Section 6: Commissioning

Commissioning the System

NOTE: See the Generac PWRcell Commissioning Quick
Start Guide for more information.
IMPORTANT: If multiple PWRcell Inverters are installed,
refer to Commissioning Multiple Inverter
not turn on AC power to more than one inverter at a time.
Before commissioning the system:
•
Verify all wiring terminations are tight and secure.
•
Verify AC voltage is within the specified range for
system configuration.
– 240 V split-phase (108-130 VAC Line to Neutral)
– 208 V 3-phase (108-130 VAC Line to Neutral)
•
Verify DC wiring field terminations are secure and
polarity is correct.
•
Verify DC disconnects for all connected devices
are turned ON.
Commissioning steps:

1. Connect to High Speed Broadband Internet.

2. Register System.

3. Connect PWRcell Inverter to AC Power.

4. Select Inverter System Mode.
5. Configure Inverter Settings.
6. Enable REbus Devices.
7. Test Island Mode.
8. Configure Time of Use (optional).
9. Access Installer Configuration Tool
(for steps 10 - 11).
10. Set Inverter Grid Compliance (optional).
11. Set Import / Export Compliance (optional).
Connect to High Speed Broadband
Internet
Refer to Connecting Ethernet
Register System
NOTE: If the system will not be connected to the Inter-
net, installer will not be able to take advantage of PWR-
fleet, the customer will not have access to the PWRview
app, and warranty will be limited to five years. Contact
Generac at 1-888-ACTIVATE to complete the registra-
tion.
NOTE: Registering an inverter automatically registers all
REbus system components connected to that inverter.
Every REbus-enabled device can be monitored from the
PWRfleet fleet management
PWRview™ online monitoring system and mobile app.
Installation and Owner's Manual for Generac PWRCell Inverter
Systems. Do
for more information.
platform and the
To register a system for PWRview monitoring:
1. See Figure 6-1. Locate the serial number and reg-
istration code on the registration decal on the front
of the inverter. This information will be required for
registration.
https://pwrfleet.generac.com
2. Navigate to
using a mobile device, scan the QR code on the
registration decal and use the "Register at
PWRfleet" URL provided.
3. Follow the on-screen prompts to complete the
profile.
DO NOT REMOVE
UNTIL INSTALLATION IS COMPLETE
SCAN FOR INSTALLATION
STEPS AND RESOURCES OR VISIT
Generac.com/Startup
System Registration:
Register your system
to activate:
• Warranty
• PWRview and PWRfleet
After-hours Software Update:
Generac.com/PWRcell/Update
System Registration Information:
SERIAL NUMBER:
XXXX-XXXXX
Figure 6-1. Registration Decal
Connect PWRcell Inverter to AC
Power
IMPORTANT: If multiple PWRcell Inverters are installed,
refer to Commissioning Multiple Inverter Systems
place of this commissioning step. Do not turn on AC
power to more than one inverter at a time.
Turn ON main AC backfeed to power-up the inverter.
See Figure 6-2. On power-up, the home screen will
appear on the control panel LCD with the system mode
listed at the top of the home screen.
Commissioning
or, if
Live Firmware Updates:
1-855-395-7841
8:00am-8:00pm ET,
Mon-Sat
REGISTRATION CODE:
RRRR-RRRR
012615
