LABCONCO CORPORATION
Quick Start Installation Guide for CentriVap
and Cold Traps
Preparations
Do not discard packaging until you have identified all parts that were shipped, and the
products operate properly.
Safety Precautions
The following safety precautions must be followed by all personnel unpacking the
equipment.
Wear safety glasses and Wear gloves
No loose fitting clothes
Wear close-toed shoes
The packaging allows for lifting with a mechanical lift truck or hand truck. If you
must lift the equipment manually, use at least two (2) persons and follow safe
lifting guidelines.
Packaging
Unit ships on runners/skid – weight varies 60 lbs. to 210 lbs.
Accessories will be in boxes – up to 74 lbs.
Requirements
Tools & Equipment
Box knife
Flat-blade screwdriver
5/16" nut driver
Mechanical lift truck or hand truck
Labor
2 people
Location
Flat surface space to accommodate each components footprint.
A fume hood will be required if hazardous solvents will be used in the
concentrator.
Part Number 1071000, Rev. -, ECO N235
8811 Prospect Ave, Kansas City, MO 64132 (816) 333-8811
or (800) 821-5525 • (816) 363-0130 fax • labconco.com
®
Concentrators
Page 1 of 7
Advertisement
Related Manuals for Labconco CentriVap Concentrators
Summary of Contents for Labconco CentriVap Concentrators
- Page 1 LABCONCO CORPORATION 8811 Prospect Ave, Kansas City, MO 64132 (816) 333-8811 or (800) 821-5525 • (816) 363-0130 fax • labconco.com ® Quick Start Installation Guide for CentriVap Concentrators and Cold Traps Preparations Do not discard packaging until you have identified all parts that were shipped, and the products operate properly.
- Page 2 Electrical Frequency must agree with the serial tag rating. Improper frequency will damage the compressor. Dedicated single phase circuit Additional appliances on the same circuit may cause the current to exceed the rating of the circuit breaker or fuse. Requirements with Requirements without Description...
- Page 3 Diagram #1 Vacuum pump Secondary Trap (if necessary) Cold Trap CentriVap Centrifugal Concentrator Join components together using the hoses provided. Hoses will be secured to CentriVap component connections with clamps provided. Use 5/16” nut driver to tighten clamps. Attach one hose to the tube that extends out the back of the Concentrator. Attach the other end of this hose to one of the barb fittings on the Cold Trap Cover Assembly.
- Page 4 If the CentriVap Concentrator or Cold Trap fails to perform as expected, consult the User’s Manual for troubleshooting or call Labconco at 1-800-821-5525. This Quick Start Installation Guide may not provide all the information necessary for your particular CentriVap Concentrator installation. For further details and precautions, access to video links and the full user’s manual, scan the QR Code...
- Page 5 Appendix A. Vacuum Pump Set Up It is important that the end user carefully reviews the Vacuum Pump User’s Manual for warnings, precautions, and operating instructions. Vacuum pumps can be permanently damaged if proper operating conditions and maintenance requirements are not met. Diaphragm Vacuum Pump Set Up ...
- Page 6 Install Exhaust Filter NOTE: Rotary vane vacuum pumps must have an exhaust filter to prevent oil mist from exiting the pump and depleting the oil supply. On rotary vane pumps only, attach the exhaust filter to the exhaust port. Insert filters and centering rings if present.
- Page 7 Appendix B. Secondary Trap Set Up Secondary Chemical Traps minimize the exhausting of solvents into the atmosphere. Remove the two small plastic hole plugs. Attach the bracket to the side of the Cold Trap housing using the screws provided. ...
