATER SUPPLY Height: 22.61 inches (574 mm) Min Flowing Pressure: 25 PSI (0.172 MPA) -
Page 5: General System Overview
Conditioning Ducts Do you have enough space to Drill Oetiker Clamp Fittings install the dispenser? BIB SYSTEM: Water Booster (Lancer PN: Is countertop level? 82-3401 or MC-163172 BIB Rack Can the countertop support the Water Regulator (recommended) weight of the dispenser? -
Page 6: Installation
INSTALLATION Read This Manual This manual was developed by Lancer Corporation as a reference for the owner/operator and installer of this dispenser. Please read this manual before installation and operation of this dispenser. Please see pages 13-17 for troubleshooting or service assistance. If the service cannot be corrected please call your Service Agent or Lancer Customer Service. -
Page 7: Dispenser Installation
The dispenser is designed to be installed either permanently to counter or placed on a counter using the four (4) inch legs (included in the Lancer kit, PN 82-1704) NOTE NSF listed units must be sealed to the counter or have four (4) inch legs installed. -
Page 8: Installing Remote Syrup Pumps - Bib
14. Route proper drain line from the designated floor drain 16. Re-install cup rest and splash plate. through the counter cutout and drip tray opening. 17. Turn on water supply and check for leaks. 15. Connect drain tube to the drain fitting located on the 18. -
Page 9: Installing Co Supply
Installing CO Supply Connect high pressure CO regulator assembly to CO Using a wrench, loosen lock nut on regulator adjustment cylinder or bulk system. screw then using a screwdriver back out lock nut screw all the way. ! ATTENTION Before installing regulator, assure that a seal (washer or o-ring) is present in regulator attachment nut. -
Page 10: Adjust Water Flow Rate & Syrup/Water Ratio
Install Lancer (yellow) syrup separator (PN 54-0031) in place of nozzle. A. Plain Water ON B. Syrup Closed Using a Lancer ratio cup verify water flow rate (5 oz. in 4 sec.). Use a screwdriver to adjust if needed. A. Syrup Separator B. Nozzle C. -
Page 11: Scheduled Maintenance
General Information • Lancer equipment (new or reconditioned) is shipped from the factory cleaned and sanitized in accordance with NSF guidelines. The operator of the equipment must provide continuous maintenance as required by this manual and/or state and local health department guidelines to ensure proper operation and sanitation requirements are maintained. -
Page 12: Cleaning And Sanitizing Solutions
Integrity of the Plastic Finish While caring for your CED-04, please note that there may be some cleaners that may compromise the integrity of the plastic finish. Most common cleaners such as Windex, Dawn, 409, etc. pose no threat to the plastic finish of the unit. However, certain cleaners with high levels of acetic acid, ethylbenzene, isopropylamine, etc., at certain temperatures, could cause aesthetic damage. -
Page 13: Troubleshooting
TROUBLESHOOTING TROUBLE CAUSE REMEDY Water leakage around nozzle. O-ring not properly installed above diffuser Install or replace o-ring correctly. O-ring is damaged or missing. Replace o-ring. Leakage between upper and Gap between upper and lower valve Tighten all six (6) retaining screws. lower bodies. - Page 14 TROUBLE CAUSE REMEDY Water only dispensed; no Water or syrup shutoff on mounting block Open shutoff fully. syrup; or syrup only dispensed, not fully open. Remove valve from mounting block, open no water Improper or inadequate water or syrup shutoffs slightly and check water and flow.
- Page 15 TROUBLE CAUSE REMEDY Excessive foaming. Incoming water or syrup temperature too Correct prior to dispenser. Consider larger high. dispenser or pre-cooler. pressure too high. Adjust CO pressure downward, but not less than 70 PSI. Water flow rate too high. Re-adjust and reset ratio. Refer to “Adjust Nozzle and diffuser not installed.
- Page 16 TROUBLE CAUSE REMEDY Compressor does not start (no Compressor relay, capacitors, or overload Replace compressor relay, capacitors, or hum), but gas cooler fan motor protectors malfunctioning. overload protector. runs. Inadequate voltage. Measure voltage across commom and run terminal on compressor. Voltage must not Incorrect wiring.
- Page 17 TROUBLE CAUSE REMEDY Circuit breaker tripping. Valve wire harness shorted to itself or to Detect short by disconnecting input fasten faucet plate. to keylock and single pin connector. Restore power if breaker doesn’t trip. PCB is bad. Then valve wire harness is shorted. If OK, Secondary wire harness is bad.
-
Page 18: The Electronic Ice Bank Control (Eibc)
THE ELECTRONIC ICE BANK CONTROL (EIBC) Checking the Normal PCB Operation ! WARNING Terminal block has AC line voltage and, when servicing the unit, should be covered with tape. Tape should cover bare electrical connections to prevent electrical shock. Turn power OFF or insure that power has been disconnected from dispenser Check condition of 0.5 amp fuse at location shown in agram to the right. If fuse is blown, trace cause of short in valve wire harness and associated 24 VAC lines and replace fuse. - Page 19 INTENTIONALLY LEFT BLANK...
-
Page 20: Illustrations And Part Listings
ILLUSTRATIONS AND PART LISTINGS Main Unit Assembly... - Page 21 Bonnet Filler, Left Side, CED-04 30-12584 Bonnet Filler, Right Side, CED-04 12-0097 Keyswitch Assembly 82-4938 Refrigeration Deck Assembly, R744, CED-04 23-1719 Cage Assembly, Plain Water, 4-Valve, CED-04 30-12300 Pump Plate, CED-04 48-3540 Tube Assembly, Syrup 1, CED-04 48-3551 Tube Assembly, Syrup 2, CED-04 48-3550...
-
Page 22: Refrigeration Deck Assembly
Refrigeration Deck Assembly Item Part No. Description 83-0078 Compressor Assembly 30-11553/01 Fan Motor Bracket 82-5067 Agitator Assembly 30-12717 Agitator Motor Bracket 52-3690 Control Housing Assembly 25-0047/01 Transformer 52-1773/02 EIBC Probe Assembly 52-3485 Condenser Fan Motor Assembly 30-11556 Condenser Fan Shroud 23-1717 Gas Cooler, 5MM Refer to Refrigerant Warning on page 3... -
Page 23: Wiring Diagram - 115 Volt
Wiring Diagram - 115 Volt... -
Page 24: Plumbing Diagram
Plumbing Diagram Lancer Corp. 800-729-1500 Technical Support/Warranty: 800-729-1550 custserv@lancercorp.com lancercorp.com...
