Racelogic VBOX Touch Quick Start Manual page 12

17. The unit is now ready to display live Accel Test results.
18. By default, VBOX Touch will automatically start recording when travelling over 0.5 km/h, this can be changed
within the General Settings.
19. Tapping on the SD Card Icon
will manually start or stop logging data, overriding the
20. The Record Icon
will show when the unit is logging data to the SD card.
If you have come to a stop, but the Record Icon is still on, press the SD Card Icon to stop the logging before
removing the card.
Sometimes, due to poor satellite visibility in a garage or close to a building, the box may start recording, even if the
car is stationary. Always check the Record Icon before ejecting the card.
IMPORTANT – The SD card shouldn't be removed when the Record Icon is on as you may lose data.
Note: If for some reason the SD card is removed whilst still recording, it may need to be repaired using a PC
before it can be reused.
21. A screenshot of what is displayed on the screen can be taken at any time by pressing the
.
22. To reset all test results shown on the current screen, press the
.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/Quick_Start_Guides/VBOX_Touch_Accel_Mode_-
when green
Configured Logging Strategy.
Reset Button
Screenshot Button
_Quick_Start_Guide
12
