Appendix A: Replacement Parts - Labconco Precise CA 5220100 User Manual

A p p e n d i x
A p p e n d i x
R e p l a c e m
R e p l a c e m
The components that are available for your glove box are listed. The parts
shown are the most commonly requested. If other parts are required, please
contact Product Service.
Item Qty.
1A 1ea
1B 1ea
2A 1ea
2B 1ea
2C 1ea
2D 1ea
2E 1ea
3A 1pr
3B 1pr
3C 1pr
3D 1pr
3E 1pr
3F 1pr
3G 2ea
3H 2ea
4 1ea
5 1ea
6A 1ea
6B 1ea
6C 1ea
6D 1ea
6E 1ea
6F 1ea
6G order by the foot
6H order by the foot
(25' coils)
6I 1ea
7 1ea
8 1ea
9A 1ea
9B 1ea
9C 1ea
9D 1ea
9E 1ea
10A 1ea
10B 1ea
11A 1ea
11B 1ea
11C 1ea
11D 1ea
12A 1ea
12B 4ea
12C 1ea
13A REF.
13B REF.
14 1ea
Product Service 1-800-522-7658
A :
A :
e n t P a r t s
e n t P a r t s
Part
Number
5232200 Framed Glass Window (standard)
5236100 Framed Acrylic Window (optional)
1230700 Receptacle, 115V Duplex
1283900 Receptacle, 230V Duplex
5232900 Sealed Duplex, 115V Complete
5232901 Sealed Duplex, 230V Complete
5233400 Wallplate Duplex Gray
1640600 9 ¾ size Neoprene Gloves (standard)
1640601 9 ¾ size Butyl Gloves
1640602 9 ¾ size Hypalon Gloves
1640500 8 ½ size Neoprene Gloves
1640501 8 ½ size Butyl Gloves
1640502 8 ½ size Hypalon Gloves
1640000 O-Rings
1965600 Clamp – O-Ring Gloves
5236200 Transfer Chamber Inner Support Sleeve
1307000 Switch, Rocker (2 Position)
5225701 Valve Kit (included on CA)
1409900 Tube Support Insert
1408300 Large Ferrule
1408400 Small Ferrule
1413602 Stainless Compression Nut
1413500 Hose Connector (Secondary Method)
1539500 Polyvinyl Chloride Tubing 3/8" OD x 3/16" ID
7396209 FEP Tubing, Drying Train, 3/8" OD x 1/4" ID
1409901 Tubing Insert, Drying Train, 3/8" OD x 1/4" ID
1365200 Main Glove Box Pressure Gauge (included on CA)
1365300 Transfer Chamber Vacuum Gauge (included on CA)
5222700 Fluorescent Bulb, 8" Circleline FC8T9/CW, 22 Watt, 4 Pin
5222800 Ballast, 115V 60 Hz
5222801 Ballast, 230V 50 Hz (also used on 100V, 50 Hz)
5222802 Ballast, 230V 60 Hz (also used on 100V, 60 Hz)
5242900 Transformer, 230V to 100V (100V models only)
1305800 Inlet Power Cord, 115V
1305900 Inlet Power Cord, 230V
5226400 Inner Transfer Door w/attached gasket (Complete Assy.)
5226500 Outer Transfer Door w/attached gasket (Complete Assy.)
5226401 Inner Door w/attached gasket only
5226501 Outer Door w/attached gasket only
1327204 Circuit Breaker, 5A, 115V
1327205 Circuit Breaker, 2A, 230V
1327200 Circuit Breaker, 3A, 115V
5226900 Wiring Diagram, 115V
5226901 Wiring Diagram, 230V
5230600 Pressure Relief Valve (included on CA)
Description
43
