McConnel ROBO-CHIPPER ROBOCUT Operations & Parts Manual page 68

DRIVE MODULE
Product: ROBO-CHIPPER
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
QTY. PART No.
1 4003277
12 4003241
8 4003208
22 4003213
1 4003278
30 4003212
1 4003279
11 4003225
4 4003280
4 4000212
1 4003281
1 4003260
4 4000759
1 4003282
4 4003283
2 4003284
4 4000760
1 4003285
6 4000078
6 4000865
1 4003286
3 4003287
1 4003288
1 4003289
1 4003290
2 4003222
2 4003223
2 4003228
1 4003291
4 4003219
2 4003292
6 4000385
6 4001527
1 4003293
2 4004008
1 4003294
1 4003295
2 4000758
6 4003296
2 4000416
2 4001381
1 4001396
DESCRIPTION
DRIVE MODULE
MOUNTING BRACKET
WASHER
BOLT
NUT
PUMP COVER
WASHER
COWL
WASHER
COVER PLATE
BOLT
BRACKET
CABLE
WASHER
COUPLING
GRUB SCREW
WASHER
WASHER
COUPLING
WASHER
LOCK NUT
LOCK PIN
KEY
ROLL PIN
FORK
PUMP
WASHER
BOLT
NUT
LEVER EXTENSION
NUT
BOLT
WASHER
BOLT
OIL TANK
BOLT
LEVER
PUMP BRACKET
WASHER
NUT
NUT
WASHER
MOTOR
