MAIN FRAME MODULE
Product: ROBO-CHIPPER
REF.
QTY.
PART No.
1
1
4003201
2
1
4003202
3
1
4003203
4
1
4003204
5
3
4003205
6
1
4003206
7
4
4003207
8
5
4003208
9
1
4003209
10
1
4003210
11
1
4003211
12
11
4003212
13
11
4003213
14
2
4003214
15
1
4003215
16
2
4003216
17
1
4003217
18
1
4003218
19
1
4003219
20
1
4003220
21
1
4003221
22
10
4003222
23
2
4003223
24
1
4003224
25
1
4003225
26
1
4003226
27
2
4003227
28
8
4003228
29
1
4003229
30
2
4003230
31
1
4003231
DESCRIPTION
MAIN FRAME MODULE
MAIN FRAME
COUPLING
ARM
WASHER
SPRING WASHER
BOLT
SERRATED WASHER
BOLT
NUT
BOLT
FLANGE COVER
WASHER
NUT
COVER PLATE
COVER PANEL
BUSH
SPRING
SPLIT PIN
NUT
BOLT
MOTOR
WASHER
BOLT
WASHER
SPRING WASHER
ROLLER
BEARING
NUT
BOLT
COVER PLATE
GRILLE KIT
