GV-3D People Counter V2
User's Manual V1.00
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
3DPC2V10-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-3D People Counter V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-3D People Counter V2

Summary of Contents for GeoVision GV-3D People Counter V2

  • Page 1 GV-3D People Counter V2 User’s Manual V1.00 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. 3DPC2V10-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    2.3 Wall / Ceiling Mount....................7   Chapter 3 The Web Interface.................... 9   3.1 Accessing the GV-Web Report Lite................9   3.2 Setting the GV-3D People Counter V2..............10   3.2.1 General Settings..................11   3.2.2 People Counter Settings ................20  ...

  • Page 4: Firmware And Software Compatibility

    Firmware and Software Compatibility The GV-VMS and GV-Web Report compatible with GV-3D People Counter V2 are listed below Model GV-VMS GV-Web Report GV-3D People Counter V2 V1.00 V16.10.3.0 or later V2.2.6.0 or later Note: For showing the people counting data on GV-VMS’s live view, see 3.18 Video Analysis...

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction The GV-3D People Counter V2 can count and analyze the number of people passing by the designated area at high precision counting accuracy. With its Power over Ethernet and user-friendly interface, the counter is simple to use and easy to install. You can look up neatly compiled people counting data in chart analysis with the support of GV-Web Report Lite, its built-in Web interface.

  • Page 6: Packing List

    1.1 Packing List GV-3D People Counter V2 Installation Sticker x 2 (Wall mount / Ceiling mount) SDHC Micro SD card Screw x 4 Ceiling Mount Kit Wall Mount Kit Anchor x 2 Documents Download Guide Warranty Card...

  • Page 7: Options

    1.2 Options Optional devices can be purchased separately for GV-3D People Counter V2. Contact your dealer for more information. Options Details Receive the GPS signals for 3D People Counter GV-GPS Receiver positioning. Through a Web browser, the GV-Web Report keeps track...

  • Page 8: Overview

    Introduction 1.3 Overview This section identifies the components of the GV-3D People Counter V2. 1.3.1 Bottom View Figure 1-2 No. Name Function Lens Fixed lens for capturing people image.

  • Page 9: Rear View

    1.3.2 Rear View Figure 1-3 No. Name Function Ethernet Port A plug for PoE (IEEE 802.3af). Default Button It resets all configurations to their factory settings. The connectors for the sensor input, alarm output and GPS Terminal Block receiver. Insert a micro SD card (SD/SDHC/SDXC/UHS-I, Class 10) to Memory Card Slot store recording data.

  • Page 10: Chapter 2 Getting Started

    1. Connect to a standard network cable or PoE for power supply and Internet connection. 2. Insert a micro SD card. Note: GV-3D People Counter V2 only supports PoE. You may purchase GV-PA191 PoE adapter to connect to your router. See 1.2 Options.

  • Page 11: Restoring To Factory Default Settings

    2.2 Restoring to Factory Default Settings If for any reason the GV-3D People Counter V2 is not responding correctly, you can restore the GV-3D People Counter V2 to factory default settings. Green LED Default Button Figure 2-2 Press and hold the Default button on the rear panel.

  • Page 12: Wall / Ceiling Mount

    Getting Started 2.3 Wall / Ceiling Mount You can use the Wall / Ceiling Mount Kit to mount GV-3D People Counter V2 on a desired location. Wall Mount Ceiling Mount 1. Remove the GV-3D People Counter V2’s outer case. Figure 2-3...
  • Page 13 5. Drill 2 holes according to the sticker and insert the 2 screw anchors to the 2 holes. 6. Secure the the GV-3D People Counter V2 to the wall with 2 long screws. 7. Optionally install the ground wire with the screw as shown below:...

  • Page 14: Chapter 3 The Web Interface

    Lite to look up counting data. The GV-Web Report Lite is a Web server built in the GV-3D People Counter V2. By default, when the GV-3D People Counter V2 is installed to a LAN with the DHCP server, the GV-3D People Counter V2 uses a dynamic IP address assigned by the server.

  • Page 15: Setting The Gv-3D People Counter V2

     Live View: Click to see the live image of the detection area captured by the infrared sensor of the GV-3D People Counter V2. The live image is in black and white.  REC: Records the live view for 30 seconds. Only one video can be stored in the SD card at a time.

  • Page 16: General Settings

    IP, SD, FW, Time, MEM, GPS, I/O, FTP. [User]  Machine Name: Change the display name of the GV-3D People Counter V2 if necessary.  Login Name / Password: Change the login name or password for accessing the GV-3D People Counter V2 if necessary. The default login name and password are admin.
  • Page 17 DHCP Server or ISP (in xDSL connection) has changed. Figure 3-4 1. Click Register to register a GeoVision DDNS Server or apply for a Host Name from other DDNS service provider’s website. 2. Type the Host Name used to link to the GV-3D People Counter V2.
  • Page 18 The Web Interface  SMTP Server: Type your SMTP Server’s URL address or IP address.  Port: The default port for most SMTP servers is 25. However webmail Yahoo and Hotmail generally use differently SMTP port. In this case, check your e-mail provider for the SMTP port number.
  • Page 19 After you have completed the Export settings, you shall receive the report in a zip file at the appointed time. The report in the zip file is as the figure below. Figure 3-7 [SCH] To enable people counting only during certain time of the day, click the checkbox and specify a time period.
  • Page 20 The Web Interface [IP] According to your network environment, select a Network Type.  DHCP: Select if your network environment has a DHCP server which can assign a dynamic IP to your device. By default, this option is enabled.  Static IP: To set up a fixed IP address, type the IP address, subnet Mask, DNS and Gateway of the static IP.
  • Page 21 [FW] You can download the latest firmware from the GeoVision’s Website at http://www.geovision.com.tw. Upload the downloaded file and click Apply. Figure 3-11 [TIME] To automatically synchronize the device time with the server time everyday, select Enable NTP Server Time SYNC. Scroll down the drop-down list to select when the device shall synchronize everyday at hourly basis.
  • Page 22 The Web Interface [MEM] By default, the counting result is reset to zero at 12:00 midnight everyday. To set a different reset time, use the Counting value reset drop-down list to select a different time and click Apply. After you have modified the reset time, you can also click Sync DB and the GV-Web Report Lite will synchronize the counting results to the Last Updated result.
  • Page 23 [I/O] You can select Enable Input / Output to enable the input and output device. Next to Normal State, you can set the input state to trigger actions by selecting Open Circuit (N/O) or Grounded Circuit (N/C). When you enable Trigger digital output relay, the output will be triggered once the input is activated.
  • Page 24 The Web Interface [FTP] The GV-3D People Counter V2 can act as a FTP server for external IP devices to download the recorded files saved on the memory card.  Enable FTP access to the GV-3D People Counter V2: Select this option to allow external IP devices to access GV-3D People Counter V2 as a FTP server.

  • Page 25: People Counter Settings

    3.2.2 People Counter Settings For more precise counting results, specify the height of the GV-3D People Counter V2 and the minimum people height. Figure 3-17 Type the height of the installed GV-3D People Counter V2 in the Device Height field.
  • Page 26 The Web Interface Click Detail button to see an illustration of the detectable height range and the dimension of the detection area based on the height you specified. Figure 3-18  Wrong Direction Alarm: Enable if the detection area is exit only or entrance only, and a wrong direction count will be recorded in GV-Web Report Lite under Counting Signage when GV-3D People Counter detects people going in the wrong direction.

  • Page 27: Report To Other Servers

    Counter V2 will be synchronized with the selected server. To cancel time synchronization, double-click the selected radio button. Note: GV-3D People Counter V2 is only compatible with GV-Web Report V2.2.6.0 or later. Dynamic domain name is not supported in the IP field.

  • Page 28: Accessing People Counting Data

    The Web Interface 3.3 Accessing People Counting Data After setting up the GV-3D People Counter V2 to start collecting data, you can access the people counts, tables and charts. Use one of the following tabs in GV-Web Report Lite to look up the data.
  • Page 29 The Total In, Total Out, Stay and Wrong Direction below the tables are the total number of people counted from all connected GV-3D People Counter V2. On the left menu, these options are available: ...

  • Page 30: Group

    The Web Interface 3.3.2 Group On the Group page, you can group the connected GV-3D People Counter V2, and see the people counts of the set group. You can also set up the maximum number of people entered, left and remaining to activate the computer alarm when the number is exceeded. E-mail notification can be activated when the number of people remaining reaches the pre-defined maximum.
  • Page 31 8. To organize multiple groups into subgroups, click Setting Group Relations in the left menu. Drag and drop a group under another group to make it a subgroup. Figure 3-22 On the left menu of the Group page, you can find these options: ...

  • Page 32: Log

    Figure 3-23 To search the log data: 1. Select a specific GV-3D People Counter V2 from the Device drop-down list or a created group from the Group drop-down list. 2. Specify Start Time and End Time of the log data.

  • Page 33: Query

    The Query page provides you with the daily, weekly, monthly and yearly people counting graphs and tables. To search the counting data, select a GV-3D People Counter V2 from the Device drop-down list or a created group from the Group drop-down list, specify a date, and select the options below.
  • Page 34 The Web Interface The following figure is an example of the In/Out Counts per hour and Total Stay option. The value 9, 19 indicates the count of remaining people until 9 am is 19. Figure 3-25 [Weekly Report] Display the weekly report that contains the data of 7 days before your specified date.
  • Page 35 The following figure is an example of the In Percentage per day option. The value 2017-07-20 (Thu), 180 (53.41%) indicates the total number of entered people on 2017/07/20 is 180. The number takes up 53.41 percent of the total people entered for the week. Figure 3-26 [Monthly Report] In Percentage per day: The daily percentage of people entered in the month.

  • Page 36: Chapter 4 Auxiliary Device Connectors

    Auxiliary Device Connectors Chapter 4 Auxiliary Device Connectors The 8-pin terminal block, located on the rear panel, provides interfaces for connecting a digital input, a relay output and a GV-GPS Receiver. Figure 4-1 PIN Assignment Pin Function Ground Digital Input Ground UART RX for GV-GPS Receiver UART TX for GV-GPS Receiver...

  • Page 37: Chapter 5 Gv-Ip Device Utility

    Chapter 5 GV-IP Device Utility GV-IP Device Utility can detect GV-3D People Counter V2 in the LAN and allows you to quickly set the IP address of the device, upgrade firmware and reboot the device. 5.1 Installing GV-IP Device Utility 1.

  • Page 38: Setting The Gv-3D People Counter V2

    1. To start the GV-IP Device Utility, go to Windows Start, point to Programs and select GV IP Device Utility. The window below appears and automatically searches for any GV-IP device under LAN. Figure 5-2 2. Double-click a GV-3D People Counter V2. This dialog box appears. Figure 5-3...
  • Page 39 Firmware Upgrade: To upgrade the firmware, click Browse to specify the path of the firmware file and click Upgrade to proceed. You can select Upgrade all devices to upgrade all other GV-3D People Counter V2 of the same username and password. ...

  • Page 40: Appendix

    Direct sunlight on the detection area may show up as a white region on the live view and interferes with people counting results. Avoid IR LED IR LED from the left of the view interferes with the IR sensor of the GV-3D People Counter V2 and causes part of the person’s head to appear dark.

  • Page 41: Detection Limitations

    Detection Limitations There are situations that may cause GV-3D People Counter V2 to falsely detect the number of people. Below are examples of situations that may or may not result in false detection. Actual: 1 Standing upright Counted: 1 Actual: 1...
  • Page 42 Appendix Actual: 2 Head to head Counted: 1 Actual: 2 One hand on shoulder Counted: 1 Actual: 4 Multiple people Counted: 4 Carrying a large backpack: Actual: 1 Backpack in close contact with the person’s head. Counted: 1 Actual: 2 Backpack at a distance from the person’s head.
  • Page 43 Pushing a cart: Actual: 1 Cart close to the person’s body. Counted: 1 Cart away from the person’s body. Actual: 1 Tip: Set a minimum detection height Counted: 2 that is higher than the cart to avoid false detection. ushing a wheelchair: Actual: 2 The person pushing the wheelchair is standing upright.

Table of Contents
