GV-3D People Counter V2
User's Manual V1.01
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
3DPC2V101-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-3D People Counter V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-3D People Counter V2

Summary of Contents for GeoVision GV-3D People Counter V2

  • Page 1 GV-3D People Counter V2 User’s Manual V1.01 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. 3DPC2V101-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    2.3 Wall / Ceiling Mount ....................10 Chapter 3 The Web Interface ...................12 3.1 Accessing the GV-Web Report Lite .................12 3.2 Setting the GV-3D People Counter V2 ..............13 3.2.1 Live View ....................13 3.2.2 People Counter Settings ................14 3.2.3 Report to Other Servers ................16 3.2.4 General Settings ..................17...

  • Page 4: Firmware And Software Compatibility

    The compatible versions of GV-VMS and GV-Web Report are listed below: Model GV-VMS GV-Web Report GV-3D People Counter V2 V1.01 V16.10.3.0 or later V2.2.6.0 or later Note: For showing the people counting data on GV-VMS’s live view, see Video Analysis by...

  • Page 5: Chapter 1 Introduction

    Introduction Chapter 1 Introduction The GV-3D People Counter V2 can count and analyze the number of people passing by the designated area at high precision counting accuracy. With its Power over Ethernet and user-friendly interface, the counter is simple to use and easy to install. You can look up neatly compiled people counting data in chart analysis with the support of GV-Web Report Lite, its built-in Web interface.

  • Page 6: Packing List

    1.1 Packing List GV-3D People Counter V2 Installation Sticker x 2 (Wall mount / Ceiling mount) SDHC Micro SD card Screw x 4 Ceiling Mount Kit Wall Mount Kit Anchor x 2 Download Guide Warranty Card...

  • Page 7: Optional Accessories

    Introduction 1.2 Optional Accessories Optional accessories can expand the capabilities of your device. Contact your dealer for more information. Options Details Receive the GPS signals for 3D People Counter GV-GPS Receiver positioning. Through a Web browser, the GV-Web Report keeps track of and analyzes the people counting results and shows GV-Web Report the latitude and longitude from up to 1000 units of GV-3D...

  • Page 8: Overview

    1.3 Overview This section illustrates the components of GV-3D People Counter V2. 1.3.1 Bottom View Figure 1-2 No. Name Function Captures people’s image. Lens...

  • Page 9: Rear View

    Introduction 1.3.2 Rear View Figure 1-3 No. Name Function Ethernet Port A plug for PoE (IEEE 802.3af). Default Button Resets all configurations to factory default settings. The connectors for the sensor input, alarm output and GPS Terminal Block receiver. Inserts a micro SD card (SD/SDHC/SDXC/UHS-I, Class 10) to Memory Card Slot store recording data.

  • Page 10: Chapter 2 Getting Started

    1. Plug a standard network cable or PoE to provide power supply and Internet connection. 2. Insert a micro SD card. Note: GV-3D People Counter V2 only supports PoE. You may purchase GV-PA191 PoE adapter to connect to your router.

  • Page 11: Restoring To Factory Default Settings

    Getting Started 2.2 Restoring to Factory Default Settings If for any reason the device is not responding correctly, you can restore it to its factory default settings. Green LED Default Button Figure 2-2 Press and hold the Default button on the rear panel. Release the Default button when the green LED stops blinking.

  • Page 12: Wall / Ceiling Mount

    2.3 Wall / Ceiling Mount You can use the Wall / Ceiling Mount Kit to mount the device on a desired location. Wall Mount Ceiling Mount 1. Remove the device’s outer case. Figure 2-3...
  • Page 13 Getting Started 2. Secure the desired mounting kit to the designated position with 2 screws. Figure 2-4 3. Reassemble the outer case. Figure 2-5 4. Put the installation sticker to the wall with the arrow pointing up. 5. Drill 2 holes according to the sticker and insert the 2 screw anchors to the 2 holes. 6.

  • Page 14: Chapter 3 The Web Interface

    Chapter 3 The Web Interface Once the GV-3D People Counter V2 is connected to the network, you can view counting data by using GV-Web Report Lite, a Web server built into the GV-3D People Counter V2. When the device is connected to a network with a DHCP server, it will be automatically assigned with a dynamic IP address.

  • Page 15: Setting The Gv-3D People Counter V2

    The Web Interface 3.2 Setting the GV-3D People Counter V2 Once logging into the GV-Web Report Lite, click the Setup tab on the top bar. The Setup page appears. Here, you can configure the people counting and / or the network settings of the device.

  • Page 16: People Counter Settings

    3.2.2 People Counter Settings In this panel, you can modify people counter settings, set up Counting Area, and reverse the direction of entrance on Live View. Figure 3-3 ◼ Device Height: Type the height of the installed device. Depending on the height where the device is installed, the range of detectable height for people varies.
  • Page 17 The Web Interface ◼ Detected Sensitivity: Adjust the detection sensitivity at Low, Medium or High. ◼ Detect Area: Apply or clear image masks on the live view. Select Mask Position to drag image masks to conceal certain area on the live view. People moving across the defined mask position will not make a count.

  • Page 18: Report To Other Servers

    If you click Time Sync under one of the servers, the current device time will be synchronized with the selected server. To cancel time synchronization, double-click Time Sync. Note: GV-3D People Counter V2 is only compatible with GV-Web Report V2.2.6.0 or later.

  • Page 19: General Settings

    The Web Interface 3.2.4 General Settings This panel below the Live View allows you to manage various settings, such as network, device settings and more, from the following tabs: User, DDNS, SMTP, Export, SCH, IP, SD, FW, Time, MEM, GPS, I/O, FTP and ALARM. [User] ◼...
  • Page 20 Administrator does not need to check if the IP address assigned by DHCP Server or ISP (in xDSL connection) has changed. Figure 3-7 1. Click Register to register a GeoVision DDNS Server or apply for a host name from other DDNS service provider’s website. 2. Type the Host Name used to connect to the device.
  • Page 21 The Web Interface ◼ SMTP Server: Type your SMTP Server’s URL address or IP address. ◼ Port: The default port for most SMTP servers is 25. However webmail Yahoo and Hotmail generally use differently SMTP port. In this case, check your e-mail provider for the SMTP port number.
  • Page 22 After completing the Export settings, you shall receive the report in a zip file at the appointed time. The format of the report is shown as the figure below. Figure 3-10 [SCH] To enable people counting only during the specified period within a day, click the checkbox and specify a time period.
  • Page 23 The Web Interface [IP] According to your network environment, select a Network Type. ◼ DHCP: Select if your network environment has a DHCP server which can assign a dynamic IP to your device. By default, this option is enabled. ◼ Static IP: To set up a fixed IP address, type the IP address, subnet Mask, DNS and Gateway of the static IP.
  • Page 24 [FW] GeoVision periodically releases updated firmware on website. Upload the new firmware and click Apply. Figure 3-13 [TIME] To automatically synchronize the device time with the server time every day, select Enable NTP Server Time SYNC. From the drop-down list, specify the time period when the syncronization is to take place everyday.
  • Page 25 The Web Interface [MEM] By default, the counting result is reset to zero at 12:00 midnight everyday. To set a different reset time, specify the time period from the drop-down list next to Counting value reset and click Apply. After modifying the reset time, you can also click Sync DB and the GV-Web Report Lite synchronizes the counting results to the last updated result.
  • Page 26 [I/O] ◼ Enable Input / Output: Enable the input and output device. ◼ Normal State: Select OpenCircuit (N/O) or Grounded Circuit (N/C) to set input state to trigger actions. ◼ Trigger digital output relay: Trigger an output upon detection of an related input. ◼...
  • Page 27 The Web Interface [FTP] The GV-3D People Counter V2 can act as a FTP server for external IP devices to download the recorded files saved on the memory card. ◼ Enable FTP access to the GV-3D People Counter V2: Select this option to allow external IP devices to access the device as a FTP server.
  • Page 28 [ALARM] Select Enable Occupancy Detection and Trigger digital output relay to trigger a digital output as the number of occupants exceeds the limit of Maximum occupancy, ranging from 1~65535 people. To define how long the triggered output will last, set up Pulse Mode in the I/O tab.

  • Page 29: Accessing People Counting Data

    The Web Interface 3.3 Accessing People Counting Data After the GV-3D People Counter V2 is properly configured and the data collection process begins, you can access the following pages for the people counting data in the format of tables, graphs and charts: •...
  • Page 30 3.2.2 People Counter Settings. The Total In, Total Out, Stay and Wrong Direction below the tables are the total number of people counted from all connected GV-3D People Counter V2. On the left menu, these options are available: ◼ Total List: Select a device to access its individual counting data. A green figure indicates that the device is connected to GV-Web Report Lite;...

  • Page 31: Group

    The Web Interface 3.3.2 Group In Group, you can organize the connected GV-3D People Counter V2 into hierarchy of groups and view the counting data of each device in a set group. When setting up a group, you can setup a threshold for the maximum number of people entered, left and remained so to activate a computer alarm on Counting Signage and an E-mail notification when the threshold is breached.
  • Page 32 8. To organize multiple groups into hierarchy, click Setting Group Relations in the left menu. Drag and drop a group under another group to make it a subordinate group. Figure 3-24 On the left menu of the Group page, you can find these options: ◼...

  • Page 33: Log

    The Web Interface 3.3.3 Log In Log, you can view the data of a specified time period, listed on an hourly basis, from a specific GV-3D People Counter V2 or group. Figure 3-25 To search the log data: 1. Select a Device or a Group.

  • Page 34: Query

    3.3.4 Query In Query, the counting data is provided on the daily, weekly, monthly and yearly graphs and tables. To search the counting data, select a Device or a Group, specify a date, and select the options below. To view the data in bar graph, line graph or pie chart, use the Chart drop-down list To back up the search results in EXCEL or WORD, click the icons at the bottom of the...
  • Page 35 The Web Interface The following figure is an example of the In/Out Counts per hour and Total Stay option. The value 9, 19 indicates the count of remaining people until 9 am is 19. Figure 3-27 [Weekly Report] Display the weekly report that contains the data of 7 days before your specified date.
  • Page 36 The following figure is an example of the In Percentage per day option. The value 2017-07-20 (Thu), 180 (53.41%) indicates the total number of entered people on 2017/07/20 is 180. The number takes up 53.41 percent of the total people entered for the week. Figure 3-28 [Monthly Report] ◼...

  • Page 37: Chapter 4 Auxiliary Device Connectors

    Auxiliary Device Connectors Chapter 4 Auxiliary Device Connectors The 8-pin terminal block, located on the rear panel, provides interfaces for connecting a digital input, a relay output and a GV-GPS Receiver. Figure 4-1 PIN Assignment Pin Function Digital Input Ground UART RX for GV-GPS Receiver UART TX for GV-GPS Receiver DC 5V Out for GV-GPS Receiver...

  • Page 38: Chapter 5 Gv-Ip Device Utility

    Chapter 5 GV-IP Device Utility GV-IP Device Utility can detect GV-3D People Counter V2 in the LAN and allows you to set the IP address of the device, upgrade firmware and reset the device. Download and install the GV-IP Device Utility from our website.
  • Page 39 GV-IP Device Utility ◼ Set IP Address: Type the IP address, subnet mask, default gateway and DNS server of the device. ◼ Firmware Upgrade: To upgrade the firmware, click Browse to specify the path of the firmware file and click Upgrade to proceed. You can select Upgrade all devices to upgrade all devices with the same username and password.

  • Page 40: Appendix

    Direct sunlight on the detection area may show up as a white region on the live view and interferes with people counting results. Avoid IR LED IR LED from the left of the view interferes with the IR sensor of the GV-3D People Counter V2 and causes part of the person’s head to appear dark.

  • Page 41: Detection Limitations

    Appendix Detection Limitations There are situations that may cause GV-3D People Counter V2 to falsely detect the number of people. Below are examples of situations that may or may not result in false detection. Actual: 1 Standing upright Counted: 1...
  • Page 42 Actual: 2 Head to head Counted: 1 Actual: 2 One hand on shoulder Counted: 1 Actual: 4 Multiple people Counted: 2 Actual: 5 Five People Counted: 3 Carrying a large backpack: Actual: 1 Backpack in close contact with the person’s head. Counted: 1 Actual: 2 Backpack at a distance from the...
  • Page 43 Appendix Pushing a cart: Actual: 1 Cart close to the person’s body. Counted: 1 Cart away from the person’s body. Actual: 1 Tip: Set a minimum detection height Counted: 2 that is higher than the cart to avoid false detection. Pushing a wheelchair: Actual: 2 The person pushing the wheelchair is...
