14. If you are intending to use the serial output from the
Test Suite or output lap timing parameters, go to
Output Mode to either VBOX Stream (live testing with VBOX Test Suite) or Lap Timing.
Note: Ensure correct hardware connections are made.
15. Press the Exit Button
to return to the Accel Test screen.
16. Take the vehicle outside and wait for the VBOX Touch to gain satellite lock. The
as solid green
, solid orange
or solid purple
depending on whether you have a VBOX Touch RTK unit.
Note: The first time that the unit is used, it may take up to 10 – 15 minutes to fully acquire satellites. After this, it
will usually take 1 – 2 minutes to acquire satellites.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/Quick_Start_Guides/VBOX_Touch_Accel_Mode_-
top CAN/Serial port
to conduct
Serial Output
within the Serial Port Settings and change the
Online Testing
with VBOX
Satellite Icon
should display
_Quick_Start_Guide
11
