TSI AIRASSURE PM2.5

INDOOR AIR QUALITY MONITOR

FIRMWARE UPDATE INSTRUCTIONS

APPLICATION NOTE PM2.5-005 (US)

The AirAssure™ instrumentation firmware can be upgraded in the field. This will require a micro

USB cable (not provided), personal computer and TSI AirAssure Update firmware utility program.

Follow the steps below for firmware update instructions.

Separating Cover from Base

To access the USB connector, remove the cover of the monitor by pressing fingers firmly on bottom

of device cover, squeeze, and pull outwards.

_____________________

TSI and TSI logo are registered trademarks of TSI Incorporated.

AirAssure is a trademark of TSI Incorporated.

Table of Contents

Do you have a question about the AIRASSURE PM2.5 and is the answer not in the manual?

Page 1 TSI AIRASSURE PM2.5 INDOOR AIR QUALITY MONITOR FIRMWARE UPDATE INSTRUCTIONS APPLICATION NOTE PM2.5-005 (US) The AirAssure™ instrumentation firmware can be upgraded in the field. This will require a micro USB cable (not provided), personal computer and TSI AirAssure Update firmware utility program.
Page 2 Attaching USB Cable Connect the unit to your personal computer using a Micro USB cable (not provided). The USB connector is on the left-hand side of the device. C A U T I O N Use caution when plugging in cable, as excessive perpendicular force may damage the connection.
Page 3 Run AirAssure Firmware Update Utility Program Once the AirAssure Update utility program has been downloaded, a shortcut will appear on your desktop. 1. Click on the shortcut icon to run the program. 2. Enter the Serial Port number determined from the COM Port Setup step above.
