GV-IP Camera
Box Camera
Ultra Box Camera
Arctic Box Camera
Target Box Camera
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Quick Start Guide
ICH265HISIV114-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-BX120D and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-BX120D

Summary of Contents for GeoVision GV-BX120D

  • Page 1 GV-IP Camera Quick Start Guide Box Camera Ultra Box Camera Arctic Box Camera Target Box Camera Before attempting to connect or operate this product, ICH265HISIV114-A please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

      1.1.2 For H.264 Cameras ............7   1.2 Overview ..................8 1.2.1 GV-BX120D / 130D Series / 140DW / 220D Series /   320D Series / 520D..............8 1.2.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 2700 Series /3400 Series / 4700  ...
  • Page 4 Chapter 2 IR Arctic Box Camera ........23   2.1 Packing List................24   2.2 Overview .................. 27 2.2.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E /   2400-E / 3400-E / 4700-E / 5300-E........27   2.2.2 GV-BX2510-E / 5310-E..........28  ...
  • Page 5   2.4.2 GV-BX2510-E / 5310-E..........37   2.5 Notice for Using the IR Arctic Box Camera......40   2.5.1 Enabling IR LED after Loading Default ....... 41   2.5.2 Disabling Status LED under Low Light Conditions ..42   2.6 Loading Factory Default............43  ...
  • Page 6   4.5.2 Directly on the Camera ..........56   Chapter 5 Accessing the Camera......... 57   5.1 System Requirement ............... 57   5.2 Accessing the Live View ............58   5.2.1 Checking the Dynamic IP Address ......59   5.2.2 Configuring the IP Address ......... 61  ...

  • Page 7: Caution

    Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Safety Notice The GV-IPCAM uses a Lithium battery as the power supply for its internal real-time clock (RTC). The battery should not be replaced unless required! If the battery does need replacing, please observe the following: •...

  • Page 8: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The power adapter is available for all Box Camera, Ultra Box Camera, and Target Box Camera. Contact Power Adapter your sales representative for the countries and areas supported.
  • Page 9 Device Description The GV-WiFi Adapter is a plug-and-play device designed to connect your camera to to wireless network. The product complies with IEEE 802.11 b/g/n (Draft 3.0) standards for wireless networking. GV-WiFi Adapter Note: Only compatible models and firmware versions can support GV-WiFi Adapter. The GV-Relay V2 is designed to expand the voltage load of GV IP devices.

  • Page 10: Creating Gv-Ip Camera's Login Credentials

    Creating GV-IP Camera’s Login Credentials The default Administrator and Guest accounts are no longer supported by GV-IPCAM H.265 series firmware V1.14 or later. When purchasing a new camera or performing factory resetting, you need to set up a login username and password for the camera. Download and install GV-IP Device Utility from the company website.

  • Page 11: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 12: Note For Usb Storage And Wifi Adapter

    Note for USB Storage and WiFi Adapter Mind the following limitations and requirements for using USB storage and GV-WiFi Adapter: The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above. The USB hard drive’s storage capacity must not exceed 2TB. USB flash drives and USB hubs are not supported.

  • Page 13: Chapter 1 Box Camera

    The Box Camera models are detailed below: Box Camera Model No. Specifications Description Auto Iris, f:2.8 ~ 12 1.3 MP, H.264, GV-BX120D mm, F/1.4, 1/3” CS Low Lux, D/N Lens Varifocal Lens Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, GV-BX130D-0 mm, F/1.4, 1/3’’...
  • Page 14 Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 Varifocal 2 MP, H.264, GV-BX220D-3 mm, F/1.4, 1/3’’ CS Lens Lens Auto Iris, f:3.1 ~ 8 GV-BX320D-0 mm, F/1.2, 1/3” CS Lens 3 MP, H.264, Auto Iris, f: 2.8 ~ 6 Varifocal GV-BX320D-1 mm, F/1.3, 1/3’’...
  • Page 15 Box Camera Model No. Specifications Description 1.3 MP, H.264, GV-BX1200-2F Low Lux, D/N 1.3 MP, H.264, GV-BX1300-2F 1.3 MP, H.264, GV-BX1500-2F Super Low Fixed Iris, f: 12 mm, Lux, D/N Fixed Lens F/1.6, 1/2.5’’ CS 2 MP, H.264, Lens GV-BX2400-2F D/N, WDR Pro 2 MP, H.264, GV-BX2500-2F...
  • Page 16 Model No. Specifications Description Auto Iris, f: 4.5 ~ 10 Varifocal 5 MP, H.264, GV-BX5300-6V mm, F/1.6, 1/2’’ CS Lens Lens 1.3 MP, H.264, GV-BX1500-8F Super Low Lux, D/N 2 MP, H.264, GV-BX2500-8F Super Low Fixed Iris, f: 2.8 mm, Lux, D/N F/1.8, 1/2.5’’...
  • Page 17 Box Camera P-Iris Models Model No. Specifications Description 1.3 MP, H.264, GV-BX1500-3V Super Low Lux, D/N P-Iris, f: 3 ~ 10.5 2 MP, H.264, Super GV-BX2500-3V mm, F/1.4, 1/2.5” Low Lux, D/N CS Lens 3 MP, H.264, D/N, GV-BX3400-3V WDR Pro Varifocal P-Iris, f: 3 ~ 10.5 2 MP, H.265, Super...

  • Page 18: Packing List

    1.1 Packing List 1.1.1 For H.265 Cameras • Box Camera • Terminal Block (2-Pin and 3-Pin) • Fixed Focal or Varifocal Megapixel Lens • Six Lens Rings (only for Varifocal Lens) • Video Out Wire • Camera Holder • Holder Screw x 2 •...

  • Page 19: For H.264 Cameras

    Box Camera 1.1.2 For H.264 Cameras • Box Camera • Terminal Block (2-Pin and 3-Pin) • Fixed Focal or Varifocal Megapixel Lens • Six Lens Rings (only for Varifocal Lens) • Video Out Wire • Camera Holder • Holder Screw x 2 •...

  • Page 20: Overview

    12 13 Figure 1-1 Note: 1. The Auto Iris connector (No. 7) is only functional in GV-BX120D, GV-BX130D-0, GV-BX220D and GV-BX320D. 2. The Light Sensor (No.11) is only available in GV-BX140DW. Keep the Light Sensor unobscured for accurate light detection.
  • Page 21 Box Camera Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. I/O Terminal For details, see 1.5 I/O Terminal Block. Block Indicates the power is supplied. For detail, see Power LED the table below.

  • Page 22: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400

    1.2.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 2700 Series /3400 Series / 4700 Series / 5300 Series / 5700 Series / 12201 Figure 1-2-1 Figure 1-2-2: GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 2700 Series / 3400 Series / 4700 Series / 5300 Series / 5700 Series...
  • Page 23 Box Camera Note: The Auto Iris Connector (No. 8) is only functional for the models with auto iris lens. The Iris Screw (No. 12) is only available in GV-BX5300-6V. The Zoom Screw (No. 13) doesn’t work on the models with fixed lens.
  • Page 24 Name Description LAN / PoE Connects to a 10/100 Ethernet or PoE. Restores the camera to factory default. For Default details, see 1.7 Loading Factory Default. Iris Screw Adjusts the iris of the camera. Zoom Screw Adjusts the zoom of the camera. Microphone Records the sounds.

  • Page 25: Connecting The Camera

    1.3 Connecting the Camera The Box Camera is designed for indoor use. Please make sure the installing site is shielded from rain and moisture. 1.3.1 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D Figure 1-3 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 26 Optionally connect to input / output devices or an infrared illuminator. For details, see 1.4.2 Infrared Illuminator and 1.5 I/O Terminal Block. Connect power using one of the following methods: • plugging the power adapter to the power port. • using the Power over Ethernet (PoE) function and the power will be provided over the network cable.

  • Page 27: Gv-Bx1200 Series / 1300 Series / 1500 Series / 2400

    Box Camera 1.3.2 GV-BX1200 Series / 1300 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 2700 Series / 3400 Series / 4700 Series / 5300 Series / 5700 Series / 12201 Figure 1-4 If you are using an auto iris model, plug the iris control cable to the Auto Iris Connector on the camera.
  • Page 28 Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 4.1.1 Video Settings, GV-IPCam Firmware Manual. Optionally connect to input / output devices or an infrared illuminator. For details, see 1.4.2 Infrared Illuminator and 1.5 I/O Terminal Block.

  • Page 29: Accessory Installation

    Box Camera 1.4 Accessory Installation 1.4.1 C-Mount Lenses If you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then secure the lens onto the camera body. Three types of C-mount lens rings are provided for Box Camera: •...

  • Page 30: Infrared Illuminators (Optional)

    1.4.2 Infrared Illuminators (Optional) If you use an infrared (IR) illuminator with I/O function, follow the steps below to install it. Connect the infrared illuminator to the terminal block on the camera. See 1.5 The I/O Terminal Block. Access the Web interface of the camera. Select Video and Motion , select Video Settings , select Streaming 1 and set the IR Check Function setting to Trigger by Input .

  • Page 31: I/O Terminal Block

    Box Camera 1.5 I/O Terminal Block The terminal block, located on the back panel of the Box Camera, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E- Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 32: Connecting To Gv-Relay V2 (Optional)

    1.5.2 Connecting to GV-Relay V2 (Optional) The Box Camera can only drive a maximum load of 200mA 5V DC . To expand the maximum voltage load to 10A 250V AC , 10A 125V AC or 5A 100V DC , connect the camera to a GV-Relay V2 module (optional product). Refer to the figure and table below.

  • Page 33: Loading Factory Default

    Box Camera 1.6 Loading Factory Default You can restore factory default settings through the Web interface or directly on the camera. 1.6.1 Using the Web Interface On the left menu of Web interface, select Management and select Tools . The Additional Tools dialog box appears. Click the Load Default button in the System Settings section.

  • Page 34: Directly On The Camera

    1.6.2 Directly on the Camera Keep the power and network cables connected to the camera. Use a pin to press and hold the default button on the back panel of the camera. Default button Figure 1-9 Release the default button when the status LED blinks. This shall take about 8 seconds.

  • Page 35: Chapter 2 Ir Arctic Box Camera

    IR Arctic Box Camera Model No. Specifications Description Auto Iris, f: 2.8 ~ 12 1.3 MP, H.264, GV-BX120D-E mm, F/1.4, 1/3” CS Low Lux, D/N Lens Auto Iris, f: 2.8 ~ 6 mm, GV-BX220D-E 2 MP, H.264, D/N F/1.3, 1/3’’ CS Lens Auto Iris, f: 2.8 ~ 6 mm,...
  • Page 36 Model No. Specifications Description Manual Iris, f: 4.5 ~ 5 MP, H.264 GV-BX5300-E Varifocal Lens 10 mm, F/1.6, 1/2’’ CS Lens P-Iris, f: 3.7 ~ 9 mm, 2 MP, H.264, GV-BX2510-E F/1.2, 1/2’’, ø 14 Super Low Lux, mm mount Motorized Varifocal Lens P-Iris, f: 4.5 ~ 9 mm,...

  • Page 37: Packing List

    IR Arctic Box Camera 2.1 Packing List For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 4700-E / 5300-E • IR Arctic Box Camera • Screw Anchor x 4 • Screw x 4 • Washer x 4 •...
  • Page 38 For GV-BX2510-E / 5310-E • IR Arctic Box Camera • Screw Anchor x 4 • Screw x 4 • Washer x 4 • 5 mm Torx Wrench • Silica Gel Bag • Adhesive Tape for Silica Gel Bag • Power Adapter (DC 48V, 2.5A, 120 W max.) •...

  • Page 39: Overview

    IR Arctic Box Camera 2.2 Overview 2.2.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400 -E / 3400-E / 4700-E / 5300-E Figure 2-1 Note: The Iris Screw (No. 7) is only available in GV-BX520D-E and GV- BX5300-E.

  • Page 40: Gv-Bx2510-E / 5310-E

    2.2.2 GV-BX2510-E / 5310-E Figure 2-2 Name Description Silica gel bag Desiccant that keeps the camera housing dry. Memory Card Inserts a micro SD card (SD/SDHC, version Slot 2.0, Class 10) to store recording data. Turns on when the camera is supplied with Power LED power.

  • Page 41: Installation

    IR Arctic Box Camera 2.3 Installation The IR Arctic Box Camera is designed for outdoor use. Follow the steps below to install your camera. Mark the installation site and drill four holes for screw anchors. Insert the supplied screw anchors. Secure the camera to the wall using the supplied washers and screws.
  • Page 42 Based on the live view, adjust the angle of the camera. Loosen the indicated screw with the supplied big torx wrench and adjust the joint. Figure 2-4 Tilt Adjustment Figure 2-5 Pan Adjustment Figure 2-6...
  • Page 43 IR Arctic Box Camera For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 4700-E / 5300-E , adjust for image clarity based on the live view. A. Unscrew the cover with the supplied 4 mm torx wrench.
  • Page 44 C. Adjust the focus, zoom and iris screws. For a more precise focus, use GV-IP Device Utility. For details, see 5.3 Adjusting Image Clarity. Focus screw Iris screw Zoom screw Figure 2-9 Note: Only GV-BX520D-E and GV-BX5300-E contain an iris screw. D.
  • Page 45 IR Arctic Box Camera For GV-BX2510-E / 5310-E , optionally insert a memory card. A. Open the camera cover using the supplied torx wrench. Figure 2-11 B. Insert a memory card to the card slot. Memory card slot Figure 2-12...
  • Page 46 C. Replace the silica gel bag. Paste the sticker to the silica gel bag. Press the silica gel bag several times onto the camera cover to make sure it adheres properly. Figure 2-13 D. Follow step 8A to close the camera cover.

  • Page 47: Connecting The Camera

    IR Arctic Box Camera 2.4 Connecting the Camera 2.4.1 GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 4700-E / 5300-E Figure 2-14 Wire Definition RJ-45 Black BNC TV out Green RCA Audio Out Pink RCA...
  • Page 48 Optionally connect a speaker (green) and an external microphone (pink). Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface. See 4.1.1 Video Settings, GV-IPCam Firmware Manual.

  • Page 49: Gv-Bx2510-E / 5310-E

    IR Arctic Box Camera 2.4.2 GV-BX2510-E / 5310-E Figure 2-15 Wire Definition Green RCA Audio Out Pink RCA Audio In Brown wire Digital Output Yellow wire Digital Input White wire Terminal Block DC 48V TV Out RJ-45 Ethernet/PoE...
  • Page 50 1. Optionally connect the audio out (green), audio in (pink), digital output (brown), digital input (yellow), and GND. 2. Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface.
  • Page 51 IR Arctic Box Camera • Use the supplied power adapter. Connect the black wire of the power adaptor to the plus (+) port and the white wire to the negative (-) port. Connect the camera to network with a network cable. Terminal Block from DC 48V Power Adaptor the Camera Cable...

  • Page 52: Notice For Using The Ir Arctic Box Camera

    2.5 Notice for Using the IR Arctic Box Camera For GV-BX120D-E / 220D-E / 320D-E / 520D-E / 1500-E / 2400-E / 3400-E / 4700-E / 5300-E , make sure that you: • enable IR LED function on the Web interface after loading the default settings.

  • Page 53: Enabling Ir Led After Loading Default

    IR Arctic Box Camera 2.5.1 Enabling IR LED after Loading Default Each GV-IR Arctic Box Camera is equipped with 4 IR LEDs to provide infrared illumination at night. The factory-loaded setting for the IR LED function is enabled . If you have restored the camera to default settings, please follow the steps below to enable the IR LED function.

  • Page 54: Disabling Status Led Under Low Light Conditions

    2.5.2 Disabling Status LED under Low Light Conditions If you have a green light spot on the live view, this is likely due to insufficient light at the installation site, which causes the status LED to reflect on the camera cover. In this case, it is advisable that you disable the status LED.

  • Page 55: Loading Factory Default

    IR Arctic Box Camera 2.6 Loading Factory Default 2.6.1 Using the Web Interface You can restore factory default settings through the Web Interface. For details, see 1.6.1 Using the Web Interface, Loading Factory Default. 2.6.2 Directly on the Camera Note that only GV-BX2510-E and GV-BX5310-E are equipped with a default button.

  • Page 56: Chapter 3 Ultra Box Camera

    Chapter 3 Ultra Box Camera The Ultra Box Camera is a series of light-weighted cameras designed for indoor usage. Equipped with IR-cut filter and built-in IR LEDs, the Ultra Box Camera provides excellent image quality. The camera supports PoE and can be installed intuitively.

  • Page 57: Packing List

    Ultra Box Camera 3.1 Packing List • Ultra Box Camera • Supporting rack • Screw x 3 • Screw anchor x 3 • Power Adapter • Download Guide • Warranty Card Note: The power adapter can be excluded upon request.

  • Page 58: Overview

    3.2 Overview Figure 3-1 Name Description Audio Out Connects a speaker for audio output. Resets the camera to factory default. Default For details, see 3.5 Loading Factory Default. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. Inserts a micro SD card (SD/SDHC, Memory Card Slot version 2.0 only, Class 10) to store...

  • Page 59: Installation

    Ultra Box Camera 3.3 Installation You can stand the Ultra Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Ultra Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 60 Connect the network and power cables to the camera. See 3.4 Connecting the Camera. Access the live view. See 5.2 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw. Figure 3-4...

  • Page 61: Connecting The Camera

    Ultra Box Camera 3.4 Connecting the Camera Figure 3-5 Connect power using one of the following methods: • Plug the power adapter to the 5V terminal block. The power adapter is an optional device. For detail, see Options in the manual.

  • Page 62: Loading Factory Default

    3.5 Loading Factory Default 3.5.1 Using the Web Interface You can restore factory default settings through the Web Interface. For details, see 1.6.1 Using the Web Interface, Loading Factory Default. 3.5.2 Directly on the Camera Press and hold the default button for about 8 seconds to restore the factory default.

  • Page 63: Chapter 4 Target Box Camera

    Target Box Camera Chapter 4 Target Box Camera The Target Box Camera (GV-EBX) is a series of light-weighted cameras designed for indoor usage. Equipped with IR­cut filter and built­in IR LEDs, the camera is an entry-level surveillance solution with all the essential features and excellent image quality.

  • Page 64: Overview

    4.2 Overview Figure 4-1 Name Description Resets the camera to factory default. For Default details, see 4.5 Loading Factory Default. LAN / PoE Connects to a 10/100 Ethernet or PoE. Microphone Records sounds. DC 12V Terminal Connects to power. Block LED Indicator Description The status LED turns on (green) when the...

  • Page 65: Installation

    Target Box Camera 4.3 Installation You can stand the Target Box Camera on a plain surface or install it to wall and ceiling. Follow the steps below to install, connect and adjust your Target Box Camera. To install the device on the wall/ceiling, put the supporting rack on the desired location and make marks for screw anchors.
  • Page 66 Connect the network and power cables to the camera. See 4.4 Connecting the Camera. Access the live view. See 5.2 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw. Figure 4-4...

  • Page 67: Connecting The Camera

    Target Box Camera 4.4 Connecting the Camera Figure 4-5 Connect power using one of the following methods: • Plug the power adapter to the 12V terminal block. The power adapter is an optional device. For detail, see Options in the manual.

  • Page 68: Loading Factory Default

    4.5 Loading Factory Default 4.5.1 Using the Web Interface You can restore factory default settings through the Web Interface. For details, see 1.6.1 Using the Web Interface, Loading Factory Default. 4.5.2 Directly on the Camera Press and hold the default button for about 8 seconds to restore the factory default.

  • Page 69: Chapter 5 Accessing The Camera

    Accessing the Camera Chapter 5 Accessing the Camera 5.1 System Requirement To access the GV-IP Camera through the Web browser, ensure your PC connects to the network properly and meets this system requirement: • Microsoft Internet Explorer 8.0 x or later Note: For the users of Internet Explorer 8 , additional settings are required.

  • Page 70: Accessing The Live View

    5.2 Accessing the Live View When the camera is connected to a network with a DHCP server, it will be automatically assigned with a dynamic IP address. See 5.2.1 Checking the Dynamic IP Address to look up this IP address. However, if you do not have a DHCP server on your network, access the camera by its default IP address 192.168.0.10 and see 5.2.2 Configuring the IP Address for more detail.

  • Page 71: Checking The Dynamic Ip Address

    Accessing the Camera 5.2.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Note: The computer you use to configure the IP address must be under the same LAN with your camera. The default Administrator and Guest accounts are no longer supported by GV-IP Camera H.265 series firmware V1.14 or later .
  • Page 72 The login page appears. Figure 5-2 Type the default ID and password admin and click Apply to log in.

  • Page 73: Configuring The Ip Address

    Click Apply . The camera is now accessible by entering the assigned IP address on the Web browser. To enable the updating of images in Microsoft Internet Explorer, you must set your browser to allow ActiveX Controls and perform a one- time installation of GeoVision’s ActiveX component onto your computer.
  • Page 74 Important: If Dynamic IP Address or PPPoE is enabled, you need to know which IP address the camera will get from DHCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP address. See 5.2.1 Checking the Dynamic IP Address in the Quick Start Guide.

  • Page 75: Configuring The Wireless Connection

    Accessing the Camera 5.2.3 Configuring the Wireless Connection You may create wireless connection to the Internet for GV-BX1200 series / 1500 series / 2400 series / 2700 series / 3400 series / 5300. To set up the wireless LAN for the first time, power on and connect a standard network cable to the camera.
  • Page 76 Select the Authentication Type using the drop-down list. You can also obtain this information by clicking the Access Point Survey button. Type the WPA-PSK Pre-shared Key or WEP depending on the encryption setting for the Access Point. Click Apply to save the configuration. Note: Your encryption settings must match those used by the Access Points or wireless stations with which you want to associate.
  • Page 77 Accessing the Camera Enable wireless LAN. On the Web interface, select Network and LAN . This page appears. Figure 5-5 Select Wireless for Optional Network Type. To use a dynamic IP address assigned by the DHCP server, select Dynamic IP address . To use a fixed IP address, select Static IP address and type the IP address information.

  • Page 78: Adjusting Image Clarity

    5.3 Adjusting Image Clarity You can adjust the image clarity using the GV-IP Device Utility. Make sure that you have connected your GV-IPCAM to the network and install the GV-IP Device Utility program under the same LAN. Make sure you have downloaded and installed GV-IP Device Utility from the company website On the GV-IP Utility window, click the...
  • Page 79 Accessing the Camera Note: For locations of adjustment screws and rings in each model, see Locations of Adjustment Screws, section, Getting Started Chapter, GV-IPCAM Firmware Manual. Do not over tighten the screws. The screws only need to be as tight as your fingers can get them to be. Do not bother using any tool to get them tighter.

  • Page 80: Chapter 6 The Web Interface

    Chapter 6 The Web Interface 12 13 Figure 6-1...
  • Page 81 The Web Interface No. Name Function Play Plays live video. Stop Stops playing video. Broadcasts to the surveillance site from a remote PC. Note this function is not available for Ultra Bullet Camera and Target Series . For Cube Camera and Advanced Cube Camera , click the Microphone Push to talk button (from the pop-up menu) for the camera to switch between audio transmission and...
  • Page 82 No. Name Function Enables the PTZ Control Panel or the Visual PTZ. Note this function is supported by PTZ Camera PTZ Control Panel and PT Camera , and only partially supported by GV-IP Cameras with motorized varifocal lens . Enables the I/O Control Panel and Visual Automation.

  • Page 83: Chapter 7 Upgrading System Firmware

    Upgrading System Firmware Chapter 7 Upgrading System Firmware GeoVision periodically releases updated firmware on the website. The new firmware can be simply loaded into the GV-IPCAM by using the Web interface or IP Device Utility. Before you start If you use the IP Device Utility for firmware upgrade, the computer used to upgrade firmware must be under the same network of the camera.
  • Page 84 1. In the Live View window, click the Show System Menu button and select Remote Config . This dialog box appears. Figure 7-1 2. Click the Browse button to locate the firmware file (.img) saved at your local computer. 3. Click the Upgrade button to start the upgrade.
