SYSTEM OVERVIEW: IV-SMART+ VENTILATION UNIT
1.1

Construction

D
16
15
Figure 1: Overview of the iV-Smart+ standard variant ventilation unit
Components
A
External termination:
Smart | Flex
1 Weather protection hood base plate
2 Weather protection hood cover
3 Drip rail
B
Wall sleeve
4 R-D160 wall sleeve
5 Recess for controller connecting cable
The description of the components of all other possible external terminations can be found in the separate installation instructions
1)
of the respective external termination.
10
10
C
7
11
8
9
10
12
13
14
weather protection hood
1)
B
5
6
C
Thermal accumulator insert
(thermal accumulator and inVENTron)
6 Thermal accumulator with insulation
7 Thermal accumulator handle
8 Standard guiding vane (wide)
9 Xenion reversible fan
10 Slim guiding vane (narrow)
11 Guiding vane knob
12 BUS plug connection
D
Flair inner cover
13 Inner cover base plate
14 ISO Coarse 60 % dust filter
15 Inner cover panel
16 Spacer (4 x)
iV-Smart+ ventilation unit | Installation instructions
A
4
Standard variant
1
2
2
3
3
Smart Flex
1
