McConnel ROBO-CHIPPER ROBOCUT Operations & Parts Manual page 62

DISCHARGE CHUTE MODULE
Product: ROBO-CHIPPER
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
QTY. PART No.
1 4003232
1 4003233
15 4003213
2 4003234
1 4003235
2 4003236
1 4003237
1 4003238
1 4003239
12 4003212
1 4003229
1 4003240
1 4003241
4 4003242
4 4003208
1 4003243
1 4003244
DESCRIPTION
DISCHARGE CHUTE MODULE
DISCHARGE CHUTE
CURVED CHUTE
NUT
WASHER
BOLT
NUT
PIN
SPLIT PIN
DEFLECTOR
WASHER
BOLT
HANDLE
WASHER
FLANGE
BOLT
CHUTE EXTENSION
BOLT
