4
Wall / Ceiling Mount
2. Secure the desired mounting kit to the designated position with 2 screws.
3. Reassemble the outer case.
4. Put the installation sticker to the wall with the arrow pointing up.
5. Drill 2 holes according to the sticker and insert the 2 screw anchors to the 2 holes.
6. Secure the device to the wall with 2 long screws.
7. Optionally install the ground wire with the screw as shown below:
Ground Wire
8
