- Page 1 S1D13C00 S5U13C00P00CX00 Customer Development Board User Manual Document Number: XB8A-G-001-01.01 Rev 1.01...
- Page 2 Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as, medical products.
-
Page 3: Table Of Contents
J1 - 24-pin RGB LCD Interface .................... 15 J2 - 21-Pin RGB LCD Interface .................... 16 J3 - 10-Pin SPI LCD Interface ....................17 10. Parts List ........................18 11. S5U13C00P00CX00 Schematics ................20 12. Revision History ......................24 Seiko Epson Corporation Customer Development Board User Manual... - Page 4 Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01)
-
Page 5: Introduction
Introduction Introduction The S5U13C00P00CX00 is the S1D13C00 BoosterPack MDC Customer Development Board. It is a BoosterPack board intended to be directly connected to the TI Tiva C Series EK-TM4C1294XL Launchpad evaluation board for evaluating and developing embedded memory LCD display applications using the Epson S1D13C00 Memory Display Controller IC. -
Page 6: Lcd Module Options And Parts List
LCD Module Options and Parts List LCD Module Options and Parts List The S5U13C00P00CX00 Customer Development Board can interface to two types of LCD modules. One type of LCD module has a parallel RGB interface and the other type has a SPI interface. -
Page 7: Connecting The Lcd Modules
J1 – 24-pin RGB Type Connector Figure 2 – Example of connecting the JDI LPM012M134B LCD module J2 – 21-pin RGB Type Connector Figure 3 – Example of connecting the Sharp LS012B7DD06 LCD module Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) -
Page 8: J3 - 10-Pin Spi Type Connector
Connecting the LCD Modules J3 – 10-pin SPI Type Connector Figure 4 – Example of connecting the Sharp LS13B7DH06 LCD module Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) -
Page 9: Connecting The Host Interface Board
Connecting the Host Interface Board Connecting the Host Interface Board Position the S5U13C00P00CX00 Customer Development Board on TOP of the EK-TM4C1294XL Launchpad Host Interface Board, press the two boards together with J4 connecting to X8, J5 connecting to X9, J6 connecting to X6, and J7 connecting to X7 respectively. -
Page 10: Jumpers Settings
Jumpers Settings Jumpers Settings The following tables show the jumpers settings for the S5U13C00P00CX00 Customer Development Board. The jumpers are divided into three groups: Host Interface, LCD Interface, and Power Supply. JP14 JP10 JP15 JP11 JP16 JP18 JP20 JP19 JP13 JP17 Figure 6 –... -
Page 11: Lcd Interface
VDD Supplies on pin 22 and pin 34 of S1D13C00 Install (used for current measurement) External 5V Power Supply JP5-1 = +5V in No Connection (NC) JP5-2 = GND JP13 External VC3 Supply connection No Connection (NC) Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) -
Page 12: Dip-Switch And Headers
DIP-Switch and Headers DIP-Switch and Headers Figure 7 – S5U13C00P00CX00 DIP-Switch and Headers Locations DIP-Switch (S1) The main purpose of the DIP-switch is used to perform a loopback test on both of the SPI interfaces of the S1D13C00. During normal operations, all the switches should be OFF (default setting). -
Page 13: Headers
Headers The main purpose of the headers is to provide a convenient way for users to access different GPIO port functions of the S1D13C00 other than those components pre-installed on the S5U13C00P00CX00 Customer Development Board. Please refer to the S1D13C00 Hardware Functional Specification, document XB8A-A-001-xx, for enabling and using of the functions. -
Page 14: Pre-Installed On-Board Components
Pre-installed On-board Components Pre-installed On-board Components LED2 Figure 8 – S5U13C00P00CX00 pre-installed on-board components locations 16Mbytes QSPI Serial Flash (U3) This serial flash is directly connected to the QSPI interface of the S1D13C00. The flash can be optionally accessed S1D13C00. -
Page 15: Tiva C Series Ek-Tm4C1294Xl Launchpad Connections
Tiva C Series EK-TM4C1294XL Launchpad Connections Tiva C Series EK-TM4C1294XL Launchpad Connections The following tables show the signals of the Tiva C Series EK-TM4C1294XL Launchpad connectors which are used by the S5U13C00P00CX00 Customer Development Board: EK-TM4C1294XL S1D13C00 MDC Connector X8 Signals... - Page 16 JP18-3 as HIFSPID3 to JP16-1 as HIFD1 to JP17-1 as HIFD2 to JP18-1 as HIFD3 To JP20-1 as J3_DISP_EN EK-TM4C1294XL S1D13C00 MDC BoosterPack Usage Connector X7 Signals TARGET_RST# PA3/PQ2 PA2/PQ3 #HIFCS Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01)
-
Page 17: Pinout For Lcd Interfaces
GRN1 J1_G2 BLU0 J1_B1 BLU1 J1_B2 T11 (test point) VCOM J1_VCOM VCOM (1) Connect through R28 to GND (2) Connect through R27 to GND (3) Connect through R12 to GND Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) -
Page 18: J2 - 21-Pin Rgb Lcd Interface
VDD2 XRST INTB INTB VCOM XFRP VMDL VMDL VDD1 RED0 R[0] R[0] RED1 R[1] R[1] GRN0 G[0] G[0] GRN1 G[1] G[1] BLU0 B[0] B[0] BLU1 B[1] B[1] VCOM J2_VCOM VCOM Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) -
Page 19: J3 - 10-Pin Spi Lcd Interface
JP8 selects J3_VDDA to either VMDH or VMDL of S1D13C00 JP9 selects J3_VDD to either VMDH or VMDL of S1D13C00 JP7 selects J3_EXTMODE to either J3_VDD or GND See Section 5.2.2, SPI Panels and Control Selection for details. Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) -
Page 20: 10. Parts List
R45,R46,R47,R48,R49, R51,R52,R53,R54,R55, R56,R61,R63,R65,R68, R69,R70,R71,R72,R75 560 OHM 1% 1/8W SMD R0603 Vishay MCT06030C5600FP500 Item Reference Part Description Manufacturer Part No. / Comments R50,R58 10K OHM 5% 1/10W SMD R0603 Yageo RC0603JR-0710KL Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) - Page 21 Grayhill Inc. 97C04ST T1,T2,T3,T4,T5,T6,T7,T8, CON1 TEST POINT Test Point, not a part T9,T10,T11,T12,T13,T14, T15,T16,T17,T18,T19,T20,T 21,T22,T23,T24,T25,T26,T2 7,T28 s1d13c00 Epson MDC S1D13C00 TQFP13-64 Epson S1D13C0000B MCP1700 3.3V LDO Microchip MCP1700T-3302E/TT S25FL127S or 16Mbytes SPI Flash Memory Cypress S25FL127SABMFI10X or IS25LP-128 ISSI IS25LP128-JBLE...
-
Page 22: S5U13C00P00Cx00 Schematics
S5U13C00P00CX00 Schematics S5U13C00P00CX00 Schematics S5U13C00P00CX00 Schematics (1 of 4) Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) - Page 23 S5U13C00P00CX00 Schematics S5U13C00P00CX00 Schematics (2 of 4) Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01)
- Page 24 S5U13C00P00CX00 Schematics S5U13C00P00CX00 Schematics (3 of 4) Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01)
- Page 25 S5U13C00P00CX00 Schematics S5U13C00P00CX00 Schematics (4 of 4) Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01)
-
Page 26: Revision History
Revision History Revision History Rev. No. Date Page Category Contents 1.01 12/09/2018 Minor update to text. 20/03/2018 Initial release of document Minor formatting and edits Seiko Epson Corporation Customer Development Board User Manual (Rev 1.01) - Page 27 International Sales Operations For more information on the S1C13C00 and other Epson Display Controllers, visit the Epson Global website. https://global.epson.com/products_and_drivers/semicon/products/display_controllers/ For Sales and Technical Support, contact the Epson representative for your region. https://global.epson.com/products_and_drivers/semicon/information/support.html Document Code: XB8A-G-001-01.01 First Issue March 2018...
