Appendix B

DIP Switch Settings

To access the DIP switched, remove the batteries from the battery
compartment. On the inside of the battery compartment, there is a window
with eight DIP switches (see Fig. B-1). The table below shows the functions
for each switch.
Caution: Make certain that power is turned off before changing the DIP
switch settings.
Switch Function
1 Temperature
2 Heat Flow
3, 4 Velocity /
Flow rate
5, 6 Pressure
7 User cal.
adjust
8 Data format
OFF: Degrees Fahrenheit (°F)
ON: Degrees Celsius (°C)
OFF: BTU/hr
ON: kW
3 ON, 4 OFF: m/s, l/s
3 OFF, 4 ON: m/s, m
3 OFF, 4 OFF: ft/min, ft
3 ON, 4 ON: m/s, m
5 OFF, 6 ON: Pa
5 ON, 6 ON: hPa
5 ON, 6 OFF: mm Hg
5 OFF, 6 OFF, if velocity is ft/min: in. H
5 OFF, 6 OFF, if velocity is m/s: mm H
OFF: Normal
ON: User calibration adjust mode
OFF: Decimals; DD:MM:YY
ON: Commas; MM:DD:YY
Settings
3
/hr
3
/min
3
/min
O
2
O
2
25
