PWRcell 2P Inv.
Enable
Mod. Settings
Calibrate CTs
RCPn: 000100073212
< EXIT SCROLL > NEXT • SELECT
Figure 6-8. Enabling Inverter (2 of 4)
5. See Figure 6-9. Arrow right and press center
button to Confirm.
PWRcell 2P Inv
Enable
Enable
Mod. Settings
Calibrate CTs
Cancel
RCPn: 00010003XXXX
< EXIT SCROLL > NEXT • SELECT
Figure 6-9. Enabling Inverter (3 of 4)
6. See
Figure 6-10.
create voltage at the DC terminals and begin com-
municating with connected REbus devices.
NOTE: Upon enabling the inverter high voltage will be
present at the REbus DC terminals and all REbus DC
wiring where the DC disconnects are turned ON for those
circuits.
PWRcell 2P Inv.
Inverter
grid connected
AC Power:
AC Voltage:
E-total:
Figure 6-10. Inverter Enabled (4 of 4)
7. Enable all other REbus devices connected to the
system by repeating steps 1 – 5 for each device.
For further commissioning instructions for REbus
devices, see their respective installation manuals.
Installation and Owner's Manual for Generac PWRCell Inverter
Menu
009656
010011
Menu
Confirm
The inverter is enabled. It will
-02
-36W
248V
2.4Wh
010013

Test Island Mode

To test Island Mode, AC power to the inverter must be
disconnected. If configured to provide backup power to a
protected loads subpanel, this may be accomplished by
turning OFF the solar backfeed breaker or solar AC dis-
connect. If configured to operate with a PWRcell ATS, AC
power must be disconnected to the inverter and the ATS
to testing islanding.
– Ensure inverter setting "EnaIslanding" is set to
'on.'
– Ensure Protected Loads breaker at the inverter
Power Core is in the ON position.
– Ensure system is set to an appropriate system
mode (e.g., Clean Backup, Priority Backup, Self
Supply).
NOTE: Exact electrical system configurations will vary. It
is up to the operator to perform this test accurately for the
configuration onsite.
NOTE: Per UL 1741, the PWRcell Inverter may require
five minutes upon recovery from a grid outage or island-
ing event before exporting power.

Configure Time of Use (optional)

REbus Beacon allows the PWRcell system to manage
energy production and storage over the course of the
day. This is called Time of Use (TOU) energy manage-
010012
ment. To take advantage of this functionality, the PWRcell
system must include a PWRcell Battery and a reliable
connection to the Internet via an Ethernet connection to a
router.
NOTE: Enable and setup the REbus Beacon for TOU
scheduling only. Otherwise, do not enable the REbus
Beacon.

Configuring and Running a TOU Schedule

1. See
Figure
page and press the center button to enter the
device menu.
REbus Beacon
TOU Scheduler
disabled
To enable scheduler,
press center button
and select "Enable".
Figure 6-11. Configuring TOU Schedule (1 of 4)
Commissioning
6-11. Navigate to the Beacon device
010109
