Location and Compliance

Voltage and Frequency Trip Thresholds

This unit or system is provided with fixed trip limits and
shall not be aggregated above 30 kW on a single point of
common connection.
All PWRcell Inverters are shipped from the factory in
compliance with all UL 1741 requirements, including
IEEE 1547. If permission to operate (PTO) is dependent
on compliance to a specific utility standard, follow the
steps covered in Set Inverter Grid Compliance
section in this manual.
(optional)

Voltage Trip Thresholds

See Table 3-2 for the default fixed voltage trip setpoints.
All over voltage and under voltage trip conditions result in
a 300-second restart delay time after the trip threshold
has been exceeded for the listed number of cycles.
Voltage Trip Thresholds
Threshold
(% of nominal)
OV4
OV3
OV2
OV1
UV1
UV2
UV3
UV4
*Value of 999 indicates a disabled threshold for voltage trips
**Value of zero indicates a disabled threshold for frequency trips
10
Table 3-2. Voltage Trip and Frequency Thresholds
Threshold
No. of Cycles
999* 1
130 1
120 10
110 60
88 120
50 10
999* 1
999* 1
The inverter is disconnected from the grid during this
300-second delay.

Frequency Trip Thresholds

See for the default fixed frequency trip set-
Table 3-2
points. All over frequency and under frequency trip condi-
tions result in a 300-second restart delay time after the
trip threshold has been exceeded for the listed number of
cycles.
The inverter is disconnected from the grid during this
300-second delay.
Frequency Trip Thresholds
Threshold
Threshold
(% of nominal)
OF4
OF3
OF2
OF1
UF1
UF2
UF3
UF4
Installation and Owner's Manual for Generac PWRcell Inverter
No. of Cycles
0** 1
0** 1
0** 1
0.5 10
0.7 10
0** 1
0** 1
0** 1
