Quick Start Guide
GV-3D People Counter V2
V1.00
Before attempting to connect or operate this product,
3DPC2V10-QG-A
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-3D People Counter V2 and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-3D People Counter V2

Summary of Contents for GeoVision GV-3D People Counter V2

  • Page 1 Quick Start Guide GV-3D People Counter V2 V1.00 Before attempting to connect or operate this product, 3DPC2V10-QG-A please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    2.2 Rear View ..........................3 3. Connection ........................4 4. Wall / Ceiling Mount ....................... 5 5. Accessing the Web Interface ..................7 5.1 Setting the GV-3D People Counter V2 ................... 8 5.2 Accessing Counting Results ....................11 6. Upgrading the Firmware ....................12...

  • Page 4: Introduction

    1. Introduction Welcome to the GV-3D People Counter V2 Quick Start Guide. In the following sections, you will learn about the basic installations and configurations of the GV-3D People Counter V2. For the detailed user’s manual, see GV-3D People Counter V2 User’s Manual.

  • Page 5: Options

    Introduction 1.2 Options Optional devices can expand your GV-3D People Counter V2’s capabilities and versatility. Contact your dealer for more information. Options for GV-3D People Counter V2 Options Description Receive the GPS signals for 3D People Counter V2 positioning. GV-GPS Receiver...

  • Page 6: Overview

    2. Overview 2.1 Bottom View No. Name Function Lens Fixed lens for capturing people image.

  • Page 7: Rear View

    Overview 2.2 Rear View No. Name Function Ethernet Port A plug for PoE (IEEE 802.3af). Default Button It resets all configurations to their factory settings. The connectors for the sensor input, alarm output and GPS Terminal Block receiver. Insert a micro SD card (SD/SDHC/SDXC/UHS ‐I, Class 10) to Memory Card Slot store recording data.

  • Page 8: Connection

    1. Connect to a standard network cable or PoE for power supply and Internet connection. 2. Insert a micro SD card. Note: GV-3D People Counter V2 only supports PoE. You may purchase GV-PA191 PoE adapter to connect to your router. See 1.2 Options.

  • Page 9: Wall / Ceiling Mount

    4. Wall / Ceiling Mount You can use the Wall / Ceiling Mount Kit to mount GV-3D People Counter V2 on a desired location. Wall Mount Ceiling Mount 1. Remove the GV-3D People Counter V2’s outer case.
  • Page 10 5. Drill 2 holes according to the sticker and insert the 2 screw anchors to the 2 holes. 6. Secure the the GV-3D People Counter V2 to the wall with 2 long screws. 7. Optionally install the ground wire with the screw as shown below:...

  • Page 11: Accessing The Web Interface

    Lite to look up counting data. The GV-Web Report Lite is a Web server built in the GV-3D People Counter V2. By default, when the GV-3D People Counter V2 is installed to a LAN with the DHCP server, the GV-3D People Counter V2 uses a dynamic IP address assigned by the server.

  • Page 12: Setting The Gv-3D People Counter V2

    5.1 Setting the GV-3D People Counter V2 1. To set the GV-3D People Counter V2, click the Setup tab on the top. This dialog box appears. 2. Draw a box on the live view to mark the boundary of the detection zone. To change the direction of the In / Out arrows, click the Change button after In/Out Direction Change on the right.
  • Page 13 Accessing the Web Interface 3. For more precise counting results, specify the height of the GV-3D People Counter V2 in the Device Height field and the minimum people height in the Minimum People Height field. Select the Device and Object Distance to adjust range of people counting.
  • Page 14 Report, select Report to Server and type the IP address, port, name and password of the GV-Web Report Lite or GV-Web Report. For details, see 3.2 The Web Interface in the GV-3D People Counter V2 User’s Manual. Note: GV-3D People Counter V2 is only compatible with GV-Web Report V2.2.6.0 or later.

  • Page 15: Accessing Counting Results

    5.2 Accessing Counting Results After setting up the GV-3D People Counter V2 to start collecting data, you can access the people counts, tables and charts. Use one of the tabs below in GV-Web Report Lite to look up the data.

  • Page 16: Upgrading The Firmware

    6. Upgrading the Firmware We will periodically release the updated firmware on the website. You can update firmware by using GV-Web Report Lite. Download the latest firmware to your computer. Log onto the GV-Web Report Lite and click Setup on the upper right. Select the FW tab.
